MT07 20142 PDF

MT07A (1XB6) EUROPE
MT07A (1XB8) EUROPE
1N1XB-352SK
( )
MT07A
CATALOGO DE REPUESTOS
©2014 por Yamaha Motor Co., Ltd.
1ª edición, febrero 2014
Todos los derechos reservados.
Toda reproducción o uso no autorizado
sin el consentimiento escrito de
Yamaha Motor Co., Ltd.
quedan expresamente prohibidos
Impreso en Japón.
PROLOGO
Este catálogo de repuestos corresponde a las piezas para el o los modelos que figuran en la 6. EL asterisco (*) antes del número de referencia indica los elementos modificados des-
página de portada. Al formular el pedido de repuestos, se ruega citar este catálogo y especi- pués de la primera edición.
ficar correctamente el número y el nombre de las piezas.
1. Las modificaciones y agregados que se hayan realizado después de la edición de este

Catálogo de Repuestos, serán anunciados en las Informaciones de Recambios.
Es recomendable que se hagan las correcciones necesarias en el Catálogo de Repues-
tos de acuerdo con las Informaciones de Recambios.
2. Abreviaciones
En este. Catálogo de Repuestos se emplean las siguientes abreviaciones.
“UR” Usar el número de partes especificado
“UN” Usar la cantidad necesaria
“AP” Piezas sustitutivas
“LM” Fabricación local (Hay que pedir los repuestos en las cercanías)
“F#” Nº de bastidor (Nº aplicable a la máquina)
“O/S” Sobredimensionado
3. La cantidad de componentes para el montaje

• Los componentes, suministrados como conjunto, se describen con un punto (.) que
precede al nombre del parte como se indica a continuación.
• La numeración que aparece a la derecha de cada descripción indica la cantidad de
partes por cada unidad de conjunto.
CODIGO Nº DESCRIPCION CANT. OBSERVACIONES

2F5–83310–60 ENSAMBLAJE DE LA LUZ 2
115–83311–60 .BOMBILLA (6V–18W) 1
4. Los colores de los componentes se indican como sigue en la columna de “OBSERVA-

CIONES”.
CODIGO Nº DESCRIPCION CANT. OBSERVACIONES

2N4–24110–00–X5 COMP. DEL TANQUE 2 MXR
3J1–24240–10 .GRAFICO, DEL TANQUE 1 PARA MXR
5. Debe tenerse en cuenta que las ilustraciones sirven como guia para la búsqueda de los
números de partes y no deben usarse para el montaje. Durante el montaje, se recomien-
da usar el manual de taller correspondiente.
PROLOGO
7. Números de serie
Nº de Serie del motor Nº de Serie del bastidor
8. Códigos de color aplicables (El símbolo (*) muestra el color de modelo.)
Abreviatura Nombre de color Código de color

DNMN(*) DARK GRAY METALLIC N 1366
DPBM15 DEEP PURPLISH BLUE METALLIC 15 1329
MBL2 MAT BLACK 2 0582
ROTULO DE MODELO
(1) El rótulo llamada “Rótulo de Modelo” está en la ubicación indicada abajo en el (3). (5) Código de Modelo–Número de código de Producción del Modelo Listado en este Catá-
Cuando se utilice este catálogo de repuestos, se ruega cotejar entre el “código de mo- logo de Repuestos
delo–número de código de producción” del catálogo y el “código de modelo–número de
código de producción” indicado en el Rótulo de Modelo fijado en el producto correspon- Código Número de Código Número de
diente. de Código de País (destino) de Código de País (destino)
Modelo Producción Modelo Producción
(2) Indicación del “Rótulo de Modelo”
AUSTRIA
CZECHO
GERMANY
HUNGARY
1XB6 010
ITALY
(3) Ubicación de fijación del Rótulo de Modelo SLOVAK

SPAIN
SWITZERLAND
AUSTRIA
CZECHO
GERMANY
HUNGARY
1XB8 010
ITALY
SLOVAK
(4) Información de Color SPAIN
Código de Código de Código Abrevia- SWITZERLAND
Nombre de color
Modelo tipo de color de color tura
1XB6 A 1366 DARK GRAY METALLIC N DNMN
1XB8 A 1366 DARK GRAY METALLIC N DNMN
CONTENIDO
MOTOR
CULATA DE CILINDRO ........................................................ 1 LUZ DE DESTELLADOR ...................................................... 62
CIGUENAL & PISTON .......................................................... 2 MEDIDOR ............................................................................. 63
VALVULA .............................................................................. 4 FARO DELANTERO ............................................................. 64
ARBOL DE LEVAS & CADENA ............................................ 6 LUZ DE COLA ...................................................................... 65
BOMBA DE AGUA ................................................................ 7 INTERRUPTOR DE MANILLAR&PALANC .......................... 66
RADIADOR & MANGUERA .................................................. 9 EQUIPO ELECTRICO 1 ....................................................... 67
BOMBA DE ACEITE ............................................................. 11 EQUIPO ELECTRICO 2 ....................................................... 69
FILTRO ACEITE .................................................................... 12 EQUIPO ELECTRICO 3 ....................................................... 70
ADMISION ............................................................................. 13 INDICE
ADMISION 2 .......................................................................... 15
DESCARGA .......................................................................... 16 INDICE NUMERICO ............................................................. 71
CARTER ................................................................................ 17
CUBIERTA DE CARTER 1 ................................................... 18
ARRANQUE .......................................................................... 19
EMBRAGUE .......................................................................... 20
TRANSMISION ..................................................................... 21
LEVA DE CAMBIO & HORQUILLA ....................................... 23
EJE DE CAMBIO & PEDAL .................................................. 24
SHASIS
CUADRO ............................................................................... 25
GUARDABARRO .................................................................. 27
CUBIERTA LATERAL ........................................................... 29
BRAZO TRASERO ................................................................ 31
SUSPENSION TRASERO .................................................... 33
DIRECCION .......................................................................... 34
HORQUILLA DELANTERA ................................................... 35
DEPOSITO DE COMBUSTIBLE ........................................... 37
DEPOSITO DE COMBUSTIBLE 2 ........................................ 39
ASIENTO ............................................................................... 42
RUEDA DELANTERA ........................................................... 44
CALIBRE FRENO DELANTERA ........................................... 45
RUEDA TRASERA ................................................................ 47
CALIBRE FRENO TRASERA ............................................... 49
MANILLAR & CABLE ............................................................ 50
CILINDRO MAESTRO DELANTERO .................................... 51
SOPORTE & APOYAPIE ...................................................... 53
SOPORTE & APOYAPIE 2 ................................................... 56
CILINDRO MAESTRO TRASERO ........................................ 58
GENERADOR ....................................................................... 60
MOTOR DE ARRANQUE ...................................................... 61
FIG. 1 CULATA DE CILINDRO
REF.
