PARTS CATALOGUE

GN125
(NF41A)
GN125X

2012-9 2 ND EDITION
 GN125X

GN125X
 PREFACIO

Cuando sea necesario reemplazar piezas en las MOTOCICLETAS de SUZUKI, sirvase usar 4. NOTICIA DE MODIFICACIÓN
Siempre las PIEZAS GENUINAS DE SUZUKI que han pasado una estricta inspección de calidad y
rendimiento.
Este catálogo contiene todas las piezas de recambio para las SUZUKI GN125X.
nuevas y viejas.
INSTRUCCIONES SOBRE EL USO DEL CATALOGO
1. DIMENSIONES 5. NOTA
Las dimensiones de las piezas se indican en milímetros
5-1.Hay ciertas diferencias entre las piezas de producción en serie y
2. ABREVIATURAS las de recambio por razones administrativas y por su uso comun en
Las abreviaturas usadas son las siguientes: otros modelos.

AR : Lo necesario NT : Número de dientes 5-2.En cuanto a las mangueras de goma y los tubos de vinilo, sirvase
ASSY : Conjunto OPT : Opcional usarlos cortando segun la longitud mencionada en el catalogo o segun
E.No. : Número de motor OS : Sobremedida la realmente requerida por el vehiculo.
F.No. : Número de bastidor STD : Normalizado
D : Diametro del material T : Espesor 5-3. Debe observarse que las ilustraciones son para una rapida
ID : Diametro interno US : Submedida referencia del número de pieza y no para usarse como un manual de
OD : Diametro externo W : Ancho montaje: para ello emplee siempre el "MANUAL DE SERVICIO DE
L : Longitud SUZUKI".
LH : Lado izquierdo
RH : Lado derecho
6. CODIGO DE ESPECIFICACIÓN
~100045: Hasta F. No. 100045
100046~: Desde F. No. 100046 Código: E2, E4, E18, E21, E22, E71, P9

12 x 34 x 5.6 ...................... Los números en la columna de "Observaciones" muestran las

dimensiones de las piezas. 7. NÚMERO DE SERIE DE MARCO O CHASIS
ID OD T (ó W, L)
GN125X: NF41A-268499~
12345 C 56781 H 000

Las letras C y H indican que la fabricación de las

piezas es de origen Colombiano.

3. PIEZAS INTERNAS DEL CONJUNTO

Las piezas marcadas con un punto (.) antes de la
denominacion, forman parte de un conjunto.

GN125X E2
COLOR CHART ＭILLIMETER —› INCH CONVERSION CHART
TABLEAU DES COULEURS ＴABLA DE CONVERSION DE MILIMETROS —› PULGADAS

0 1 2 3 4 5 6 7 8 9

COLOR NO. COLOR DESCRIPTION COLOR NO. COLOR DESCRIPTION 00 .000 .039 .079 .118 .157 .197 .236 .276 .315 .354
NO DE COULEUR DESCRIPTION DE COULEUR NO DE COULEUR DESCRIPTION DE COULEUR
10 .394 .433 .472 .512 .551 .591 .630 .669 .709 .748

20 .787 .827 .866 .906 .945 .984 1.024 1.063 1.102 1.142
F6N 10R, 019, 1RR 20F CANDY PRESIDENT MAROON
30 1.181 1.220 1.260 1.299 1.339 1.378 1.417 1.457 1.496 1.535
G29 24G, 0VU 20H WARM SILVER METALLIC 40 1.575 1.614 1.654 1.693 1.732 1.772 1.811 1.850 1.890 1.929
G31 20H, ODH 24G LEGATO GOLD METALLIC 50 1.969 2.008 2.047 2.087 2.126 2.165 2.205 2.214 2.283 2.323
G33 24G, 0VU, 19A 291 BLACK (SEMI-GLOSS) 60 2.362 2.402 2.441 2.480 2.520 2.559 2.598 2.638 2.677 2.717

G34 20H, 0DW, 33J 3EX CANDY FOREST GREEN (Y98) 70 2.756 2.795 2.835 2.874 2.913 2.953 2.992 3.031 3.071 3.110

G8F 14B, 20F 33J PEARL NOVELTY BLACK 80 3.150 3.189 3.228 3.268 3.307 3.346 3.38 6 3.425 3.465 3.504

G8G 14B, 20F, Y0R 48H BLACK 90 3.543 3.583 3.622 3.661 3.701 3.740 3.78 0 3.819 3.858 3.898

L7Z 0FP, 019, 1RR

L8A 10R, Y4H, 20F

Ｈow to read
YOR CANDY FLARE RED Ｍodo de lectura.

Y4H ECRU SILVER METALLIC

0 1 2 3 4
Y98 CANDY FOREST GREEN 00 … … … … …

ODW AERO BLUE (TAPE) 10 … … … … …

20 … … … 0.906 …
OFP TRADITIONAL SILVER METALLIC 30 … … … … …
OVU PINKY PINK (TAPE)
23 millimeters equal 0.906 inch.
019 BLACK 23 milimetros igual 0.906 pulgadas

1RR BAT GOLD (TAPE)

10R MILKY WHITE

14B FANTASTIC COPPER GOLD METALLIC

19A CANDY ANTARES RED

Contents are subject to change without notice or obligation.
2AX PEARL NOVELTY BLACK (33J)

2HX CANDY ANTARES RED (19A)

GN125X E2
FIG.1
FIG.1 (B-3) CYLINDER HEAD
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 11100-05263 HEAD ASSY, CYLINDER 1 OPT
2 11115-05270 ·GUIDE, VALVE 2 GN125UV/UW/UX E22
3 09381-10004 ·RING, VALVE GUIDE 2
4 09206-08001 ·PIN 2 GN125UVE22
5 01550-06357 ·BOLT (6X35) 8 ~F.NO.242514
6 01550-06607 ·BOLT (6X60) 2
7 11141-05201 GASKET, CYLINDER HEAD 1 GN125UV/UW/UX E22
8 04211-11169 PIN, CYLINDER HEAD 2
9 09168-06023 WASHER 1
10 11151-45000 PAD, RUBBER 6
11 08316-10083 NUT 1 ~F.NO.239071
12 09159-08049 NUT 3 F.NO.239072~
13 09160-08053 WASHER 2 OPT
14 09168-08021 GASKET (8.5X17X2.3) 2 GN125UV/UW/UX E22
15-1 09482-00144 SPARK PLUG (NGK. D8EA) 1
15-2 09462-00145 SPARK PLUG (DENSO. X24ES - U) 1 GN125UVE22
15-3 09462-00399 SPARK PLUG (NGK. DR8EA) 1 ~F.NO.242514

15-4 09482-00223 SPARK PLUG (DENSO,X24ESR- U) 1 GN125UV/UW/UX E22

15-5 09482-00144 SPARK PLUG (NGK, D8EA) 1

15-6 09482-00145 SPARK PLUG (DENSO, X24ES -U) 1
15-7 09482-00399 SPARK PLUG (NGK. DR8EA) 1 ~F.NO.239071
15-8 09482-00223 GASKET SET 1 F.NO.239072~
16-1 11175-37111 CAP, INSPECTION 2 ~F.NO.242514
16-2 11175-18900 CAP, INSPECTION 2
17 09260-30001 O RING (D:3.0. ID:29.5) 2 GN125UV/UW/UX E22
18 09241-22002 PLUG, HEAD 1
19 26431-05201 GEAR, TACHOMETER DRIVEN 1
20 26441-49000 SLEEVE 1
21 26451-45000 SEAL BAND 1 ~F.NO.239071
22 09128-05101 SCREW 1 F.NO.239072~
23 09289-05002 OIL SEAL (5X12X8) 1

SFV650L1 E28_001
GASKET SET
GN125X E2
FIG.1
FIG.1 (B-3) CYLINDER HEAD
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
24-1 13110-05300 PIPE , INTAKE 1 OPT
24- 2 13110-05370 PIPE , INTAKE 1 GN125UV/UW/UX E22
25-1 09280-32006 O RING (D;2. 4 , ID:31 .7) 1
25-2 09280-32006 O RING (D;2. 4 , ID:31 .7) 1 GN125UVE22
~F.NO.242514
26-1 02112-36163 SCREW 2
26-2 09139-06014 SCREW 2 GN125UV/UW/UX E22
27 09402-44208 CLAMP 1
28 09103-08081 BOLT (8X50) 1
29 08319-31087 BOLT (8X50) 1
30-1 11401-05862 GASKET SET 1 ~F.NO.239071
30-2 11401-05863 GASKET SET 1 F.NO.239072~

SFV650L1 E28_001
GASKET SET
GN125X E2
FIG.2
FIG.2 CYLINDER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 11210-05202-0F0 CYLINDER 1
2 09108-08062 STUD BOLT (L:150) 2
3 09108-08089 STUD BOLT (L:155) 2
4 01421-06257 STUD BOLT (L:25) 4 OPT
5 08316-10067 NUT 4
6 11241-05311 GASKET, CYLINDER 1
7 04211-11149 PIN (L:14) 2

GN125X E2
FIG.3
FIG.3 CRANKCASE
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 11300-05303 CRANKCASE SET 1
1-2 11300-05340 CRANKCASE SET 1 GN125UV/UW/UX E22
2 04211-13189 ·PIN 2
3 01547-06557 ·BOLT (6X55) 4 OPT
4 01547-06607 ·BOLT (6X60) 4
5 01547-06757 ·BOLT (6X75) 4
6 11319-05200 ·PLATE 1
7 01500-06103 ·BOLT (6X10) 1
8 09103-08016 BOLT (8X80) 2
9 09103-08010 BOLT (8X88) 1
10 08319-31087 NUT 3
11 11365 05502 LIMITER, ENGINE SPROCKET 1 GN125UV/UW/UX E22
12 09139 06026 SCREW 2 GN125UV/UW/UX E22

GN125X E2
FIG.4
FIG.4 CRANKCASE COVER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 11340-05303 COVER, CLUTCH 1
2 11971-45010 ·LENS, OIL LEVEL 1
3 11462-05311 GASKET, CLUTCH COVER 1
4 04211-13169 PIN 2
5 01547-06307 BOLT (6X30) 9
6 01547-06457 BOLT (6X45) 1
7 09259-20007 PLUG, OIL FILLER 1
8 09260-17003 O RING (D:3.1, ID:16.8) 1
9 09247-14026 PLUG, OIL CHECK 1
10 09166-14002 GASKET 1
11 11351-05302 COVER, MAGNETO 1
12-1 11483-05311 GASKET, MAGNETO COVER 1 ~F.NO.239071
12-2 11483-05312 GASKET, MAGNETO COVER 1 F.NO.239072~
13 04211-09129 PIN 1
14 01547-06307 BOLT (6X30) 2
15 01547-06357 BOLT (6X35) 2
16 01547-06407 BOLT (6X40) 2
17 01547-06507 BOLT (6X50) 1
18 09247-12104 PLUG, T.D.C 1
19 09166-12002 GASKET 1
20 09259-26011 PLUG 1
21 09260-22008 O RING (D:3.1, ID:22.7) 1
22 11361-05301 COVER, ENGINE SPROCKET 1
23 01547-05357 BOLT 2
24 01547-05257 BOLT 1
25 09166-06024 GASKET 1

GN125X E2
FIG.5
FIG.5 CRANKSHAFT
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 12200-05340 CRANKSHAFT ASSY 1 ←12200-05323
2 12105-05821 ·ROD SET, CONNECTING 1
3 09263-28027-0B0 ··BEARING (28X36X15.8) 1
4 12221-05210 ·CRANKSHAFT, RH 1 ←12221-05202
5 12261-05301 ·CRANKSHAFT, LH 1
6 09262-28014 BEARING, RH (28X68X18) 1
7 09262-35038 BEARING, LH (35X72X17) 1
8 09282-12009 OIL SEAL, RH (12X21X7) 1
9 16321-05201 GEAR, OIL PUMP DRIVE 1
10 21111-05200 O RING (D:1.9,ID:12.6) 1
11 09140-16019 NUT 1
12 09166-16012 LOCK WASHER 1
13 09421-04004 KEY, GEAR 1
14 12111-05202-0F0 PISTON 1
15 12140-01410 RING SET, PISTON 1
16 12151-05220 PIN, PISTON 1
17 09381-14001 JET 2
18 12100-05200-050 PISTON SET (0.50) 1 OPT

GN125X E2
FIG.6
FIG.6 STARTER CLUTCH
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 12611-05300 GEAR, STARTER IDLE 1
2 09206-13003 PIN 1
3 09180-13006 SPACER 1
4 12600-05874 CLUTCH SET, STARTER 1 ←12600-05873
5 09261-10003 ·ROLLER 3
6 09440-03004 ·SPRING 3
7 12633-05300 ·PIECE 3
8 09263-22031 ·BEARING (22X28X16) 1
9 07130-06163 BOLT 3
10 12649-05300 SHIM 1