1XB6
1XB8
CODIGO Nº DESCRIPCION OBSERVACIONES
Nº
1 1WS–11101–09 CULATA DE CILINDRO COMPLETA 1 1
2 4D9–11133–10 .GUIA DE VALVULA 1 8 8
3 91808–16023 .PASADOR DE CLAVIJA 2 2
5 90105–06027 .TORNILLO 12 12
6 90340–18002 .TORNILLO, DE DRENAJE 1 1
7 93501–04011 .BOLA 1 1
8 90116–08087 .ESPARRAGO 4 4
9 94701–00436 BUJIA (NGK LMAR8A-9) 2 2
10 90109–06293 PERNO 1 1
11 5VY–1111G–00 CASQUILLO DE GOMA 1 1
12 90119–10056 TORNILLO CON ARANDELA 6 6
13 90110–06081 TORNILLO ALLEN 2 2
14 1WS–11181–00 JUNTA, DE CULATA 1 1 1
15 99530–10114 PASADOR, DE ESPIGA 2 2
16 1WS–11190–00 TAPA CULATA DE CILINDRO 1 1 1
17 1WS–11165–00 .PLACA RESPIRADERO 1 1
18 1WS–11169–00 .EMAPQ CBTA.DE RESP. 1 1
19 90105–05024 .TORNILLO 6 6
20 1WS–11193–00 .EMPAQUE 1 1
21 90109–066F0 PERNO 4 4
22 5VY–1111G–00 CASQUILLO DE GOMA 4 4
1
FIG. 2 CIGUENAL & PISTON
REF.
1XB6
1XB8
Nº
1 1WS–11400–00 CIGUENAL COMPLETO 1 1
2 1WS–11650–00 BIELA COMPLETA 2 2
3 1RC–11654–00 .TORNILLO DE BIELA 2 2
4 1RC–11656–00 COJINETE PLANO 4 4 UR AZUL
1RC–11656–10 COJINETE PLANO 4 4 UR NEGRO
1RC–11656–20 COJINETE PLANO 4 4 UR MARRON
1RC–11656–30 COJINETE PLANO 4 4 UR VERDE
5 3GM–11416–B0 COJINETE PLANO 1 6 6 UR PURPURA
3GM–11416–A0 COJINETE PLANO 1 6 6 UR BLANCO
3GM–11416–00 COJINETE PLANO 1 6 6 UR AZUL
3GM–11416–10 COJINETE PLANO 1 6 6 UR NEGRO
3GM–11416–20 COJINETE PLANO 1 6 6 UR CASTANO
6 1WS–11631–00 PISTON (NORMA) 2 2
7 1WS–11603–00 JUEGO DE ANILLOS (NORMA) 2 2
8 1WS–11633–00 PASADOR, PISTON 2 2
9 93450–19052 SEGURO 4 4
10 90280–05029 CUNA WOODRUFF 1 1
11 90105–126A8 TORNILLO 1 1
12 90201–12008 ARANDELA PLANA 1 1
13 1WS–11500–00 COMPENSADOR COMPLETA 1 1
14 1WS–11454–00 .PESO 1 1 1
15 1WS–11496–00 .COPA TOPE 1 1
16 1WS–11531–00 .ENGRANAJE CONTRAPESO 1 1
17 90501–22721 .RESORTE DE COMPRESION 8 8
19 1WS–11533–00 .PLACA DE AMORTIGUADOR 1 1
20 90282–04001 .CHAVETA, RECTA 1 1
2
FIG. 2 CIGUENAL & PISTON
REF.
1XB6
1XB8
Nº
21 90105–10445 .TORNILLO 1 1
22 2S3–11413–00 DESLIZADOR METALICO P/PESO 6 6 UR AZUL
2S3–11413–10 DESLIZADOR METALICO P/PESO 6 6 UR NEGRO
2S3–11413–20 DESLIZADOR METALICO P/PESO 6 6 UR CASTANO
2S3–11413–30 DESLIZADOR METALICO P/PESO 6 6 UR VERDE
2S3–11413–40 DESLIZADOR METALICO P/PESO 6 6 UR AMARILLO
3
FIG. 3 VALVULA
REF.