GN125X E2
FIG.7
FIG.7 CRAM SHAFT- VALVE
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 12711-05201 CAM SHAFT 1
2 12741-05201 SPROCKET (NT;32) 1
3 09261-05005 PIN 1
4 12747-05201 WASHER 1
5 09111-06032 BOLT (6X10.5) 2
6 09390-22002 O RING 1
7 12850-25C00 ARM, VALVE ROCKER 2
8 12842-32411 ·SCREW 2
9 12843-32400 ·NUT 2
10 12861-05201 SHAFT, ROCKER ARM 2
11 09280-09005 O RING (D:1.9. lD:8.6) 2
12 09168-06023 GASKET 2
13 09164-12021 WAVE WASHER 2
14 01550-06257 BOLT 2
15 12911-04B00 VALVE, INTAKE (H:3.92) 1
16 12912-24400 VALVE, EXHAUST (H: 3.92) 1
17 12920-05210 SPRING SET, VALVE, INTAKE 1
18 12920-05240 SPRING SET, VALVE , EXHAUST 1
19 12931-49200 RETAINER, SPRING 2
20 12932-24400 COTTER, VALVE 4
21 12933-49201 SEAT, SPRING 2
22 09289-05015 OIL SEAL (5.5X11X8.2) 2

GN125X E2
FIG.8
FIG.8 CAM CHAIN
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 12760-44A00 CHAIN, CAM SHAFT DRIVE 1 98LE
2 12771-05200 GUIDE, CAM CHAIN 1
3 12811-05220 TENSIONER, CAM CHAIN 1
4 12812-32400 BOLT 1
5 09168-08008 WASHER 1
6 12830-32452 ADJUSTER ASSY, TENSIONER 1
7 09440-11018 ·SPRING 1
8 12838-45001 ·SCREW 1
9 08316-10083 ·NUT 1
10 09280-06005 ·O RING (D:1.9, ID:5,7) 1
11 12837-32410 GASKET, TENSIONER ADJUSTER 1
12 01500-06203 BOLT 2

GN125X E2
FIG.9
FIG.9 CARBURETOR
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
13200-05313 CARBURETOR ASSY 1 GN125V E1
13200-05302 CARBURETOR ASSY 1 GN125V E1
13200-05313 CARBURETOR ASSY 1 E2,E21,E7I
13200-053D0 CARBURETOR ASSY 1 E18
13200-05302 CARBURETOR ASSY 1 E30
13200-05500 CARBURETOR ASSY 1 E4
13200-05510 CARBURETOR ASSY 1 E22
13200-05540 CARBURETOR ASSY 1 P9
1-1 09491-36005 ·JET, PILOT AIR (180) 1
1-2 09491-29010 ·JET, PILOT AIR (147.5) 1 E4 , E22. P9
← 09491-29009

2-1 13503-33200 ·SPRING, THROTTLE VALVE 1

2-2 13503-05350 ·SPRING, THROTTLE VALVE 1 E4, E22, P9
3 13502-33210 ·COVER 1
4-1 02112-33083 ·SCREW 2
4-2 02112-03063 ·SCREW 2 E4, E22, P9
5 13389-37400 ·PLATE 1
6 13431-05300 ·PACKING 1
7 09160-04015 ·WASHER 1
8-1 13410-05300 ·SHAFT ASSY, STARTER 1
8-2 13410-05500 ·SHAFT ASSY, STARTER 1 E4, E22, P9
9 13651-51010 ·SEAL 2 E18
10 13557-47070 ·PACKING 1 E18
11 13617-44080 ·E RING 1 E18
12-1 09492-35008 ·JET, PILOT (35) 1
12-2 09492-35010 ·JET, PILOT (37.5) 1 E18
12-3 09492-17006 ·JET, PILOT (17,5) 1 E4, E22, P9
13-1 13383-05310 ·NEEDLE, JET (4DZ35) 1
13-2 13383-05300 ·NEEDLE, JET (4DZ42) 1 E30
14-1 09494-00370 ·JET, NEEDLE ( P - 2) 1
14-2 09494-00725 ·JET, NEEDLE ( O - 8) 1 E4, E22, P9
15 13357-44080 ·PLUG 1 E1, E2, E18, E21, E30, E7l
16 13246-44080 ·GASKE T 1
17 13247-44080 ·SCREW, DRAIN 1

GN125X E2
FIG.9
FIG.9 CARBURETOR
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
18-1 09491-20012 ·JET, MAIN (102.5) 1
18-2 09491-97003 ·JET, MAIN (97,5) 1 E4, E22, P9
19 13382-03110 ·WASHER 1 ← 13332-44080
20-1 13373-11400 ·PLATE 1
20-2 15373-39110 ·PLATE 1 E18,E30
20-3 13373-11400 ·PLATE 1 GN125V E1
20-4 13373-39110 ·PLATE 1 GN125EV E1
21 02112-04063 ·SCREW 1
22 13250-05300 ·FLOAT 1
23 13254-92311 ·PIN 1
24 13370-44500 ·VALVE ASSY, NEEDLE (2.0) 1
25 13374-44080 ·O RING 1
26 13376-84110 ·NET 1
27 13251-05400 ·GASKET 1
28 13500-053D0 ·DIAPHRAGM ASSY 2
29 13388-44030 ·SPRING 2
30 13382-44030 ·WASHER 1
31 13394-10010 ·E RING 1
32 13387-47010 ·RING 1
33-1 13438-33110 ·SCREW 1
33-2 13433-33110 ·SCREW 1 E4, E22, P9
34 13426-43010 ·SPRING 2
35 13615-43010 ·WASHER 1
36 09352-50823-600 ·HOSE (5X8.2X600) 1 L: 600 300
←

37 02112-05087 ·SCREW 1
38 13422-05300 ·LEVER 1
39 13605-31210 ·SCREW 1
40 09351-35653-600 ·HOSE (3.5X6.5X600) 1 L: 600 350
←

41 13268-37420 ·SPRING 1
42 15267-25D00 ·ADJUSTER 1 ← 3267-37100
43-1 13601-04148 ·SCREW 1
43-2 13601-45C00 ·SCREW 1 E4, E22, P9

GN125X E2
FIG.9
FIG.9 CARBURETOR
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
44-1 13279-45400 ·SCREW, PILOT (1 7/8) 1 E2, E4, E21, E22, E71
44-2 13279-45400 ·SCREW, PILOT (2 0) 1 E9O
44-3 13279-45400 ·SCREW, PILOT (1 1/4) 1 P9
44-4 13279-45400 ·SCREW, PILOT (1 7/8) 1 GN125V E1
44-5 13279-45400 ·SCREW, PILOT (2 0) 1 GN125V E1
45 13295-29900 ·O RING 1 EXCEPT E18
46 13291-29900 ·WASHER 1 EXCEPT E18
47 13266-47070 ·SPRING 1 EXCEPT E18
48-1 13261-05A00 ·PLUG 1 E1, E2, E21, E30, E71
48-2 13357-36A00 ·PLUG 1 E4, E22 , P9
49 13560-05500 ·SENSOR ASSY 1 E4, E22
50 13602-55A00 ·SCREW 2 E4, E22

GN125X E2
FIG.10
FIG.10 AIR CLEANER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 13700-05302 CLEANER ASSY 1
1-2 13700-05360 CLEANER ASSY 1 E18,E22
2 13780-36301 ·FILTER 1
3 09402-56206 ·CLAMP 1
4 13881-05300 ·TUBE, OUTLET 1
5 13826-38300 ·CLAMP 1
6-1 13853-05300 ·TUBE, BREATHER 1
6-2 13650-05360 ·TUBE, BREATHER 1 E18,E22
7 09401-14401 ·CLIP 2
8 13670-21308 ·TUBE, DRAIN 1
9 09401-13409 ·CLIP 1
10 02142-05127 ·SCREW 3
11 01560-06163 BOLT 2
12-1 02142-06163 SCREW 1 MODEL V
12-2 01560-06163 BOLT 1 MODEL W/X

SFV650L1 E28_010
CAM CHAIN
GN125X E2
FIG.11
FIG.11 MUFFLER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 14181-18C00 GASKET, EXHAUST PIPE 1
2-1 14305-053A0 MUFFLER 1 E2, E21, E71, P9
2-2 14305-05313-H01 MUFFLER 1 E18, E30
2-3 14305-053B0 MUFFLER 1 E4, E22
2-4 14305-053A0 MUFFLER 1 GN125V E1
2-5 14305-05313-HO1 MUFFLER 1 GN125EV E1
3 07130-08253 BOLT 2
4 08322-01103 WASHER 1

GN125X E2
FIG.12
FIG.12 OIL PUMP
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 16400-05201 PUMP ASSY, ENGINE OIL 1
2 16331-05200 GEAR DRIVEN (NT:30) 1
3 09261-02008 PIN 1
4 08332-11063 CIRCLIP 1
5 02112-06253 SCREW 3
6 16520-05202 STRAINER, ENGINE OIL 1
7 02112-75123 SCREW 2
8 16523-05200 CAP. OIL STRAINER 1
9 09280-60005 O RING (D:2.4, IDm5) 1
10 01547-06203 BOLT 3
11-1 09247-14001 PLUG, DRAIN 1 ~E.NO.423057
11-2 09247-14026 PLUG, DRAIN 1 E.NO.423058~
11-3 09247-14026 PLUG, DRAIN 1 E30
11-4 09247-14001 PLUG, DRAIN 1 GN125V E1
11-5 09247-14026 PLUG, DRAIN 1 GN125EV E1
12 09168-14002 GASKET 1
13 16510-05240 FILTER ENGINE OIL 1
14 09280-13004 O RING (D:1.9, ID:13) 1
15 16512-05212 CAP, OIL FILTER 1
16 09280-54001 O RING (D:2. 4,ID:52. 6) 1
17 09440-18002 SPRING 1
18 01421-06128 STUD BOLT 2
19 01421-06858 STUD BOLT 1
20 08313-10067 NUT 3

GN125X E2
FIG.13
FIG.13 CLUTCH
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 21200-05880 GEAR ASSY, PRIMARY DRIVEN 1
2 08211-20353 WASHER 1
3 21411-05200 HUB, SLEEVE 1
4 09140-16005 NUT 1
5 09169-16003 LOCK WASHER 1
6 08211-20352 WASHER 1
7 21441-13A01 PLATE, DRIVE 5
8 21451-19A00 PLATE, DRIVEN 4
9 21462-14102 DISK, PRESSURE 1
10 09440-15014 SPRING 5
11-1 09116-05003 BOLT (5X16) 5
11-2 09116-05020 BOLT (5X16) 5
12 23110-05202 ROD, PUSH 1
13 23121-38201 PIECE 1
14 23122-05200 CAM SHAFT 1
15 09181-10195 WASHER (10X20X1.0) 1
16 09160-15045 WASHER (15,5X28X1) 1
17 09263-15003 THRUST BEARING ( 15X28X2) 1
18 09282-10012 OIL SEAL (10X20X6) 1
19 09134-06010 SCREW 1
20 09140-06023 NUT 1
21 23271-46010 ARM, RELEASE 1
22 01500-06167 BOLT 1
23 02142-06103 STOPPER 1

GN125X E2
FIG.14
FIG.14 TRANSMISSION
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 24120-05810 COuNTERSHAFT (NT:11) 1
2 24125-36201 BUSH 1
3 24221-05301 GEAR, 2ND DRIVE (NT:14) 1 ← 24221-05300

4 24231-05203 GEAR. 3/4 DRIVE (NT:19/21) 1 ← 24231-05202

5 24251-05203 GEAR, 5TH DRIVE (NT:23) 1 ← 24251-05202

6 09360-20009 CIRCLIP 1
7 09262-20069 BEARING, RH (20X47X14) 1
8 06123-60027 BEARING, LH 1
9 24741-05200 HOLDER BEARING 1
10 02122-06123 SCREW 2
11-1 24130-05300 DRIVESHAFT 1
11-2 24130-05310 DRIVESHAFT 1 E4 , E22
12 24311-05201 GEAR, 1ST DRIVEN (NT:33) 1 ← 24311-05200

13 06211-15251 WASHER 2
14 09263-15023 BEARING (15X19X7.8) 1
15 24320-05202 GEAR, 2ND DRIVEN (NT:26) 1 ← 24320-05201
16 09380-20009 CIRCLIP 3
17 24331-05203 GEAR, 3RD DRIVEN (NT:26) 1 ← 24320-05201