1XB6
1XB8
Nº
1 1WS–12111–00 VALVULA DE ADMISION 4 4
2 1WS–12121–00 VALVULA DE ESCAPE 4 4
3 1WS–12113–01 RESORTE VALVULA INTERNA 4 4
4 1WS–12114–00 RESORTE VALVULA EXTERIOR 4 4
5 1WS–12117–00 RETEN RESORTE DE VALVULA 8 8
6 1WG–12118–00 SEGURO DE VALVULA 16 16
7 4TE–12119–00 SELLO DE ACEITE VALVULA 8 8
8 1WS–12116–00 ASIENTO RESORTE DE VALVULA 8 8
9 4C8–12153–10 LEVANTADOR DE VALVULA 8 8 AMARILLO
4C8–12153–09 LEVANTADOR DE VALVULA (O/S) 8 8 AP VERDE
10 1HX–12168–F0 COJIN, AJUSTADOR 2 (1.50) 8 8 UR
1HX–12168–H1 COJIN, AJUSTADOR 2 (1.55) 8 8 UR
1HX–12168–K1 COJIN, AJUSTADOR 2 (1.60) 8 8 UR
1HX–12168–M1 COJIN, AJUSTADOR 2 (1.65) 8 8 UR
1HX–12168–R1 COJIN, AJUSTADOR 2 (1.70) 8 8 UR
1HX–12168–U1 COJIN, AJUSTADOR 2 (1.75) 8 8 UR
1HX–12168–W1 COJIN, AJUSTADOR 2 (1.80) 8 8 UR
1HX–12168–Y1 COJIN, AJUSTADOR 2 (1.85) 8 8 UR
1HX–12169–11 COJIN, AJUSTADOR 2 (1.90) 8 8 UR
1HX–12169–E0 COJIN, AJUSTADOR 2 (2.15) 8 8 UR
1HX–12169–G0 COJIN, AJUSTADOR 2 (2.20) 8 8 UR
1HX–12169–J0 COJIN, AJUSTADOR 2 (2.25) 8 8 UR
1HX–12169–L0 COJIN, AJUSTADOR 2 (2.30) 8 8 UR
4
FIG. 3 VALVULA
REF.
1XB6
1XB8
Nº
10 1HX–12169–N0 COJIN, AJUSTADOR 2 (2.35) 8 8 UR
1HX–12169–T0 COJIN, AJUSTADOR 2 (2.40) 8 8 UR
5
FIG. 4 ARBOL DE LEVAS & CADENA
REF.
1XB6
1XB8
Nº
1 1WS–12170–00 ARBOL DE LEVAS COMPLETO 1 1 1
2 2C0–12176–00 CATALINA DE CADENA 1 1
3 90105–07006 TORNILLO 2 2
4 1WS–12180–00 ARBOL DE LEVAS COMPLETO 2 1 1
5 1WS–12181–00 .ARBOL DE LEVAS 2 1 1
6 90331–16001 .TAPON 1 1
7 1WS–12280–00 .EQUIPO DE DESCOMPRESION 1 1
8 90105–07006 .TORNILLO 2 2
9 1WS–12247–00 .EJE TENSOR 1 1
10 1WS–12257–00 .EJE 2 1 1
11 1PD–12288–00 .LEVA DE DESCOMPRESION 2 2
12 94591–61134 CADENA 1 1
13 1WS–12210–01 TENSOR CADENA DE LEVA 1 1
14 5EL–12228–00 .PERNO 1 1
15 5SL–12214–00 .EMPAQUE 1 1
16 1WS–12213–00 EMPAQUE DE CAJA TENSOR 1 1
17 90110–06396 TORNILLO ALLEN 2 2
18 1WS–12251–00 AMORTIGUADOR CADENA 1 1 1
19 1WS–12252–00 AMORTIGUADOR CADENA 2 1 1
20 90109–06295 PERNO 1 1
6
FIG. 5 BOMBA DE AGUA
REF.
1XB6
1XB8
Nº
1 1WS–12481–00 TUBO 1 1 1
2 93210–235A1 ANILLO O 1 1
3 1WS–12482–00 TUBO 2 1 1
4 95022–06010 .PERNO, DE BRIDA 1 1
5 90430–06014 .JUNTA 1 1
6 93210–235A1 ANILLO O 1 1
7 91314–06014 TORNILLO ALLEN 1 1
9 1WS–12576–00 MANGUERA 1 2 2
10 90467–290A0 PRESILLA 3 3
11 90450–35001 BRIDA, MANGUERA 1 1
12 1WS–12469–00 CONDUCTO 1 1
13 93210–33786 ANILLO O 1 1
14 95812–06020 TORNILLO DE REBORDE 2 2
15 1WS–12410–00 TERMOSTATO CONJUNTO 1 1
16 1WS–12413–00 CUBIERTA TERMOSTATO 1 1
17 95817–06020 TORNILLO 2 2
18 1WS–12588–00 MANGUERA 5 1 1
19 90467–170A6 PRESILLA 2 2
20 1WS–12589–00 MANGUERA 6 1 1
21 90467–170A6 PRESILLA 2 2
22 1WS–15421–00 TAPA DE CARTER DERECHA 1 1
23 2D1–16382–00 EJE DE PALANCA DE EMPUJE 1 1
24 92907–08600 ARANDELA 1 1
25 99001–07600 PRESILLA REDONDA 1 1
26 93317–11096 COJINETE 1 1
27 93315–21570 COJINETE DE RODILLOS 1 1
7
FIG. 5 BOMBA DE AGUA
REF.