18 09167-20011 WASHER (20.5X25X0.5) 2

19-1 24341-05201 GEAR, 4TH DRIVEN (NT:23) 1 ← 14153-87D11

19-2 24341-05203 GEAR, 4TH DRIVEN (NT:23) 1 ← 14141-87D02-02M

20-1 24351-05201 GEAR, 5TH DRIVEN (NT:21) 1 ← 14141-87D02-01T

20-2 24351-05202 GEAR, 5TH DRIVEN (NT:21) 1 ~model:94
21 24359-05200 WASHER 1
22 24421-05300 WHEEL 1
23 09263-15024 BEARING, RH (15X33X12) 1
24 09262-20069 BEARING, LH (20X47X14) 1 ← 09401-25403
25 24741-05200 HOLDER BEARING 1 model:92~97
26 02122-06123 SCREW 2 model:89
27 09263-27010 OIL SEAL, LH (27X40X6) 1 model:91~94
28-1 24751-05201 HOLDER, OIL SEAL 1 model:91~97
28-2 24751-05210 HOLDER, OIL SEAL 1 model:91~97
29 01500-06103 BOLT 2 model:91~97
30 09161-15111 WASHER (15X20X1.0) 1
31 06331-31156 CIRCLIP 1

GN125X E2
FIG.14
FIG.14 TRANSMISSION
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
32 27511-41310 SPROCKET (NT:14) 1
32A 27510-41730 SPROCKET (NT:14) 1 E4, E22
33 27531-05200 SPACER 1
34 09280-19005 O RING (D:2.40, ID:19) 1
35 09140-16017 NUT 1
36-1 09167-20012 WASHER (18X38XO,8) 1 MODEL V/W E4, E22
36-2 09167-20006 WASHER (20.5X38X0.8) 1 MODEL X E4, E22
36-3 09167-20030 WASHER (16.5X38X08) 1 L:124 114
←

37 27600-29B20-124 CHAIN (RK428FDZ, 124LE) 1

38 27620-40220 ·JOINT, CHAIN (RK) 2

GN125X E2
FIG.15
FIG.15 GEAR SHIFTING
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 25221-08300 FORK, GEAR SHIFTING (1) 2
2 25231-05201 FORK, GEAR SHIFTING (3) 1
3 25411-16701 SHAFT, FORK (1) 1 ←25411-05201
4 25421-35403 SHAFT, FORK (2) 1
5 25310-05300 CAM, GEAR SHIFTING 1
6 09181-25251 WASHER (25X40X1.0) 1
7 25322-31310 GEAR, CAM DRIVEN 1 ←2322-31302
8 25323-34201 PAWL, (1) 1
9 25324-34201 PAWL, (2) 1
10 09261-05003 PIN 2
11 09440-04003 SPRING 2
12 25331-30001 LIFTER, PAWL 1
13 02122-06123 SCREW 2
14 25341-05200 GUIDE, CAM 1
15 02122-06123 SCREW 2
16 25350-44A00 STOPPER, CAM 1
17 09111-06054 BOLT (6X14.6) 1
18 06211-06141 WASHER 1
19 09440-11016 SPRING 1 L:27
20 09443-08044 SPRING 1
21 09223-04001 HOOK 1
22 25351-30010 STOPPER, NEUTRAL 1
23 25381-45400 PLATE, STOPPER 1
24 04221-04069 PIN 1
25 09247-14026 PLUG, CAM STOPPER 1
26 09168-14002 WASHER (13.8XI8.8X0.4) 1
27 25510-05201 SHAFT, GEAR SHIFTING 1
28 09160-12068 SPACER (12X20X15.3) 1
29 09444-26013 SPRING 1
30 25671-01000 STOPPER, ARM 1
31 09285-12002 OIL SEAL (12X22X9) 1
32 01500-06203 BOLT 1

GN125X E2
FIG.15
FIG.15 GEAR SHIFTING
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
33 25600-05320 LEVER ASSY, GEAR SHIFTING 1
34 25652-16500 ·RUBBER 1
35-1 37720-47D00 BASE ASSY, GEAR TERM 1
35-2 37720-44700 BASE ASSY, GEAR TERM 1 GN125V/W/X E4
GN125EV/EW/EX E1 E30
35A 37730-05310 BASE ASSY, GEAR TERM 1 GN125V/W/X E22
35B 37730-05300 BASE ASSY, GEAR TERM 1 GN125UV/UW/UX E22
36 09280-26003 O RING (D:2,4 ID:26.2) 1
37 02112-75203 SCREW 2
37A 09119-05022 BOLT (5X19) 2 GN125UV/UW/UX E22
37B 02142-05203 SCREW 2 GN125V/W/X E22
38 09209-05011 CONTACT 1
39 09440-04010 SPRING 1

GN125X E2
FIG.16
FIG.16 STARTING MOTOR
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 31100-05501 MOTOR ASSY, STARTING 1
2 31310-11D00 ·ARMATURE 1
3 31175-42A01 ·FRAME ASSY, COMMUTATOR, END 1
4 31132-32C10 ··BRUSH 2
5 31130-32C20 ··BRUSH SUB ASSY 1
6 31133-32C10 ··HOLDER, BRUSH 1
7 02112-34123 ··SCREW 2
8 31135-32C10 ·SPRING 4
9 31281-32C10 ·BOLT 2
10 31156-38300 ·O RING 2
11 31264-32C10 ·O RING 2
12 31361-38300 ·SHIM 1
13 31361-32C10 ·PLATE, LOCK 1
14 31150-06C00 ·BRACKET 1
15 09280-24003 ·O RING (D:3, ID:24.5) 1
16 01547-06307 BOLT 2
17 09137-05004 SCREW 1

GN125X E2
FIG.17
FIG.17 MAGNETO
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 32101-05300 STATOR ASSY 1
2 32102-05300 ROTOR, FLYWHEEL 1
3 02112-05253 SCREW 3
4 02142-04123 SCREW 2
5 06316-10103 NUT 1
6 06341-31039 KEY 1

GN125X E2
FIG.18
FIG.18 BATTERY
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 33610-10310 BATTERY (YB7---A, 12V, 8AH) 1
2 33651-37000 PROTECTOR (170X95X3) 4 CUT AS REQUIRED PROFILE
3 33652-28000 CUSHION (20X45X6) 1 (30X40X3)
4 33680-16A10 HOSE, BATTERY EXHAUST 1
5 09462-00020 BAND 1 L:780 450
6 33820-053A0 WIRE, BATTERY (+) 1
7 31861-10D00 ·CAP, STARTER RELAY 1
8 33624-43500 ·CAP, BATTERY PLUS 1
9 33860-05550 LEAD WIRE, BATTERY (-) 1
10 33690-05360 PLATE, BATTERY CAUTION 1

GN125X E2
FIG.19
FIG.19 ELECTRICAL
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 31800-49100 RELAY, STARTING MOTOR 1
2-1 09128-06004 SCREW (6X10) 2 MODEL V/W
2-2 09128-06044 SCREW (6X10) 2 MODEL X
3 08361-35068 NUT 2
4 33850-05301 LEAD WIRE, STARTING MOTOR 1
5 31861-31500 CAP, STARTER RELAY TERMINAL 2
6 32800-29B00 RECTIFIER- REGULATOR 1
7 09128-06057 SCREW (6X20) 2
8 32900-05300 IGNITER ASSY 1
9-1 32900-05330 IGNITER ASSY 1 E4
9-2 32900-05340 IGNITER ASSY 1 E22
10 32931-053A0 BRACKET, IGNITER 1 E4, E22
11 32980-05300 CUSHION 2 E4, E22
12 08316-10063 NUT 2 E4, E22
13 33410-05350 COIL, IGNITION 1
14 02142-05103 SCREW 2
15 33510-22010 CAP, SPARK PLUG 1
16 33541-24510 SEAL, SPARK PLUG 1
17 33542-38B00 SEAL, HIGHTENSION CORD 1

GN125X E2
FIG.20
FIG.20 SPEEDOMETER - TACHOMETER (GN125V/W/X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 34110-05310 SPEEDOMETER (MILE/KILO) 1
1-2 34110-05300 SPEEDOMETER CKILO) 1 E1, E4, E18, E21, E22, E71, P9
2 34210-05320 TACHOMETER 1
3 34173-05300 SOCKET, TACHOMETER 1
4 34273-05320 SOCKET, TACHOMETER 1
5 09471-12082 BULB (12V,3.4W) 5
6 34950-05300 BRACKET 1
7 34193-05300 ORNAMENY, SPEEDOMETER 1
8 34293-05300 ORNAMENT, TACHOMETER 1
9 34956-28011 CUSHION 1
10 09160-05013 WASHER (5.2X16X 1) 4
11 34187-28310 SPACER 4
12 34189-28310 CUSHION 4
13 09160-05024 WASHER (5.5X16X1.5) 2
14 08313-10057 NUT 4
15 01550-06163 BOLT 2
16 34910-05310 CABLE, SPEEDOMETER 1
17 34940-05300 CABLE, TACHOMETER 1
18 58621-21203 GUIDE, SPEDOMETER CABLE 1

GN125X E2
FIG.21
FIG.21 HEADLAMP (E2, E71, P9)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 35100-44270 HEADLAMP ASSY 1
2 35111-37350 ·RIM 1
3 35121-44270 ·UNIT 1
4 09471-12044 ·BULB (12V,45/45W) 1
5 35171-44270 ·SOCKET 1
6 09471-12001 ·BULB (12V, 3.4W) 1
7 36118-30500 ·SOCKET 1
8 35172-33630 ·SPRING 3
9 02122-05127 SCREW 2
10 09169-05008 WASHER 2
11 02142-05087 SCREW 2

REFER TO FIG.21A (D-9) FOR E4, E18, E21, E22

REFER TO FIG.21B (D-10) FOR GN125E E1, E30

GN125X E2
FIG.22
FIG.22 TURN SIGNAL LAMP (E1, E2, E4, E18, E21, E22, E71, P9)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 35601-39370-999 LAMP, FRONT TURN SIGNAL 1 ←5601-39370
2 35612-02460 ·LENS 1
3 35613-28620 ·GASKET 1
4 03211-04208 ·SCREW 1
5 35627-43010 ·GASKET 1
6 09471-12045 BULB (12V,21W) 1 PURCHASE LOCALLY
7 35695-36590 SPACER 1
8 35690-32200 CUSHION 1
9-1 09160-10006 WASHER (10.5X30X2.3) 1 MODEL V
9-2 09160-10501 WASHER (10.5X30X2.3) 1 MODEL W/X
10 08310-00107 NUT 3
11 36660-33000 LEAD WIRE, EARTH 1
12-1 35603-26420-999 LAMP, REAR TURN SIGNAL 1
12-2 35603-39380 LAMP, REAR TURN SIGNAL 1 E18, E22
13 35652-02470 ·LENS 1
14 35613-28620 ·GASKET 1
15 03211-04208 ·SCREW 1
16 35627-43010 ·GASKET 1
17 09471-12045 ·BULB (12V, 21W) 1 PURCHASE LOCALLY
18 35695-36590 SPACER 1
19 09320-15004 CUSHION 1
20 09160-10501 WASHER (10.5X30X2.3) 1 ←09160-1006
21 08310-00107 NUT 1
22 36862-44000 LEAD WIRE, EARTH 1
23-1 35621-36300 BRACKET, RH 1 E1,E2, E4, E21,. E71, P9
23-2 35641-38300 BRACKET, LH 1 E1,E2, E4, E21,. E71, P9
24-1 38610-31X50 RELAY, TURN SIGNAL 1
24-2 38610-45091 RELAY, TURN SIGNAL 1 MODEL V
E18, E22
24-3 38610-06F00 RELAY, TURN SIGNAL 1 MODEL W(X
E18, E22
REFER TO FIG.22A (E-3) FOR GN125E E1, E30

GN125X E2
FIG.23
FIG.23 REAR COMBINATION LAMP (E1, E71, P9)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 35720-05311-999 LAMP UNIT. TAIL 1
2 35712-48624 ·LENS 1
3 35713-30510 ·GASKET 1
4 09471-12035 ·BULB ( 12V, 23/8W) 1
5 09125-04002 ·SCREW (4X55) 2
6 02112-05127 ·SCREW 2
7 08310-00057 ·NUT 2
8 08322-01057 ·WASHER 2
9 35730-26470 BRACKET UNIT 1
10 35766-26470 ·SPACER 3
11 35765-26470 ·CUSHION 1
12 35764-26470 ·CUSHION 3
13 09116-06167 BOLT (6X20) 3
14 08310-00063 NUT 3