1XB6
1XB8
Nº
28 93102–15212 SELLO ACEITE 1 1
29 1WS–12450–00 EJE IMPULSOR COMPLETO 1 1
30 93306–00106 COJINETE 1 1
31 5VK–12438–00 SELLO MECANICO 1 1
32 93101–12173 SELLO ACEITE 1 1
34 1WS–12422–00 CUBIERTA DE CAJA 1 1
35 1WS–12439–00 ANILLO O 1 1
36 93603–12007 PASADOR DE CLAVIJA 1 1
37 90110–06274 TORNILLO ALLEN 3 3
8
FIG. 6 RADIADOR & MANGUERA
REF.
1XB6
1XB8
Nº
1 1WS–12461–00 RADIADOR COMPLETO 1 1
2 1WS–12405–00 COMPRESOR 1 1
3 1WS–12671–00 TUERCA 1 6 6
4 5GJ–12675–00 PERNO, SUJECION VENTILADOR 3 3
5 90480–15363 TAPON 3 3
6 90387–07391 ESPACIADOR 1 1
8 3D7–12462–00 TAPON, DEL RADIADOR 1 1
9 91317–03006 PERNO 1 1
10 1WS–12578–00 MANGUERA 3 1 1
11 90467–290A0 PRESILLA 1 1
12 90450–35001 BRIDA, MANGUERA 1 1
13 1WS–21871–00 TANQUE DE RECUPERACION 1 1
14 26H–21828–00 CODO 1 1
15 90445–08020 TUBO 1 1
16 3P6–21875–00 TAPA 1 1
17 90467–08075 PRESILLA 1 1
18 1WS–21816–00 TUBO 1 1 1
19 4XY–14568–00 UNION 1 1
20 1WS–2172W–00 CUBIERTA 1 1
21 90269–06008 REMACHE 1 1
22 90387–06024 ESPACIADOR 1 1
23 90110–06163 TORNILLO ALLEN 1 1
24 90467–08075 PRESILLA 1 1
25 90467–08003 PRESILLA 1 1
26 90445–11M08 TUBO (L10) 1 1
27 90464–07M40 BRIDA 1 1
9
FIG. 6 RADIADOR & MANGUERA
REF.
1XB6
1XB8
Nº
28 1WS–21731–00 TAPA LATERAL 3 1 1
29 1WS–21741–00 TAPA LATERAL 4 1 1
30 90387–06130 ESPACIADOR 4 4
31 90111–06151 TORNILLO 4 4
10
FIG. 7 BOMBA DE ACEITE
REF.
1XB6
1XB8
Nº
1 1WS–13300–00 BOMBA DE ACEITE COMPLETA 1 1
2 99009–15500 .PRESILLA REDONDA 1 1
4 94581–79060 CADENA 1 1
5 1WS–13898–00 SOSTEN 1 1
7 1WS–13410–00 CAJA DE FILTRO COMPLETA 1 1
8 93210–207A0 ANILLO O 1 1
9 90480–13010 TAPON 1 1
10 5VY–13117–10 COLLAR, DISTANCIA 1 1
11 90110–06173 TORNILLO ALLEN 3 3
11
FIG. 8 FILTRO ACEITE
REF.
1XB6
1XB8
Nº
1 1WS–13470–00 ENFRIADOR DE ACEITE COMPLETO 1 1
2 1XD–13475–00 EMPAQUE 1 1
3 90401–20009 PERNO DE UNION 1 1
4 5GH–13440–50 ELEMENTO FILTRO DE ACEITE 1 1
5 1WS–13400–00 CUBIERTA DE FILTRO COMPLETO 1 1
6 90340–14132 .TORNILLO, DE DRENAJE 1 1
7 214–11198–01 .EMPAQUE 1 1
8 1WS–13414–00 EMPAQUE DE TAPA FILTRO 1 1
9 91312–06030 TORNILLO 11 11
12
FIG. 9 ADMISION
REF.
1XB6
1XB8
Nº
1 1WS–13635–00 JUNTA DE ADMISION 1 2 2
2 90450–56011 BRIDA, MANGUERA 2 2
3 90450–56012 BRIDA, MANGUERA 2 2
4 1WS–13542–00 MANGUERA, DE VACIO 1 1 1
5 1WS–14401–00 CAJA DE FILTRO DE AIRE COMPL. 1 1
6 1WS–14450–00 ELEMENTO COMP.FILTRO DE AIRE 1 1
7 1WS–14452–00 .SELLO 1 1
8 1WS–14469–00 EMBUDO PARA AIRE 1
1WS–14469–10 EMBUDO PARA AIRE 1
9 1WS–1446C–00 EMBUDO 2 1
1WS–1446C–10 EMBUDO 2 1
10 90160–05013 TORNILLO REDONDO ROSCA HEMBRA 5 5
11 1WS–14430–00 CONJUNTO CONDUCTO 1
1WS–14430–20 CONJUNTO CONDUCTO 1
12 1WS–14437–00 .CONDUCTO 1
13 3D7–14545–00 .DIAFRAGMA 1 1
14 90450–56011 BRIDA, MANGUERA 2 2
15 1WS–1443E–00 TUBO, DRENAJE 1 1
16 90467–13083 PRESILLA 1 1
17 90480–15001 TAPON 1 1
18 90480–15014 TAPON 1 1
19 90387–06300 ESPACIADOR 2 2
20 95817–06025 TORNILLO 2 2
21 90201–064K6 ARANDELA PLANA 1 1
22 5PS–1410H–00 SOLENOIDE VALVULA 1 1
23 95707–05500 TUERCA DE BRIDA 1 1
24 5PS–14552–00 VALVULA DE RETENCION 1 1
13
FIG. 9 ADMISION
REF.