REFER TO FIG.23A (E- 5) FOR E2, E4, E21

REFER TO FIG.238 (E- 6) FOR E18, E22
REFER TO FIG 23 (E- 7) FOR GN125E E1, E30

GN125X E2
FIG.24
FIG.24 WIRING HARNESS (GN125V/W/X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 36610-053G1 WIRING HARNESS 1 ←36610-053G0
1-2 36610-053F0 WIRING HARNESS 1 E4, E22
1A 09481-15001 ·FUSE (15A) 1
2 09407-05403 CLAMP (L:55) 1
3-1 09407-14403 CLAMP (L:125) 3
3-2 09407-18403 CLAMP (L:165) 3
3-3 09407-26401 CLAMP (L:235) 1
4 36619-37300 CLAMP 1
5 36651-05301 CLAMP, CABLE 1
6 37110-33021 SWITCH ASSY, IGNITION 1
7 37740-31D00 SWITCH REAR BRAKE LAMP 1
8 09443-06078 SPRING 1
9-1 38500-38361 HORN 1
9-2 38500-38390 HORN 1 E4, E18, E21, E22
10 01550-08163 BOLT 1
11 36852-05300 WIRE, CLUTCH SWITCH LEAD 1
12 36791-46700 HOLDER, FUSE CASE 1
13 37145-19710 KEY, BLANK 1 OPT
14 38740-24X50 STAND 1
15 38741-05300 SRACKET, RELAY 1
16 37640-11X50 SWITCH ASSY, SIDE STAND 1
17 37841-14D00 PROTECTOR 1
18 01550-06203 SCREW 2

REFER TO FIG 24A (E- 9) FOR GN125EV/EW/EX

GN125X E2
FIG.25
FIG.25 HANDLE SWITCH
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 37200-45C03 SWITCH ASSY, HANDLE RH 1 GN125V/W
1-2 37200-45C12 SWITCH ASSY, HANDLE RH 1 GN125EV/EW
2 02112-05453 ·SCREW 2
3 37400-06B12 SWITCH ASSY, HANDLE LH 1
4 02112-05453 ·SCREW 2

GN125X E2
FIG.26
FIG.26 FRAME
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 41100-053E0-019 FRAME (BLACK) 1
1-2 41100-053F0-019 FRAME (BLACK) 1 E18, E22
2 41991-05300 PLATE, UPPER 2
3 09103-08081 BOLT 2
4 08319-31087 NUT 2
5 41992-05300 PLATE, LOWER 1
6 01550-08657 BOLT 2
7 08319-31087 NUT 2
8 41540-38301 HOLDER, BATTERY 1
9 09116-06168 BOLT 2
10 09180-06038 SPACER 2
11 09320-08021 CUSHION 2
12 09800-21020 TOOL, ASSY 1
13 47431-05300 BOX, TOOL 1
14 47432-05300 CAP 1
15 47440-05301 PLATE 1
16 09116-06168 BOLT 1
17 09180-06038 SPACER 1
18 09320-08021 CUSHION 1
19 08316-10063 NUT 3

GN125X E2
FIG.27
FIG.27 STAND
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 42100-05303 STAND, CENTER 1
2 42211-36504 SHAFT 1
3 04111-30308 COTTER PIN 1
4 09443-18006 SPRING 1
5 09443-15013 SPRING, No.1 1 E18, E22
6 09443-22003 SPRING, No.2 1 E18, E22
7 09321-10001 CUSHION 1
8 42310-053E0 STAND, PROP 1
9 09111-10047 BOLT 1
10 09443-12025 SPRING, No.1 1
11 09443-19006 SPRING, No.2 1
12-1 09159-10027 NUT 1 MODEL V/W
12-2 08319-21103 NUT 1 MODEL X
13 43110-05301 PEDAL, BRAKE 1
14 09443-14015 SPRING 1
15 43231-05302 SPACER 1
16 09116-10121 BOLT 1
17 04111-20208 COTTER PIN 1
18 09100-06009 BOLT 1
19 08310-00063 NUT 1
20 43261-17C00 TUBE, SPRING 1

GN125X E2
FIG.28
FIG.28 FOOTREST
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 43510-05330 BAR, FOOTREST RH 1
2 43520-05330 BAR, FOOTREST LH 1
3 43550-37301 RUBBER, FOOTREST RH 1
4 43560-37301 RUBBER, FOOTREST LH 1
5 01550-12257 BOLT 2
6 09200-08002 PIN 2
7 04111-20208 COTTER PIN 2
8 09448-14012 SPRING 2
9 43600-05301 FOOTREST ASSY, PILLION LH 1
10 43700-05301 FOOTREST ASSY, PILLION RH 1
11 43610-03001 ·BAR, PILLION FOOTREST 2
12 43612-33200 ·RUBBER 2
13-1 09160-19006 ·WASHER 2 MODEL V
13-2 09160-19023 ·WASHER 2 MODEL W/X
14 09200-06033 ·PIN 2
15 04111-20158 ·COTTER PIN 2
16 01550-10453 BOLT, RH 1
17 08316-10103 NUT 1
18 01550-10253 BOLT, LH 1

GN125X E2
FIG.29
FIG.29 CARRIER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 46210-05300 HANDLE, PILLION RIDER 1
2 95700-37810 LOCK SET, HELMET 1
3 09139-06075 SCREW 2
4 46310-05300 CARRIER, SPORT 1 OPT
5 46300 05860 CARRIER SET, SPORT 1 OPT E22
6 68391-44AD0 ·LABEL 1 OPT E22

GN125X E2
FIG.30
FIG.30 FUEL TANK (MODEL X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 44100-383A0-2HX TANK ASSY, FUEL (RED) 1 FOR 19A
1-2 44100-383A0-2AX TANK ASSY, FUEL (BLACK) 1 FOR 33J
1-3 44100-383A0-3EX TANK ASSY, FUEL (GREEN) 1 FOR Y96
1-4 44100-383A0-Y4H TANK ASSY, FUEL (SILVER) 1 FOR Y4H
1-5 44100-383BO-2HX TANK ASSY, FUEL (RED) 1 E18, E22 FOR 19A
1-6 44100-383B0-2AX TANK ASSY, FUEL (BLACK) 1 E18, E22 FOR 33J
1-7 4100-383B0-3EX TANK ASSY, FUEL (GREEN) 1 E18, E22 FOR Y98
1- 8 44100-383B0-Y4H TANK ASSY, FUEL (SILVER) 1 E18, E22 FOR Y4H
2-1 68110-38340-L7Z ·TAPE SET, FUEL TANK 1 FOR 2HX, 2AX, 3EX
2-2 68110-38340-L8A ·TAPE SET, FUEL TANK 1 FOR Y4H
3 68111-37300 EMBLEM 2
4 02122-03063 SCREW 4
5 44200-30830 CAP SET, FUEL TANK 1
6 09329-10016 CUSHION, FRONT 2
7 44541-05300 CUSHION, UPPER FRONT 1
8 44542-38300 CUSHION, REAR LOWER 1
9 09320-10022 CUSHION, REAR 2
10 09180-06067 SPACER 2
11 09160-06054 WASHER 2
12 09100-06033 BOLT 2

GN125X E2
FIG.31
FIG.31 FUEL COCK
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 44300-22075 COCK ASSY , FUEL 1 MODEL V/W
1-2 44300-22080 COCK ASSY , FUEL 1 MODEL X
2 44346-28070 ·O RING, JOINT 1
3 44347-28071 ·CUP 1
4 44346-28070 ·O RING, CUP 1
5 44353-12C01 ·O RING, LEVER 1
6 44357-32470 ·SPRING 1
7 44343-41370 ·SCREW 1
8 09126-06057 SCREW 2
9 09166-06026 GASKET 2
10 09352-50823-600 HOSE, FUEL (L:600- 140) 1
11 09401-06401 CLIP 2

SFV650L1 E28_031
SPEEDOMETER
GN125X E2
FIG.32
FIG.32 FRAME COVER (MODEL X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 47111-05301-19A COVER, FRAME RH (RED) 1
1-2 47111-05301-33J COVER, FRAME RH (BLACK) 1
1-3 47111-05301-Y98 COVER, FRAME RH (GREEN) 1
1-4 47111-05301-Y4H COVER, FRAME RH (SILVER) 1
2-1 47211-05301-19A COVER, FRAME LH (RED) 1
2-2 47211-05301-33J COVER, FRAME LH (BLACK) 1
2-3 47211-05301-Y98 COVER, FRAME LH (GREEN) 1
2-4 47211-05301-Y4H COVER, FRAME LH (SILVER) 1
3-1 68135-38300-L7Z TAPE, FRAME COVER 2 FOR 19A, 33J, Y98
3-2 68135-38300-L8A TAPE, FRAME COVER 2 FOR Y4H
4 66131-05310 EMBLEM 2
5 09146-03003 NUT 4
6 09320-03004 CUSHION, LOWER RH 1
7 09320-08018 CUSHION 5

GN125X E2
FIG.33
FIG.33 FRONT FENDER - HEADLAMP HOUSING
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 53110-05301 FENDER. FRONT 1
2 01570-08163 BOLT 4
3 51810-44201 HOUSING, HEADLAMP 1
4 01264-08207 BOLT 2
5 51821-36200 SPACER, HOUSING 2
6 51827-27302 CUSHION, HOUSING 2
7 94631-33C01 MOLDING, HOUSING 1

GN125X E2
FIG.34
FIG.34 REAR COMBINATION LAMP
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 56110-05321 HANDLEBAR 1
2 56500-44200 MIRROR ASSY, REAR VIEW RH 1 E1 , E71, P9
3 56600-44200 MIRROR ASSY, REAR VIEW LH 1 E1,E71, P9
4 56500-45640 MIRROR ASSY, REAR VIEW 2 E2, E21
5 56500-28601 MIRROR ASSY, REAR VIEW 2 E4, E18, E22
6 56170-05300 COVER, STEERING HEAD 1
7 58200-05391 CABLE ASSY, CLUTCH 1
8 09200-06004 PIN 1
9 04111-20158 COTTER PIN 1
10 58626-37400 CLAMP, No. 1 1
11 02112-16103 SCREW 1
12 58285-05351 CLAMP, No.2 1
13 02112-05163 SCREW 1
14 08310-00053 NUT 1
15 58300-05320 CABLE ASSY, THROTTLE 1

GN125X E2
FIG.35
FIG.35 HANDLE LEVER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 57110-34300 GRIP, THROTTLE 1
2 56115-05300 SPACER, HANDLE RH 1
3 57421-13001 LEVER, BRAKE (BLACK) 1
4 57431-13030 SCREW 1
5 08319-21063 NUT 1
6 57460-17C00 SWITCH ASSY, STOP 1
7 57465-17C00 SCREW 1
8 57211-34300 GRIP, LH 1
9 57500-05390 LEVER ASSY, CLUTCH 1
10 57620-05390 ·LEVER, CLUTCH 1
11 57431-45C00 ·BOLT 1
12 57433-09F00 ·NUT 1
13 01547-06203 ·BOLT 2
14 57441-45C00 ·ADJUSTER 1
15 57442-45C00 ·NUT 1
16 57560-05A00 ·SWITCH 1
17 02122-03208 ·SCREW 1
18 57661-31000 COVER, CLUTCH LEVER 1
19 58273-31000 BOOT, CLUTCH CABLE 1
20 09407-12402 CLAMP (L:120) 4

GN125X E2
FIG.36
FIG.36 REAR FENDER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 63112-05302 BODY, REAR FENDER, FRONT 1
2-1 63110-38312 FENDER, REAR 1 MODEL V/W
2-2 63110-38313 FENDER, REAR 1 MODEL X
2-3 63110-38322 FENDER, REAR 1 MODEL V/W E18, E22
2-4 63110-38323 FENDER, REAR 1 MODEL X E 18, E22
2-5 63110-38302 FENDER, REAR 1 MODEL V/W E30
2-6 63110-38303 FENDER, REAR 1 MODEL X E30
2-7 63110-38312 FENDER, REAR 1 GN125V E1
2-8 63110-38302 FENDER, REAR 1 GN125EV E1
3 01560-06163 BOLT, FRONT 2
4 09320-06504 CUSHION 2
5 01560-08257 BOLT, REAR 2
6 06316-10083 NUT, REAR 2
7-1 66319-33E00 LABEL, SAFETY (ENGLISH) 1
7-2 68319-33E30 LABEL, SAFETY (FRANCH) 1 E4, E18, E21
7-3 66319-33E20 LABEL SAFETY (GERMAN) 1 E18, E22
7-4 66319-33E40 LABEL, SAFETY (ITALIAN) 1 E18
7-5 66319-33E50 LABEL, SAFETY (SPANISH) 1 E71, P9
8-1 66332-05320 LABEL, TIRE AIR PRESSURE 1 MODEL V
8-2 68332-05350 LABEL, TIRE INFORMATION 1 MODEL W/X
9 68623-17D00 LABEL, FUEL CAUTION 1 E2
10-1 99011-05351-GDU MANUAL, OWNERS 1 MODEL V
10-2 99011-05352-GDU MANUAL, OWNERS 1 MODEL W
10-3 99011 -05353-DGS MANUAL, OWNERS 1 MODEL X
DRAWING NOT SHOWN

GN125X E2
FIG.37
FIG.37 SEAT
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 37200-38G30 SEAT ASSY (BLACK) 1
2 02112-0530B ·CUSHION 6
3 37400-29G11 BOLT 2
4 02112-0525B BAND, SEAT GRIP (BLACK) 1 E2, E4, E21, E71, P9
ROD ASSY, REAR BRAKE GN125V E1
5 02112-0545B ROD ASSY, REAR BRAKE 1
6 37200-38G30 ·WASHER 1
7 02112-0530B ·SPRING 1
8 37400-29G11 ·PIN 1
9 02112-0525B ·NUT 1
10 02112-0545B ·PIN 1
11 02112-0525B ·WASHER 1
12 02112-0545B ·COTTER PIN 1

GN125X E2
FIG.38
FIG.38 FRONT DAMPER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
51103-05301 DAMPER ASSY, FRONT FORK RH 1 FOR CWH
51104-05301 DAMPER ASSY, FRONT FORK LH 1 FOR YVB, JRU
1 51130-05300 ·TUBE, OUTER RH 1
2 41100-44H01-YKY ·TUBE, OUTER LH 1 FOR CWH
3 51153-05300 ·OIL SEAL 2 FOR YVB, JRU
4 51156-41603 ·RING, STOPPER 2
5 51148-41310 ·GASKET 2 FOR CWH
6 51147-16510 ·BOLT 2 FOR YVB, JRU
7 51173-41603 ·DUST SEAL 2
8 51195-36220 ·PIECE, OIL LOCK 2 FOR CWH
9 51146-05300 ·CYLINDER 2 FOR YVB, JRU
10 51110-05300 ·TUBE, INNER 2
11 51171-05300 ·SPRING 2 FOR CWH
12 51172-18630 ·GUIDE, SPRING 2 FOR YVB, JRU
13 51176-05300 ·SPACER 2
14 51181-29400 ·O RING 2 FOR CWH
15 51351-41603 ·CAP 2 FOR YVB, JRU

GN125X E2
FIG.39
FIG.39 FRAME
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1-1 51410-11311 STEM, STEERING 1
1-2 51410-053B0 STEM, STEERING 1 E18, E22
2 51621-33001 ·RACE, OUTER 1
3 51311-11300-291 HEAD, STEERING STEM (BLACK) 1
4 51356-22012 WASHER 1
5 51351-29400 BOLT 1
6 56211-29320-291 HOLDER, HANDLE (BLACK) 2
7 01254-08357 BOLT 4
8 01500-10407 BOLT 2
9 08321-01107 LOCK WASHER 2
10 51451-28012 BOLT 2
11 08321-01127 LOCK WASHER 2
12 51530-05300 BRACKET, HEADLAMP RH 1
13 51540-05300 SRACKET, HEADLAMP LH 1
14 51553-11300 CUSHION, BRACKET 4
15 51871-05301 COVER, STEERING STEM 1
16 66211-38300 EMBLEM, COVER 1
17 51631-28000 NUT, STEERING STEM 1
18 51643-25001 DUST SEAL 1
19 51621-28000 RACE, OUTER UPPER 1
20 51611-20002 RACE, INNER UPPER 1
21 51611-33002 RACE, INNER LOWER 1
22 06111-06003 STEEL BALL, UPPER 22
23 06111-08003 STEEL BALL, LOWER 18
24 51910-25311 LOCK ASSY, STEERING 1 E1, E2, E4, E21, E30, E71, P9
25 02112-35123 SCREW 2 E1, E2, E4, E21, E30, E71, P9
26-1 51900-30901 LOCK ASSY, STEERING 1 E18
(NEIMAN)
26-2 51900-30901 LOCK ASSY, STEERING 1 E22
(NEIMAN) PURCHASE LOCALLY

GN125X E2
FIG.40
FIG.40 FRONT WHEEL (GN125V/W/X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 54111-36210 HUB, FRONT 1
2 08123-63017 BEARING 2
3 09180-12144 SPACER (12,5X19X52) 1
4-1 54711 -4 1101 AXLE, FRONT 1 MODEL V/W E1, E2, E4, E2 I
4-2 54 711-05300 AXLE, FRONT 1 E18, E22
4-3 54711-05300 AXLE, FRONT 1 MODEL X
E2, E4, E21, E71, P9
5 54740-11300 SPACER, FRONT AXLE LH 1
6 08322-01127 WASHER 1 MODEL V/W E1, E2, E4 , E21
7 09141-12003 NUT 1 MODEL V/W E1, E2, E4 , E21
8 04111-30308 COTTER PIN 1 MODEL V/W E1, E2, E4 , E21
9 54600-36400 BOX ASSY, SPEEDOMETER GEAR 1
10 59211-13001 DISK, FRONT BRAKE 1
11 09100-08140 BOLT (8X28) 4
12 09169-08019 WASHER 2
13 55100-12B00 TIRE, FRONT, 2.75 -18 IRC 1
14 55200-11601 TUBE, WHEEL INNER 1
15 55261-11010 PROTECTOR, INNER TUBE 1
16 55311-18420 RIM, WHEEL CI.6OX18) 1
17 55320-36221 SPOKE SET, FRONT WHEEL 1
18-1 08319-31128 NUT 1 E 18, E22
18-2 08319-31128 NUT 1 MODEL X
E2, E4, E21,. E71, P9

REFER TO FIG. 40A (H 6) FOR GN125EV/EW/EX

GN125X E2
FIG.41
FIG.41 FRONT CALIPER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
59300-04712 CALIPER ASSY, FRONT LH 1
1 59300-04850 ·PISTON SET 1
2 59300-04860 ··SEAL SET , PISTON 1
3 59300-04831 ·PAD SET 1
4 59350-36501 ·CARRIER, LH 1
5 59312-36500 ·BOOT 1
6 59313-36500 ·INSULATOR 1
7 59315-36500 ·SPRING 1
8 59121-18410 ·BLEEDER 1
9 55156-66310 ·CAP 1
10 02112-75123 ·SCREW 1
11 01550-08303 BOLT 2
12 59313-15001 PROTECTOR, CALIPER 1

GN125X E2
FIG.42
FIG.42 FUEL TANK
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 59600-05360 CYLINDER ASSY, FRONT MASTER 1 FOR YVB, JRU
2 59600-04810 ·PISTON/CUP SET 1
3 59667-36500 ·DIAPHRAGM 1
4 59669-36510 ·CAP, RESERVOIR 1
5 59691-36500 ·SCREW, RESERVOIR 2
6 59671-05300 ·HOLDER 1
7 59675-19C00 ·BOLT 2
8 09360-10039 BOLT (10X1.00X22) 2
9 09161-10009 WASHER 4
10 59480-05350 HOSE, BRAKE 1
11 59246-39100 CLAMP, BRAKE HOSE 1
12 59268-11300 CLAMP, BRAKE HOSE 1
13 01570-06123 BOLT 1

GN125X E2
FIG.43
FIG.43 (H-8) REAR SWINGING ARM
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 61000-05300-019 SWINGING ARM ASSY,REAR 1
(BLACK)
2 61261-05301 ·BUSH 2
3 61251-05300 SPACER, ARM PIVOT 2
4 09286-20001 OIL SEAL (20X27X5) 2
5 08211-14341 WASHER 2
6 61262-45002 COVER, ARM PIVOT 2
7 08322-01143 WASHER 1
8 08319-21148 NUT 1
9 61211-05302 SHAFT, PIVOT 1
10 09320-08020 CUSHION 1
11 61273-05300 BUFFER, CHAIN TOUCH DEFENSE 1
12 64310-05300-019 TORQUE LINK , REAR (BLACK ) 1
13 09111-08012 BOLT, FRONT (8X22 5) 1
14 09111-08013 BOLT, REAR (8X26 5) 1
15 09162-08008 LOCK WASHER 2
16 09140-08008 NUT 2
17 04111-20208 COTTER PIN 2

GN125X E2
FIG.44
FIG.44 (H-9) REAR SHOCK ABSOBER
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 61310-05301 CASE, CHAIN 1
2 02112-36163 SCREW, FRONT 1
3 09160-06077 WASHER 1
4 09180-06259 SPACER 1
5 09320-08021 CUSHION 1
6 02112-36163 SCREW, REAR 1
7 62100-05330 ABSORBER ASSY, REAR SHOCK 2
8-1 09160-10127 WASHER, UPPER (10,5X24X2.30) 2 E2, E4, E21,E71, P9
GN125V E1
8-2 09160-10127 WASHER, UPPER (10,5X24X2.30) 4 E18, E22, E30
GN125EV E1
9 09160-12090 WASHER, INNER (12.5X26X1.60) 4
10 09160-10127 WASHER, LOWER (10,5X24X2.30) 1
11 08313-10107 NUT 4

GN125X E2
FIG.45
FIG.45 (H-10) REAR WHEEL (GN125V/W/X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
1 64110-07005 HUB, REAR WHEEL 1
2 64210-39115 PANEL, REAR BRAKE ANCHOR 1
3 54400-07870 SHOE SET, BRAKE 1
4 09443-07001 SPRING 2
5 54441-29305 CAM, BRAKE(BLUE) 1
6 09280-14011 O RING (D:2.50. ID:13.8) 1
7 09160-14055 WASHER (14.5X22X1.6) 1
8 64451-48000 LEVER, BRAKE CAM 1
9 01550-06353 BOLT 1
10 08316-10063 NUT 1
11 64610-05301 DRUM, SPROCKET MOUNTING 1
12 64651-07001 SHOCK ABSORBER, HUB 1
13 64733-05301 RETAINER, MOUNTING 1
14-1 64711-48001 AXLE, REAR 1 MODEL V/W E1, E2, E4, E21
14-2 64711-05310 AXLE, REAR 1 E18, E22
14-3 64711-05310 AXLE, REAR 1 MODEL X
E2, E4, E21, E71, P9
15 08322-01143 WASHER 1 MODEL V/W E1, E2, E4, E21
16 09180-15042 SPACER, LH (15.2X23X33) 1
17 09141-14001 NUT 1 MODEL V/W E1, E2, E4, E21
18 09180-15002 SPACER, RH (15.2X23X33) 1
19 09180-15011 SPACER, HUB SEARING 1
(15.3X21,7X63)
20 08144-63027 BEARING, RH 1
21 08143-62027 BEARING, LH 1
22 09285-28001 OIL SEAL (28X47X7) 1
23 09262-20069 BEARING (20X47X14) 1
24 04111-30308 COTTER PIN 1 MODEL V/W E1, E2, E4, E21
25 61410-36002 ADJUSTER, CHAIN 2
26 09104-08034 BOLT (8X50) 2
27 08310-00087 NUT 2

REFER TO FIG.45A (J-8) FOR GN125EV/EW/EX

GN125X E2
FIG.45
FIG.45 (H-10) REAR WHEEL (GN125V/W/X)
Q'TY
REF NO. PART NO. DESCRIPTION REMARKS
28-1 64511-12B02 SPROCKET, REAR (NT:42 ) 1 E1, E2, E21,E71, P9
28-2 64511-12B11 SPROCKET, REAR (NT.41) 1 E4, E22
29 09119-08043 BOLT (8X33) 4
30 09169-08012 WASHER 2
31 08310-00083 NUT 4
32 65100-05320 TIRE, REAR.3.50-16 IRC 1
33 65200-26700 TUSE ASSY, WHEEL INNER 1
34 65261-37300 PROTECTOR, INNER TUBE 1
35 65311-05300 RIM, WHEEL (1.85 -16) 1
36 65320-38301 SPOKE SET, REAR WHEEL 1
37-1 08322-01143 WASHER 1 E18, E22
37-2 08322-01143 WASHER 1 MODEL X
1 E2, E4, E21, E71, P9
38-1 09159-14008 NUT 1 E18, E22
38-2 09159-14008 NUT 1 MODEL X
E2, E4, E21, E71, P9