1XB6
1XB8
Nº
25 5PS–1446E–00 DEPOSITO, COMPENSACION 1 1
26 95707–05500 TUERCA DE BRIDA 1 1
27 1WS–13545–00 SELLO 1 1
28 1WS–13546–00 SELLO 1 1
29 1WS–13547–00 SELLO 1 1
30 90445–08010 TUBO 1 1
31 1WS–11166–00 TUBO RESPIRADERO 1 1 1
32 90467–17128 PRESILLA 1 1
33 90467–160A2 PRESILLA 1 1
14
FIG. 10 ADMISION 2
REF.
1XB6
1XB8
Nº
1 1WS–13750–00 CAJA DE ACELERADOR COMPL. 1
1WS–13750–20 CAJA DE ACELERADOR COMPL. 1
2 8FP–13556–00 .ANILLO PROTECTOR 2 2
3 1WS–13761–00 .INYECTOR 2 2
4 5PS–14147–00 ..ANILLO O 1 1
5 1WS–85801–00 .MOTOR 1 1
6 1WS–14335–00 .RESORTE DE EMBOLO 1 1
7 98502–06012 .TORNILLO 1 1
8 54P–14243–00 .PLACA 1 1
9 1WS–13938–00 .TUBO DE ADMISION 1 1
10 8HG–13573–00 .PERNO 1 2 2
11 8GL–13571–00 .ARANDELA 2 2
12 8HG–14534–00 .COLLAR 2 2
13 8CC–14216–10 .TORNILLO 2 2
14 3B4–85885–00 .TERMICA SENSORIO 1 1
15 54P–E416A–00 .ANILLO O 1 1
15
FIG. 11 DESCARGA
REF.
1XB6
1XB8
Nº
1 1WS–14710–00 TUBO DE ESCAPE COMPLETO 1 1 1
2 1WS–14708–00 .PROTECTOR COMPLETA 1 1
3 90111–06060 .TORNILLO 3 3
4 1WS–8592A–00 .SENSOR 1 1
5 3YF–14613–01 JUNTA, TUBO DE ESCAPE 2 2
6 90179–08410 TUERCA 4 4
7 20S–21445–01 SOPORTE DE SILENCIADOR 1 2 2
8 90105–08164 TORNILLO 2 2
9 95824–06016 TORNILLO 4 4
16
FIG. 12 CARTER
REF.
1XB6
1XB8
Nº
1 1WS–15100–09 CARTER COMPLETO 1 1
2 5EB–15155–00 .BOQUILLA 3 2 2
3 93210–04092 .ANILLO O 2 2
4 99530–10014 .PASADOR, DE ESPIGA 3 3
5 90338–16262 .TAPON 3 3
6 93210–12790 .ANILLO O 3 3
7 2H7–15361–00 MEDIDOR DE NIVEL 1 1
8 36Y–15189–00 TAPON 1 1
9 93210–16325 ANILLO O 1 1
10 1WS–15189–00 TAPON 1 1
11 90101–06043 TORNILLO 1 1
13 1WS–15156–00 TORNILLO, CARTER MANIVELA MUNO 6 6
14 93210–07540 .ANILLO O 1 1
18 90109–06100 PERNO 2 2
19 90462–10064 BRIDA 1 1
20 1WS–15416–00 CUBIERTA DE BOMBA DE ACEITE 1 1
21 1WS–15456–00 EMPAQ CUBTA.BOMBA ACEITE 1 1 1
22 90110–06395 TORNILLO ALLEN 2 2
23 1WS–15128–00 SOPORTE 1 1
17
FIG. 13 CUBIERTA DE CARTER 1
REF.
1XB6
1XB8
Nº
1 1WS–15411–00 CUBIERTA DE CARTER 1 1 1
2 90340–36005 TORNILLO, DE DRENAJE 1 1
3 93210–357A3 ANILLO O 1 1
4 92017–08012 PERNO 1 1
5 90430–08143 JUNTA 1 1
6 1WS–15451–00 EMPAQ DE CUBIERTA DE CARTER 1 1
10 1WS–15418–00 CUBIERTA CAJA DE CADENA 1 1
11 1WS–15377–00 GUIA DE ENTRADA 1 1
12 90110–06395 TORNILLO ALLEN 3 3
13 1WS–15461–00 JUNTA TAPA CARTER DERECHO 2 1 1
15 90110–06388 TORNILLO ALLEN 10 10
16 90465–08045 BRIDA 2 2
17 1WS–15441–00 SOSTEN DE CABLE DE EMBRAGUE 1 1
18 90110–06389 TORNILLO ALLEN 2 2
19 3F9–15362–10 TAPON DEL NIVEL DE ACEITE 1 1
20 93210–27194 ANILLO O 1 1
18
FIG. 14 ARRANQUE
REF.
1XB6
1XB8
Nº
1 1WS–15515–00 ENGRANAJE 3 1 1
2 1WS–15590–00 ENSAMBLE GUIA CADENA ARRANQUE 1 1
3 90149–08030 TORNILLO DE REGLAJE 3 3
4 23P–15521–00 EJE 1 1 1
5 1WS–15512–00 ENGRENAJE NEUTRO 1 1
6 1WS–15560–00 AMORTIGUADOR 1 1
7 93317–11096 COJINETE 1 1
8 93306–00006 COJINETE 1 1
19
FIG. 15 EMBRAGUE
REF.