REFER TO FIG. 45A (J-8) FOR GN125EV/EW/EX

GN125X E2
PARTS NUMBER INDEX
 PART NO. FIG.NO. - REF.NO.
10000
11100-05263.......................... 1 - 1
11115-05270.......................... 1 - 2
11141-05201.......................... 1 - 7
11151-45000.......................... 1 - 10
11175-18900.......................... 1 - 16-2
11175-37111............................1- 16-1
11210-05202-0F0................... 2 - 1
11241-05311.......................... 2 - 6
11319-05200.......................... 3 - 6
11340-05303.......................... 4 - 1
11351-05302.......................... 4 - 11
11361-05301.......................... 4 - 22
11365 05502.......................... 3 - 11
11401-05862.......................... 1 - 30
11401-05863.......................... 1 - 30
11462-05311.......................... 4 - 3
11483-05311.......................... 4 - 12-1
11483-05312.......................... 4 - 12-2
11971-45010.......................... 4 - 2
12100-05200-050................... 5 - 18-1
12105-05821.......................... 5 - 2
12111-05202.......................... 5 - 14
12140-01410.......................... 5 - 15
12151-05220.......................... 5 - 16
12200-05340.......................... 5 - 1
12221-05210.......................... 5 - 4
12261-05301.......................... 5 - 5
12600-05874.......................... 6 - 4
12611-05300.......................... 6 - 1
12633-05300.......................... 6 - 7
12649-05300.......................... 6 - 10
12711-05201.......................... 7 - 1
12741-05201.......................... 7 - 2
12747-05201.......................... 7 - 4
12760-44A00.......................... 8 - 1
12771-05200.......................... 8 - 2
12811-05220.......................... 8 - 3
12812-32400.......................... 8 - 4
12830-32452.......................... 8 - 6
12837-32410.......................... 8 - 11
12838-45001.......................... 8 - 8
12842-32411.......................... 7 - 8
12843-32400.......................... 7 - 9
12850-25C00.......................... 7 - 7
GN125X E2
PART NO. FIG.NO. - REF.NO.
12861-05201.......................... 7 - 10
12911-94B00.......................... 7 - 15
12912-24400.......................... 7 - 16
12920-05210.......................... 7 - 17
12920-05240.......................... 7 - 18
12931-49200.......................... 7 - 19
12932-24400.......................... 7 - 20
12933-49201.......................... 7 - 21
1300-05303 .......................... 3 - 1-1
1300-05340 .......................... 3 - 1-2
13110-05300.......................... 1 - 24-1
13110-05370.......................... 1 - 24-2
13200-05302.......................... 9 - 1
13200-05302.......................... 9 - 1
13200-05313.......................... 9 - 1
13200-05313.......................... 9 - 1
13200-053D0.......................... 9 - 1
13200-05500.......................... 9 - 1
13200-05510.......................... 9 - 1
13200-05540.......................... 9 - 1
13246-44080.......................... 9 - 16
13247-44080.......................... 9 - 17
13250-05300.......................... 9 - 22
13251-05400.......................... 9 - 27
13254-92311.......................... 9 - 23
13261-05A00.......................... 9 - 48-1
13266-47070.......................... 9 - 47
13268-37420.......................... 9 - 41
13279-45400.......................... 9 - 44-1
13279-45400.......................... 9 - 44-2
13279-45400.......................... 9 - 44-3
13279-45400.......................... 9 - 44-4
13279-45400.......................... 9 - 44-5
13291-29900.......................... 9 - 46
13295-29900.......................... 9 - 45
13357-36A00.......................... 9 - 48-2
13357-44080.......................... 9 - 15
13370-44500.......................... 9 - 24
13373-11400.......................... 9 - 20-1
13373-11400.......................... 9 - 20-3
13373-39110.......................... 9 - 20-4
13374-44080.......................... 9 - 25
13376-84110.......................... 9 - 26
13382-03110.......................... 9 - 19
13382-44030.......................... 9 - 30
13383-05300.......................... 9 - 13-2
13383-05310.......................... 9 - 13-1
13387-47010.......................... 9 - 32
13388-44030.......................... 9 - 29
13389-37400.......................... 9 - 5
PART NO. FIG.NO. - REF.NO.
13394-10010.......................... 9 - 31
13410-05300.......................... 9 - 8-1
13410-05500.......................... 9 - 8-2
13422-05300.......................... 9 - 38
13426-43010.......................... 9 - 34
13431-05300.......................... 9 - 6
13433-33110.......................... 9 - 33-2
13438-33110.......................... 9 - 33-1
13500-053D0.......................... 9 - 28
13502-33210.......................... 9 - 3
13503-05350.......................... 9 - 2-2
13503-33200.......................... 9 - 2-1
13557-47070.......................... 9 - 10
13560-05500.......................... 9 - 49
13601-04148.......................... 9 - 43-1
13601-45C00.......................... 9 - 43-2
13602-55A00.......................... 9 - 50
13605-31210.......................... 9 - 39
13615-43010.......................... 9 - 35
13617-44080.......................... 9 - 11
13650-05360.......................... 10 - 6-2
13651-51010.......................... 9 - 9
13881-05300.......................... 10 - 4
13670-21308.......................... 10 - 8
13700-05302.......................... 10 - 1-1
13700-05360.......................... 10 - 1-2
13780-36301.......................... 10 - 2
13826-38300.......................... 10 - 5
13853-05300.......................... 10 - 6-1
14181-18C00.......................... 11 - 1
14305-05313.......................... 11 - 2-2
14305-05313.......................... 11 - 2-5
14305-053A0.......................... 11 - 2-1
14305-053A0.......................... 11 - 2-4
14305-053B0.......................... 11 - 2-3
15267-25D00.......................... 9 - 42
15373-39110.......................... 9 - 20-2
16321-05201.......................... 5 - 9
16331-05200.......................... 12 - 2
16400-05201.......................... 12 - 1
16510-05240.......................... 12 - 13
16512-05212.......................... 12 - 15
16520-05202.......................... 12 - 6
16523-05200.......................... 12 - 8
-1 -
PART NO. FIG.NO. - REF.NO.
20000
21111-05200.......................... 5 - 10
21200-05880.......................... 13 - 1
21411-05200.......................... 13 - 3
21441-13A01.......................... 13 - 7
21451-19A00.......................... 13 - 8
21462-14102.......................... 13 - 9
23110-05202.......................... 13 - 12
23121-38201.......................... 13 - 13
23122-05200.......................... 13 - 14
23271-46010.......................... 13 - 21
24120-05810.......................... 14 - 1
24125-36201.......................... 14 - 2
24130-05300.......................... 14 - 11-1
24130-05310.......................... 14 - 11-2
24221-05301.......................... 14 - 3
24231-05203.......................... 14 - 4
24251-05203.......................... 14 - 5
24311-05201.......................... 14 - 12
24320-05202.......................... 14 - 15
24331-05203.......................... 14 - 17
24341-05201.......................... 14 - 19-1
24341-05203.......................... 14 - 19-2
24351-05201.......................... 14 - 20-1
24351-05202.......................... 14 - 20-2
24359-05200.......................... 14 - 21
24421-05300.......................... 14 - 22
24741-05200.......................... 14 - 25
24741-05200.......................... 14 - 9
24751-05201.......................... 14 - 28-1
24751-05210.......................... 14 - 28-2
25221-08300.......................... 15 - 1
25231-05201.......................... 15 - 2
25310-05300.......................... 15 - 5
25322-31310.......................... 15 - 7
25323-34201.......................... 15 - 8
25324-34201.......................... 15 - 9
25331-30001.......................... 15 - 12
25341-05200.......................... 15 - 14
25350-44A00.......................... 15 - 16
25351-30010.......................... 15 - 22
25381-45400.......................... 15 - 23
25411-16701.......................... 15 - 3
25421-35403.......................... 15 - 4
25510-05201.......................... 15 - 27
25600-05320.......................... 15 - 33
PART NO. FIG.NO. - REF.NO.
25652-16500.......................... 15 - 34
25671-01000.......................... 15 - 30
26431-05201.......................... 1 - 19
26441-49000.......................... 1 - 20
26451-45000.......................... 1 - 21
27510-41730.......................... 14 - 32A
27511-41310.......................... 14 - 32
27531-05200.......................... 14 - 33
27600-29B20.......................... 14 - 37
27620-40220.......................... 14 - 38
30000
31100-05501.......................... 16 - 1
31130-32C20.......................... 16 - 5
31132-32C10.......................... 16 - 4
31133-32C10.......................... 16 - 6
31135-32C10.......................... 16 - 8
31150-06C00.......................... 16 - 14
31156-38300.......................... 16 - 10
31175-42A01.......................... 16 - 3
31264-32C10.......................... 16 - 11
31281-32C10.......................... 16 - 9
31310-11D00.......................... 16 - 2
31361-32C10.......................... 16 - 13
31361-38300.......................... 16 - 12
31800-49100.......................... 19 - 1
31861-10D00.......................... 18 - 7
31861-31500.......................... 19 - 5
32101-05300.......................... 17 - 1
32102-05300.......................... 17 - 2
32800-29B00.......................... 19 - 6
32900-05300.......................... 19 - 8
32900-05330.......................... 19 - 9-1
32900-05340.......................... 19 - 9-2
32931-053A0.......................... 19 - 10
32980-05300.......................... 19 - 11
33410-05350.......................... 19 - 13
33510-22010.......................... 19 - 15
33541-24510.......................... 19 - 16
33542-38B00.......................... 19 - 17
33610-10310.......................... 18 - 1
33624-43500.......................... 18 - 8
33651-37000.......................... 18 - 2
33652-28000.......................... 18 - 3
33680-16A10.......................... 18 - 4
33690-05360.......................... 18 - 10
33820-053A0.......................... 18 - 6
PART NO. FIG.NO. - REF.NO.
33850-05301.......................... 19 - 4
33860-05550.......................... 18 - 9
34110-05300.......................... 20 - 1-2
34110-05310.......................... 20 - 1-1
34173-05300.......................... 20 - 3
34187-28310.......................... 20 - 11
34189-28310.......................... 20 - 12
34193-05300.......................... 20 - 7
34210-05320.......................... 20 - 2
34273-05320.......................... 20 - 4
34293-05300.......................... 20 - 8
34910-05310.......................... 20 - 16
34940-05300.......................... 20 - 17
34950-05300.......................... 20 - 6
34956-28011.......................... 20 - 9
35100-44270.......................... 21 - 1
35111-37350.......................... 21 - 2
35121-44270.......................... 21 - 3
35171-44270.......................... 21 - 5
35172-33630.......................... 21 - 8
35601-39370-999....................22 - 1
35603-26420-999....................22 - 12-1
35603-39380.......................... 22 - 12-2
35612-02460.......................... 22 - 2
35613-28620.......................... 22 - 14
35613-28620.......................... 22 - 3
35621-36300.......................... 22 - 23-1
35627-43010.......................... 22 - 16
35627-43010.......................... 22 - 5
35641-38300.......................... 22 - 23-2
35652-02470.......................... 22 - 13
35690-32200.......................... 22 - 8
35695-36590.......................... 22 - 18
35695-36590.......................... 22 - 7
35712-48624.......................... 23 - 2
35713-30510.......................... 23 - 3
35720-05311-999....................23 - 1
35730-26470.......................... 23 - 9
35764-26470.......................... 23 - 12
35765-26470.......................... 23 - 11
35766-26470.......................... 23 - 10
36118-30500.......................... 21 - 7
36610-053F0.......................... 24 - 1-2
36610-053G1.......................... 24 - 1-1
36619-37300.......................... 24 - 4
36651-05301.......................... 24 - 5
36660-33000.......................... 22 - 11
36791-46700.......................... 24 - 12
36852-05300.......................... 24 - 11
36862-44000.......................... 22 - 22
 PART NO. FIG.NO. - REF.NO.
37110-33021.......................... 24 - 6
37145-19710.......................... 24 - 13
37200-38G30.......................... 37 - 1
37200-38G30.......................... 37 - 6
37200-45C03.......................... 25 - 1-1
37200-45C12.......................... 25 - 1-2
37400-06B12.......................... 25 - 3
37400-29G11.......................... 37 - 3
37400-29G11.......................... 37 - 8
37640-11X50.......................... 24 - 16
37720-44700.......................... 15 - 35-2
37720-47D00.......................... 15 - 35-1
37730-05300.......................... 15 - 35B
37730-05310.......................... 15 - 35A
37740-31D00.......................... 24 - 7
37841-14D00.......................... 24 - 17
38500-38361.......................... 24 - 9-1
38500-38390.......................... 24 - 9-2
38610-06F00.......................... 22 - 24-3
38610-31X50.......................... 22 - 24-1
38610-45091.......................... 22 - 24-2
38740-24X50.......................... 24 - 14
38741-05300.......................... 24 - 15
40000
4100-383B0-3EX ....................30 - 1-7
41100-053E0-019....................26 - 1-1
41100-053F0-019....................26 - 1-2
41100-44H01-YKY...................38 - 2
41540-38301.......................... 26 - 8
41991-05300.......................... 26 - 2
41992-05300.......................... 26 - 5
42100-05303.......................... 27 - 1
42211-36504.......................... 27 - 2
42310-053E0.......................... 27 - 8
43110-05301.......................... 27 - 13
43231-05302.......................... 27 - 15
43261-17C00.......................... 27 - 20
43510-05330.......................... 28 - 1
43520-05330.......................... 28 - 2
43550-37301.......................... 28 - 3
43560-37301.......................... 28 - 4
43600-05301.......................... 28 - 9
43610-03001.......................... 28 - 11
43612-33200.......................... 28 - 12
GN125X 32
PART NO. FIG.NO. - REF.NO.
43700-05301.......................... 28 - 10
44100-383A0-2AX.................. 30 - 1-2
44100-383A0-2HX.................. 30 - 1-1
44100-383A0-3EX.................. 30 - 1-3
44100-383A0-Y4H.................. 30 - 1-4
44100-383B0-2AX.................. 30 - 1-6
44100-383B0-Y4H.................. 30 - 1-8
44100-383BO-2HX................. 30 - 1-5
44200-30830.......................... 30 - 5
44300-22075.......................... 31 - 1-1
44300-22080.......................... 31 - 1-2
44343-41370.......................... 31 - 7
44346-28070.......................... 31 - 2
44346-28070.......................... 31 - 4
44347-28071.......................... 31 - 3
44353-12C01.......................... 31 - 5
44357-32470.......................... 31 - 6
44541-05300.......................... 30 - 7
44542-38300.......................... 30 - 8
46210-05300.......................... 29 - 1
46300 05860.......................... 29 - 5
46310-05300.......................... 29 - 4
47111-05301-19A................... 32 - 1-1
47111-05301-33J.....................32 - 1-2
47111-05301-Y4H................... 32 - 1-4
47111-05301-Y98....................32 - 1-3
47211-05301-19A.................... 32 - 2-1
47211-05301-33J.................... 32 - 2-2
47211-05301-Y4H................... 32 - 2-4
47211-05301-Y98....................32 - 2-3
47431-05300.......................... 26 - 13
47432-05300.......................... 26 - 14
47440-05301.......................... 26 - 15
50000
51103-05301.......................... 38 - 5
51104-05301.......................... 38 - 5
51110-05300.......................... 38 - 10
51130-05300.......................... 38 - 1
51146-05300.......................... 38 - 9
51147-16510.......................... 38 - 6
51148-41310.......................... 38 - 5
51153-05300.......................... 38 - 3
51156-41603.......................... 38 - 4
51171-05300.......................... 38 - 11
PART NO. FIG.NO. - REF.NO.
51172-18630.......................... 38 - 12
51173-41603.......................... 38 - 7
51176-05300.......................... 38 - 13
51181-29400.......................... 38 - 14
51195-36220.......................... 38 - 8
51311-11300-291.................... 39 - 3
51351-29400.......................... 39 - 5
51351-41603.......................... 38 - 15
51356-22012.......................... 39 - 4
51410-053B0.......................... 39 - 1-2
51410-11311.......................... 39 - 1-1
51451-28012.......................... 39 - 10
51530-05300.......................... 39 - 12
51540-05300.......................... 39 - 13
51553-11300.......................... 39 - 14
51611-20002.......................... 39 - 20
51611-33002.......................... 39 - 21
51621-28000.......................... 39 - 19
51621-33001.......................... 39 - 2
51631-28000.......................... 39 - 17
51643-25001.......................... 39 - 18
51810-44201.......................... 33 - 3
51821-36200.......................... 33 - 5
51827-27302.......................... 33 - 6
51871-05301.......................... 39 - 15
51900-30901.......................... 39 - 26
51900-30901.......................... 39 - 26
51910-25311.......................... 39 - 24
53110-05301.......................... 33 - 1
54 711-0530.......................... .40 - 4-2
54111-36210.......................... 40 - 1
54400-07870.......................... 45 - 3
54441-29305.......................... 45 - 5
54600-36400.......................... 40 - 9
54711-05300.......................... 40 - 4-3
54711-41101.......................... 40 - 4-1
54740-11300.......................... 40 - 5
55100-12B00.......................... 40 - 13
55156-66310.......................... 41 - 9
55200-11601.......................... 40 - 14
55261-11010.......................... 40 - 15
55311-18420.......................... 40 - 16
55320-36221.......................... 40 - 17
56110-05321.......................... 34 - 1
56115-05300.......................... 35 - 2
56170-05300.......................... 34 - 6
56211-29320-291.................... 39 - 6
56500-28601.......................... 34 - 5
56500-44200.......................... 34 - 2
56500-45640.......................... 34 - 4
-2 -
PART NO. FIG.NO. - REF.NO.
56600-44200.......................... 34 - 3
57110-34300.......................... 35 - 1
57211-34300.......................... 35 - 8
57421-13001.......................... 35 - 3
57431-13030.......................... 35 - 4
57431-45C00.......................... 35 - 11
57433-09F00.......................... 35 - 12
57441-45C00.......................... 35 - 14