1XB6
1XB8
Nº
1 1WS–16150–00 CAMPANA DE EMBRAGUE 1 1
2 363–16154–00 ARANDELA, DE EMPUJE 1 1 1
3 1WS–16371–00 CUBO, DE EMBRAGUE 1 1
4 5VY–16321–00 PLACA DE FRICCION 5 5
5 5VY–16325–00 DISCO, DE EMBRAGUE 6 6
6 5TG–16321–00 PLACA DE FRICCION 2 2
7 1WS–16350–00 PLACA DE PRESION COMPLETA 1 1
8 93306–00106 .COJINETE 1 1
9 90501–230E4 RESORTE DE COMPRESION 6 6
11 1WS–16181–00 SEPARADOR 1 1
12 93310–232R9 COJINETE DE RODILLOS 1 1
13 363–16154–00 ARANDELA, DE EMPUJE 1 1 1
14 90201–20030 ARANDELA PLANA 1 1
15 90208–20001 ARANDELA DE RESORTE CONICO 1 1
16 90179–20007 TUERCA 1 1
17 1WS–16356–00 VARILLA DE EMPUJE 1 1 1
18 1WS–16340–00 PALANCA DE EMPUJE COMPLETA 1 1
19 90508–18132 RESORTE DE TORSION 1 1
20 90201–10029 ARANDELA PLANA 1 1
20
FIG. 16 TRANSMISION
REF.
1XB6
1XB8
Nº
1 1WS–17401–00 EJE PRINCIPAL COMPLETO 1 1
2 1WS–17151–00 ENGRANAJE PINON DE 5TA (22T) 1 1
3 90387–250R3 ESPACIADOR 1 1
4 90209–21332 ARANDELA DE SEPARACION 1 1
5 93440–25186 SEGURO 1 1
6 1WS–17131–00 ENGRANAJE PINON DE 3RA(20/19T) 1 1
7 93440–25186 SEGURO 1 1
9 1WS–17161–00 ENGRANAJE PINON 6TA (28T) 1 1
10 90387–21003 ESPACIADOR 1 1
13 1WS–17121–00 ENGRANAJE PINON DE 2DA (16T) 1 1
14 93306–20464 COJINETE 1 1
15 1WS–17446–00 PLACA 1 1
17 1WS–17421–00 EJE SECUNDARIO 1 1
18 93306–20663 COJINETE 1 1
19 90387–30012 ESPACIADOR 1 1
20 93440–64199 SEGURO 1 1
21 93102–40030 SELLO ACEITE 1 1
22 1WS–17221–00 ENGRANAJE RUEDA DE 2DA (34T) 1 1
23 90387–31003 ESPACIADOR 1 1
25 93440–31187 SEGURO 1 1
26 1WS–17261–00 ENGRANAJE RUEDA DE 6TA (27T) 1 1
27 93440–31187 SEGURO 1 1
21
FIG. 16 TRANSMISION
REF.
1XB6
1XB8
Nº
29 1WS–17241–00 ENGRANAJE DE RUEDA 4TA (26T) 1 1
30 90387–28004 ESPACIADOR 1 1
31 90214–29002 ARANDELA DE POSICION 1 1
32 90214–28002 ARANDELA DE POSICION 1 1
33 1WS–17231–00 ENGRANAJE RUEDA DE 3RA (31T) 1 1
34 90387–28004 ESPACIADOR 1 1
36 93440–31187 SEGURO 1 1
37 1WS–17251–00 ENGRANAJE RUEDA DE 5TA (24T) 1 1
38 1WS–17211–00 ENGRANAJE RUEDA DE 1RA (37T) 1 1
39 90387–25008 ESPACIADOR 1 1
40 1WS–17460–00 CORONA (16T) 1 1
41 90208–22002 ARANDELA DE RESORTE CONICO 1 1
42 90179–22018 TUERCA 1 1
43 90201–20008 ARANDELA PLANA 1 1
44 93306–20464 COJINETE 1 1
22
FIG. 17 LEVA DE CAMBIO & HORQUILLA
REF.
1XB6
1XB8
Nº
1 1WS–18540–00 LEVA DEL CAMBIO COMPLETA 1 1
2 3D7–18542–00 PUNTO MUERTO 1 1
3 90501–06022 RESORTE DE COMPRESION 1 1
4 1WS–18511–00 HORQUILLA DEL CAMBIO 1 1 1
7 20S–18535–00 BARRA GUIA HORQ .CAMBIO 2 2 2
8 1WS–18536–00 TOPE DE PALANCA SELECTOR 1 1
23
FIG. 18 EJE DE CAMBIO & PEDAL
REF.
1XB6
1XB8
Nº
1 90506–18021 RESORTE DE TENSION 1 1
2 132–16346–00 GANCHO DE RESORTE 1 1
3 1D7–18127–00 PASADOR DE PALANCA 1 1
4 1WS–18101–00 EJE SELECTOR COMPLETO 1 1
5 90508–29040 .RESORTE DE TORSION 1 1
6 2C0–18175–00 .ESPACIADOR 1 1
7 1WS–18140–00 .PALANCA DE TOPE COMPLETA 1 1
8 90201–177G4 .ARANDELA PLANA 1 1
9 99009–17400 .PRESILLA REDONDA 1 1
10 93317–11295 COJINETE 1 1
11 93102–12106 SELLO ACEITE (SD 12-22-5 HS) 1 1
12 90201–12575 ARANDELA PLANA 2 2
14 1WS–18112–00 BRAZO DEL CAMBIO 1 1
15 91317–06020 PERNO 1 1
24
FIG. 19 CUADRO
REF.
1XB6
1XB8
Nº
1 1WS–21110–50 ARMAZON COMPLETO 1 1
2 1WS–2191B–00 PLACA 1 1 1
3 90105–10219 TORNILLO 1 1
4 90105–10349 TORNILLO 1 1
5 90179–10024 TUERCA 2 2
6 90201–10035 ARANDELA PLANA 2 2
7 90105–12092 TORNILLO 2 2
9 1WS–21315–00 SOPORTE DE MOTOR 1 1 1
10 1WS–21316–00 SOPORTE DE MOTOR 2 1 1
11 90110–10044 TORNILLO ALLEN 2 2
12 90110–08111 TORNILLO ALLEN 4 4
13 90520–20004 EQUILIBRIO, CUBIERTA 1 1
15 1WS–21946–00 SOPORTE ASIENTO ACCESORIE 1 1
16 1WS–2112B–00 ASIENTO 1 1 1
17 92012–06010 PERNO 4 4
18 1WS–2117N–00 CUBIERTA 3 1 1
19 90387–1001B ESPACIADOR 1 1
22 90387–06372 ESPACIADOR 1 1
23 90269–06002 REMACHE 1 1
24 1WS–21158–00 SOPORTE 1 1
26 3UF–24737–00 AMORTIGUADOR DE ASIENTO 1 1
27 3KJ–15337–00 COLLAR 1 1
25
FIG. 19 CUADRO
REF.
1XB6
1XB8
Nº
28 1HX–27415–00 PLACA 1 1
29 5DM–28371–00 AMORTIGUADOR 1 1
30 90480–30167 TAPON 2 2
31 4XV–21376–00 BANDA DE HERRAMIENTA 1 1
32 95702–06500 TUERCA DE BRIDA 2 2
33 90111–06122 TORNILLO 1 1
34 1WS–2161J–00 SOPORTE 8 1 1
35 92017–06010 PERNO 1 1
36 1WS–2175U–00 SOPORTE 2 1 1
37 90269–07077 REMACHE 1 1
38 1WS–2117R–00 CUBIERTA 4 1 1
39 1HX–27415–00 PLACA 3 3
40 1WS–2117T–00 CUBIERTA 5 1 1
41 1HX–27415–00 PLACA 2 2
42 95807–06012 TORNILLO 2 2
43 90387–062M9 ESPACIADOR 2 2
44 1XB–21288–00 GUIA DE CABLE 1 1
45 95027–06010 PERNO, DE BRIDA 1 1
46 3HA–24141–00 PROTECTOR DEPOSITO COMBUST. 1 1
26
FIG. 20 GUARDABARRO
REF.
1XB6
1XB8
Nº
1 1WS–21511–00 GUARDABARRO DELANTERO 1 1
5 90111–06151 TORNILLO 2 2
6 90387–08079 ESPACIADOR 2 2
8 90387–06066 ESPACIADOR 2 2
9 1WS–21512–00 SOPORTE DE GUARDABARRO 1 1
10 1WS–21612–00 SOPORTE DE GUARDABARRO 1 1
11 95022–06010 PERNO, DE BRIDA 4 4
12 1WS–21513–00–P4 SOPORTE DE GUARDABARRO 1 1 PARA DNMN
14 90387–06107 ESPACIADOR 1 1
15 1WS–21514–00–P4 SOPORTE DE GUARDABARRO 2 1 1 PARA DNMN
17 90387–06107 ESPACIADOR 1 1
18 5VS–21578–10 EMBLEMA 1 1
19 5VS–21578–10 EMBLEMA 1 1
20 1WS–8212B–00 CAJA DE BATERIA 1 1
21 1WS–21639–00 AMORTIGUADOR 2 1 1
22 90109–06202 PERNO 3 3
23 90338–06018 TAPON 2 2
24 90464–18002 BRIDA 1 1
25 90183–04039 TUERCA DE RESORTE 2 2
26 90480–14100 TAPON 2 2
27 90465–13275 BRIDA 1 1
27
FIG. 20 GUARDABARRO
REF.
1XB6
1XB8
Nº
28 1WS–21642–00 GUARDA DE CHARNELA 1 1
29 90269–06002 REMACHE 2 2
30 1WS–21629–00 GUARDABARRO INFERIOR 1 1
31 90387–06372 ESPACIADOR 4 4
32 90111–06089 TORNILLO 4 4
33 1WS–2164F–00 APOYO 1 1 1
34 1WS–2164G–00 APOYO 2 1 1
35 1WS–21682–00 SOPORTE DE PLACA 1 1
37 1WS–2161G–00 SOPORTE 6 1 1
38 90105–06205 TORNILLO 4 4
39 1WS–2163A–00 CUBIERTA TRAS GUARDABARRO 1 1 1
40 90269–07008 REMACHE 2 2
41 3Y6–85130–02 REFLECTOR TRASERO COMPLETO 1 1
42 95602–05200 TUERCA DE AUTO-CIERRE 1 1
28
FIG. 21 CUBIERTA LATERAL
REF.