57442-45C00.......................... 35 - 15
57460-17C00.......................... 35 - 6
57465-17C00.......................... 35 - 7
57500-05390.......................... 35 - 9
57560-05A00.......................... 35 - 16
57620-05390.......................... 35 - 10
57661-31000.......................... 35 - 18
58200-05391.......................... 34 - 7
58273-31000.......................... 35 - 19
58285-05351.......................... 34 - 12
58300-05320.......................... 15
58621-21203.......................... 20 - 18
58626-37400.......................... 34 - 10
59121-18410.......................... 41 - 8
59211-13001.......................... 40 - 10
59246-39100.......................... 42 - 11
59268-11300.......................... 42 - 12
59300-04712.......................... 41 - 5
59300-04831.......................... 41 - 3
59300-04850.......................... 41 - 1
59300-04860.......................... 41 - 2
59312-36500.......................... 41 - 5
59313-15001.......................... 41 - 12
59313-36500.......................... 41 - 6
59315-36500.......................... 41 - 7
59350-36501.......................... 41 - 4
59480-05350.......................... 42 - 10
59600-04810.......................... 42 - 2
59600-05360.......................... 42 - 1
59667-36500.......................... 42 - 3
59669-36510.......................... 42 - 4
59671-05300.......................... 42 - 6
59675-19C00.......................... 42 - 7
59691-36500.......................... 42 - 5
PART NO. FIG.NO. - REF.NO.
60000
61000-05300-019....................43 - 1
61211-05302............................43 - 9
61251-05300.......................... 43 - 3
61261-05301.......................... 43 - 2
61262-45002.......................... 43 - 6
61273-05300.......................... 43 - 11
61310-05301.......................... 44 - 1
61410-36002.......................... 45 - 25
62100-05330.......................... 44 - 7
63110-38302.......................... 36 - 2-5
63110-38302.......................... 36 - 2-8
63110-38303.......................... 36 - 2-6
63110-38312.......................... 36 - 2-1
63110-38312.......................... 36 - 2-7
63110-38313.......................... 36 - 2-2
63110-38322.......................... 36 - 2-3
63110-38323.......................... 36 - 2-4
63112-05302.......................... 36 - 1
64110-07005.......................... 45 - 1
64210-39115.......................... 45 - 2
64310-05300-019................... 43 - 12
64451-48000.......................... 45 - 8
64511-12B02.......................... 45 - 28-1
64511-12B11.......................... 45 - 28-2
64610-05301.......................... 45 - 11
64651-07001.......................... 45 - 12
64711-05310.......................... 45 - 14-2
64711-05310.......................... 45 - 14-3
64711-48001.......................... 45 - 14-1
64733-05301.......................... 45 - 13
65100-05320.......................... 45 - 32
65200-26700.......................... 45 - 33
65261-37300.......................... 45 - 34
65311-05300.......................... 45 - 35
65320-38301.......................... 45 - 36
66131-05310.......................... 32 - 4
66211-38300.......................... 39 - 16
66319-33E00.......................... 36 - 7-1
66319-33E20.......................... 36 - 7-3
66319-33E40.......................... 36 - 7-4
66319-33E50.......................... 36 - 7-5
66332-05320.......................... 36 - 8-1
68110-38340-L7Z....................30 - 2-1
68110-38340-L8A................... 30 - 2-2
68111-37300.......................... 30 - 3
PART NO. FIG.NO. - REF.NO.
68135-38300-L7Z....................32 - 3-1
68135-38300-L8A................... 32 - 3-2
68319-33E30.......................... 36 - 7-2
68332-05350.......................... 36 - 8-2
68391-44AD0.......................... 29 - 6
68623-17D00.......................... 36 - 9
90000
94631-33C01.......................... 33 - 7
9481-15001 ............................24 - 1A
95700-37810.......................... 29 - 2
99011-05351-GDU..................36 - 10-1
99011-05352-GDU..................36 - 10-2
99011-05353-DGS..................36 - 10-3
00000
01547-06203.......................... 12 - 10
09443-12025.......................... 27 - 10
01254-08357.......................... 39 - 7
01264-08207.......................... 33 - 4
01421-06128.......................... 12 - 18
01421-06257.......................... 2 - 4
01421-06858.......................... 12 - 19
01500-06103.......................... 14 - 29
01500-06103.......................... 3 - 7
01500-06167.......................... 13 - 22
01500-06203.......................... 15 - 32
01500-06203.......................... 8 - 12
01500-10407.......................... 39 - 8
01547-05257.......................... 4 - 24
01547-05357.......................... 4 - 23
01547-06203.......................... 35 - 13
01547-06307.......................... 16 - 16
01547-06307.......................... 4 - 14
01547-06307.......................... 4 - 5
01547-06357.......................... 4 - 15
 PART NO. FIG.NO. - REF.NO.
01547-06407.......................... 4 - 16
01547-06457.......................... 4 - 6
01547-06507.......................... 4 - 17
01547-06557.......................... 3 - 3
01547-06607.......................... 3 - 4
01547-06757.......................... 3 - 5
01550-06163.......................... 20 - 15
01550-06203.......................... 24 - 18
01550-06257.......................... 7 - 14
01550-06353.......................... 45 - 9
01550-06357.......................... 1 - 5
01550-06607.......................... 1 - 6
01550-08163.......................... 24 - 10
01550-08303.......................... 41 - 11
01550-08657.......................... 26 - 6
01550-10253.......................... 28 - 18
01550-10453.......................... 28 - 16
01550-12257.......................... 28 - 5
01560-06163.......................... 10 - 11
01560-06163.......................... 10 - 12
01560-06163.......................... 36 - 3
01560-08257.......................... 36 - 5
01570-06123.......................... 42 - 13
01570-08163.......................... 33 - 2
02112-03063.......................... 9 - 4-2
02112-04063.......................... 9 - 21
02112-05087.......................... 9 - 37
02112-05127.......................... 23 - 6
02112-05163.......................... 34 - 13
02112-05253.......................... 17 - 3
02112-0525B.......................... 37 - 11
02112-0525B.......................... 37 - 4
02112-0525B.......................... 37 - 9
02112-0530B.......................... 37 - 2
02112-0530B.......................... 37 - 7
02112-05453.......................... 25 - 2
02112-05453.......................... 25 - 4
02112-0545B.......................... 37 - 10
02112-0545B.......................... 37 - 12
02112-0545B.......................... 37 - 5
02112-06253.......................... 12 - 5
02112-16103.......................... 34 - 11
02112-33083.......................... 9 - 4-1
02112-34123.......................... 16 - 7
02112-35123.......................... 39 - 25
02112-36163.......................... 1 - 26-1
02112-36163.......................... 44 - 2
02112-36163.......................... 44 - 6
02112-75123.......................... 12 - 7
02112-75123.......................... 41 - 10
GN125X E2
PART NO. FIG.NO. - REF.NO.
02112-75203.......................... 15 - 37
02122-03063.......................... 30 - 4
02122-03208.......................... 35 - 17
02122-05127.......................... 21 - 9
02122-06123.......................... 14 - 10
02122-06123.......................... 14 - 26
02122-06123.......................... 15 - 13
02122-06123.......................... 15 - 15
02142-04123.......................... 17 - 4
02142-05087.......................... 21 - 11
02142-05103.......................... 19 - 14
02142-05127.......................... 10 - 10
02142-05203.......................... 15 - 37B
02142-06103.......................... 13 - 23
02142-06163.......................... 10 - 12
03211-04208.......................... 22 - 15
03211-04208.......................... 22 - 4
04111-20158.......................... 28 - 15
04111-20158.......................... 34 - 9
04111-20208.......................... 27 - 17
04111-20208.......................... 28 - 7
04111-20208.......................... 43 - 17
04111-30308.......................... 27 - 3
04111-30308.......................... 40 - 8
04111-30308.......................... 45 - 24
04211-09129.......................... 4 - 13
04211-11149.......................... 2 - 7
04211-11169.......................... 1 - 8
04211-13169.......................... 4 - 4
04211-13189.......................... 3 - 2
04221-04069.......................... 15 - 24
06111-06003.......................... 39 - 22
06111-08003.......................... 39 - 23
06123-60027.......................... 14 - 8
06211-06141.......................... 15 - 18
06211-15251.......................... 14 - 13
06316-10083.......................... 36 - 6
06316-10103.......................... 17 - 5
06331-31156.......................... 14 - 31
06341-31039.......................... 17 - 6
07130-06163.......................... 6 - 9
07130-08253.......................... 11 - 3
08123-63017.......................... 40 - 2
08143-62027.......................... 45 - 21
08144-63027.......................... 45 - 20
08211-14341.......................... 43 - 5
08211-20352.......................... 13 - 6
08211-20353.......................... 13 - 2
08310-00053.......................... 34 - 14
08310-00057.......................... 23 - 7
PART NO. FIG.NO. - REF.NO.
08310-00063.......................... 23 - 14
08310-00063.......................... 27 - 19
08310-00083.......................... 45 - 31
08310-00087.......................... 45 - 27
08310-00107.......................... 22 - 10
08310-00107.......................... 22 - 21
08313-10057.......................... 20 - 14
08313-10067.......................... 12 - 20
08313-10107.......................... 44 - 11
08316-10063.......................... 19 - 12
08316-10063.......................... 26 - 19
08316-10063.......................... 45 - 10
08316-10067.......................... 2 - 5
08316-10083.......................... 1 - 11
08316-10083.......................... 8 - 9
08316-10103.......................... 28 - 17
08319-21063.......................... 35 - 5
08319-21103.......................... 27 - 12-2
08319-21148.......................... 43 - 8
08319-31087.......................... 1 - 29
08319-31087.......................... 26 - 4
08319-31087.......................... 26 - 7
08319-31087.......................... 3 - 10
08319-31128.......................... 40 - 18
08319-31128.......................... 40 - 18
08321-01107.......................... 39 - 9
08321-01127.......................... 39 - 11
08322-01057.......................... 23 - 8
08322-01103.......................... 11 - 4
08322-01127.......................... 40 - 6
08322-01143.......................... 43 - 7
08322-01143.......................... 45 - 15
08322-01143.......................... 45 - 37-1
08322-01143.......................... 45 - 37-2
08332-11063.......................... 12 - 4
08361-35068.......................... 19 - 3
09100-06009.......................... 27 - 18
09100-06033.......................... 30 - 12
09100-08140.......................... 40 - 11
09103-08010.......................... 3 - 9
09103-08016.......................... 3 - 8
09103-08081.......................... 1 - 28
09103-08081.......................... 26 - 3
09104-08034.......................... 45 - 26
09108-08062.......................... 2 - 2
09108-08089.......................... 2 - 3
09111-06032.......................... 7 - 5
09111-06054.......................... 15 - 17
09111-08012.......................... 43 - 13
09111-08013.......................... 43 - 14
-3 -
PART NO. FIG.NO. - REF.NO.
09111-10047.......................... 27 - 9
09116-05003.......................... 13 - 11-1
09116-05020.......................... 13 - 11-2
09116-06167.......................... 23 - 13
09116-06168.......................... 26 - 16
09116-06168.......................... 26 - 9
09116-10121.......................... 27 - 16
09119-05022.......................... 15 - 37A
09119-08043.......................... 45 - 29
09125-04002.......................... 23 - 5
09126-06057.......................... 31 - 8
09128-05101.......................... 1 - 22
09128-06004.......................... 19 - 2-1
09128-06044.......................... 19 - 2-2
09128-06057.......................... 19 - 7
09134-06010.......................... 13 - 19
09137-05004.......................... 16 - 17
09139-06014.......................... 1 - 26-2
09139-06026.......................... 3 - 12
09139-06075.......................... 29 - 3
09140-06023.......................... 13 - 20
09140-08008.......................... 43 - 16
09140-16005.......................... 13 - 4
09140-16017.......................... 14 - 35
09140-16019.......................... 5 - 11
09141-12003.......................... 40 - 7
09141-14001.......................... 45 - 17
09146-03003.......................... 32 - 5
09159-08049.......................... 1 - 12
09159-10027.......................... 27 - 12-1
09159-14008.......................... 45 - 38-1
09159-14008.......................... 45 - 38-2
09160-04015.......................... 9 - 7
09160-05013.......................... 20 - 10
09160-05024.......................... 20 - 13
09160-06054.......................... 30 - 11
09160-06077.......................... 44 - 3
09160-08053.......................... 1 - 13
09160-10006.......................... 22 - 9-1
09160-10127.......................... 44 - 10
09160-10127.......................... 44 - 8-1
09160-10127.......................... 44 - 8-2
09160-10501.......................... 22 - 20
09160-10501.......................... 22 - 9-2
09160-12068.......................... 15 - 28
09160-12090.......................... 44 - 9
09160-14055.......................... 45 - 7
09160-15045.......................... 13 - 16
09160-19006.......................... 28 - 13
09160-19023.......................... 28 - 13
PART NO. FIG.NO. - REF.NO.
09161-10009.......................... 42 - 9
09161-15111.......................... 14 - 30
09162-08008.......................... 43 - 15
09164-12021.......................... 7 - 13
09166-06024.......................... 4 - 25
09166-06026.......................... 31 - 9
09166-12002.......................... 4 - 19
09166-14002.......................... 4 - 10
09166-16012.......................... 5 - 12
09167-20006.......................... 14 - 36-2
09167-20011.......................... 14 - 18
09167-20012.......................... 14 - 36-1
09167-20030.......................... 14 - 36-3
09168-06023.......................... 1 - 9
09168-06023.......................... 7 - 12
09168-08008.......................... 8 - 5
09168-08021.......................... 1 - 14
09168-14002.......................... 12 - 12
09168-14002.......................... 15 - 26
09169-05008.......................... 21 - 10
09169-08012.......................... 45 - 30
09169-08019.......................... 40 - 12
09169-16003.......................... 13 - 5
09180-06038.......................... 26 - 10
09180-06038.......................... 26 - 17
09180-06067.......................... 30 - 10
09180-06259.......................... 44 - 4
09180-12144.......................... 40 - 3
09180-13006.......................... 6 - 3
09180-15002.......................... 45 - 18
09180-15011.......................... 45 - 19
09180-15042.......................... 45 - 16
09181-10195.......................... 13 - 15
09181-25251.......................... 15 - 6
09200-06004.......................... 34 - 8
09200-06033.......................... 28 - 14
09200-08002.......................... 28 - 6
09206-08001.......................... 1 - 4
09206-13003.......................... 6 - 2
09209-05011.......................... 15 - 38
09223-04001.......................... 15 - 21
09241-22002.......................... 1 - 18
09247-12104.......................... 4 - 18
09247-14001.......................... 12 - 11-1
09247-14001.......................... 12 - 11-4
09247-14026.......................... 12 - 11-2
09247-14026.......................... 12 - 11-3
09247-14026.......................... 12 - 11-5
09247-14026.......................... 15 - 25
09247-14026.......................... 4 - 9
PART NO. FIG.NO. - REF.NO.
09259-20007.......................... 4 - 7
09259-26011.......................... 4 - 20
09260-17003.......................... 4 - 8
09260-22008.......................... 4 - 21
09260-30001.......................... 1 - 17
09261-02008.......................... 12 - 3
09261-05003.......................... 15 - 10
09261-05005.......................... 7 - 3
09261-10003.......................... 6 - 5
09262-20069.......................... 14 - 24
09262-20069.......................... 14 - 7
09262-20069.......................... 45 - 23
09262-28014.......................... 5 - 6
09262-35038.......................... 5 - 7
09263-15003.......................... 13 - 17
09263-15023.......................... 14 - 14
09263-15024.......................... 14 - 23
09263-22031.......................... 6 - 8
09263-27010.......................... 14 - 27
09263-28027.......................... 5 - 3
09280-06005.......................... 8 - 10
09280-09005.......................... 7 - 11
09280-13004.......................... 12 - 14
09280-14011.......................... 45 - 6
09280-19005.......................... 14 - 34
09280-24003.......................... 16 - 15
09280-26003.......................... 15 - 36
09280-32006.......................... 1 - 25-1
09280-32006.......................... 1 - 25-2
09280-54001.......................... 12 - 16
09280-60005.......................... 12 - 9
09282-10012.......................... 13 - 18
09282-12009.......................... 5 - 8
09285-12002.......................... 15 - 31
09285-28001.......................... 45 - 22
09286-20001.......................... 43 - 4
09289-05002.......................... 1 - 23
09289-05015.......................... 7 - 22
09320-03004.......................... 32 - 6
09320-06504.......................... 36 - 4
09320-08018.......................... 32 - 7
09320-08020.......................... 43 - 10
09320-08021.......................... 26 - 11
09320-08021.......................... 26 - 18
09320-08021.......................... 44 - 5
09320-10022.......................... 30 - 9
09320-15004.......................... 22 - 19
09321-10001.......................... 27 - 7
09329-10016.......................... 30 - 6
09351-35653-600....................9 - 40
 PART NO. FIG.NO. - REF.NO.
09352-50823-600....................31 - 10
09352-50823-600.....................9 - 36
09360-10039.............................42 - 8
09360-20009...........................14 - 6
09380-20009...........................14 - 16
PART NO. FIG.NO. - REF.NO. PART NO. FIG.NO. - REF.NO. PART NO. FIG.NO. - REF.NO. PART NO. FIG.NO. - REF.NO. PART NO. FIG.NO. - REF.NO.
09482-00399.......................... 1 - 15-7
09491-20012.......................... 9 - 18-1
09491-29010.......................... 9 - 1-2
09491-36005.......................... 9 - 1-1
09491-97003.......................... 9 - 18-2

09381-10004...........................1 - 3 09492-17006.......................... 9 - 12-3

09381-14001.......................... 5 - 17 09492-35008.......................... 9 - 12-1
09390-22002.......................... 7 - 6 09492-35010.......................... 9 - 12-2
09401-06401.......................... 31 - 11 09494-00370.......................... 9 - 14-1
09401-13409.......................... 10 - 9 09494-00725.......................... 9 - 14-2

09401-14401.......................... 10 - 7 09800-21020.......................... 26 - 12
09402-44208.......................... 1 - 27
09402-56206.......................... 10 - 3
09407-05403.......................... 24 - 2
09407-12402.......................... 35 - 20

09407-14403.......................... 24 - 3-1
09407-18403.......................... 24 - 3-2
09407-26401.......................... 24 - 3-3
09421-04004.......................... 5 - 13
09440-03004.......................... 6 - 6

09440-04003.......................... 15 - 11
09440-04010.......................... 15 - 39
09440-11016.......................... 15 - 19
09440-11018.......................... ..8 - 7
09440-15014............................13 - 10

09440-18002.......................... 12 - 17
09443-06078.......................... 24 - 8
09443-07001.......................... 45 - 4
09443-08044.......................... 15 - 20
09443-14015.......................... 27 - 14

09443-15013.......................... 27 - 5
09443-18006.......................... 27 - 4
09443-19006.......................... 27 - 11
09443-22003.......................... 27 - 6
09444-26013.......................... 15 - 29

09448-14012.......................... 28 - 8
09462-00020.......................... 18 - 5
09462-00145.......................... 1 - 15-2
09462-00399.......................... 1 - 15-3
09471-12001.......................... 21 - 6

09471-12035.......................... 23 - 4
09471-12044.......................... 21 - 4
09471-12045.......................... 22 - 17
09471-12045.......................... 22 - 6
09471-12082.......................... 20 - 5

09482-00144.......................... 1 - 15-1
09482-00144.......................... 1 - 15-5
09482-00145.......................... 1 - 15-6
09482-00223.......................... 1 - 15-4
09482-00223.......................... 1 - 15-8

GN125X 32 -4 -
SUZUKI GN125X E2 PARTS CATALOGUE
SUZUKI MOTOR CORPORATION All rights reserved
No part of this document may be reproduced or transmitted in any form or by any means, electronic or
mechanical, for any purpose, without the express written permission of Suzuki Motor Corporation.

SUZUKI MOTOR CORPORATION

Technical Readiness Group, Quality Administration Department
300 Takatsuka, Minami, Hamamatsu, Japan
SUZUKI MOTOR de COLOMBIA S.A
Departamento de Repuestos, Diseño y Desarrollo de Catalogos de Partes.
Km 15 Via Pereira-Cartago (PEREIRA, RISARALDA - COLOMBIA) Tel: 3139626 -3139627

Reprint Prohibited
 SUZUKI MOTOR DE COLOMBIA S.A

EDITADO EN COLOMBIA S