1XB6
1XB8
Nº
1 1WS–21711–00–P1 CUBIERTA LATERAL 1 1 1 PARA DNMN
2 1WS–2834E–00 AMORTIGUADOR 1 1 1
4 90109–06245 PERNO 1 1
6 90269–06008 REMACHE 1 1
8 90387–08101 ESPACIADOR 1 1
11 1WS–2834F–00 AMORTIGUADOR 1 1
13 90109–06245 PERNO 1 1
14 90110–08062 TORNILLO ALLEN 1 1
15 90269–06008 REMACHE 1 1
17 90387–08101 ESPACIADOR 1 1
19 1WS–2171E–00–P1 CUBIERTA LATERAL 5 1 1 PARA DNMN
21 1WS–2171X–00–P1 CUBIERTA LATERAL 6 1 1 PARA DNMN
23 97702–50012 TORNILLO ROSCA HEMBRA 2 2
24 97707–50016 TORNILLO 2 2
25 1WS–2171J–00 REVESTIMIENTO, CUBIERTALATERAL 1 1
26 90183–05M02 TUERCA DE RESORTE 3 3
27 1WS–2171K–00 REVESTIMINTO,CUBIERTALATERAL2 1 1
29
FIG. 21 CUBIERTA LATERAL
REF.
1XB6
1XB8
Nº
29 1WS–21651–00 TAPA DE GUARDABARRO TRAS. 1 1
30 90269–06008 REMACHE 1 1
31 1WS–21781–40 EMBLEMA 1 1 1
32 1WS–21782–40 EMBLEMA 2 1 1
33 1RC–2416B–00 EMBLEMA 1 1
30
FIG. 22 BRAZO TRASERO
REF.
1XB6
1XB8
Nº
1 1WS–22110–00 BRAZO TRASERO COMPLETO 1 1
2 93317–22262 COJINETE 3 3
3 93106–22019 SELLO ACEITE (DC 22-28-8) 2 2
4 30X–2219X–00 CUBIERTA 2 2
5 93108–35004 SELLO ACEITE (35-41-8) 2 2
6 90380–16158 CASQUILLO SOLIDO 2 2
7 1UY–22141–10 EJE DEL BARCULANTE 1 1
8 90201–164H4 ARANDELA PLANA 1 1
9 90185–16002 TUERCA AUTOBLOCANTE 1 1
10 1WS–2217A–00 BRAZO REEURIO 1 1
11 90105–102A6 TORNILLO 2 2
12 90201–10045 ARANDELA PLANA 1 1
14 93315–31758 COJINETE DE RODILLOS 3 3
15 93109–17071 SELLO ACEITE 6 6
16 90387–1012A ESPACIADOR 3 3
17 1WS–22189–00 FUNDA DE GOMA 1 1
18 1WS–2217F–00 BIELA COMPLETA 1 1 1
19 90101–12049 TORNILLO 1 1
21 93317–31771 COJINETE 2 2
22 93109–17071 SELLO ACEITE 2 2
23 1WS–22184–00 BUJE 1 1
24 1WS–22151–00 SELLO DE GUARDA 1 1
25 1WS–21650–00 GUARDABARRO TRANSERO COMP. 1 1
26 90387–06372 ESPACIADOR 2 2
27 90111–06119 TORNILLO 2 2
31
FIG. 22 BRAZO TRASERO
REF.
1XB6
1XB8
Nº
28 90269–07007 REMACHE 2 2
29 1WS–25887–00 SOPORTE DE MANGUERA FRENO 1 1
30 1WS–2588F–00 SOPORTE DE MANGUERA FRENO 5 1 1
31 92014–06016 PERNO 1 1
32 92017–06010 PERNO 1 1
33 1TP–21668–00 ETIQUETA DE FRANJA 1 1
32
FIG. 23 SUSPENSION TRASERO
REF.
1XB6
1XB8
Nº
1 1WS–22210–00 AMORTIGUADOR TRASERO COMPLETO 1 1
2 90105–10283 TORNILLO 1 1
4 90387–1012A ESPACIADOR 1 1
5 90105–10212 TORNILLO 1 1
33
FIG. 24 DIRECCION
REF.
1XB6
1XB8
Nº
1 93399–99931 COJINETE 1 1
2 1W1–23416–00 CUBIERTA DE BASE DE BOLA 2 1 1
3 1WS–23357–00 TUERCA 1 1
4 1WS–23430–00 PLATINA SUPERIOR 1 1
5 91314–08030 .TORNILLO ALLEN 2 2
6 91314–10035 .TORNILLO ALLEN 1 1
7 1WS–84136–00 AMORTIGUADOR SOP.FARO DEL. 2 2
8 1WS–23442–00–P0 SOPORTE DE MANUBRIO INFERIOR 1 1 MBL2 PARA DNMN
9 92902–10200 ARANDELA 2 2
10 90201–10043 ARANDELA PLANA 2 2
11 90176–10003 TUERCA CORONA 2 2
12 1E6–23441–10–P0 SOPORTE DE MANUBRIO 2 2 MBL2 PARA DNMN
13 95022–08035 PERNO, DE BRIDA 4 4
14 1WS–2334G–00 SOPORTE 1 1 1
16 3C3–83513–00 AMORTIGUADOR 2 2
17 90387–06026 ESPACIADOR 2 2
18 95827–06025 TORNILLO 2 2
19 1WS–23121–00 CUBIERTA SUPERIOR 1 1 1
20 1WS–2318U–00 PLACA DE ASIENTO 1 1
21 1WS–23131–00 CUBIERTA SUPERIOR 2 1 1
22 90269–05055 REMACHE 2 2
23 93210–40M10 ANILLO O 2 2
24 1WS–2334H–00 SOPORTE 2 1 1
34
FIG. 25 HORQUILLA DELANTERA
REF.
1XB6
1XB8
Nº
1 1XB–23103–00 HORQUILLA DELANTERA COMPL.(MD) 1 1
2 1XB–23136–00 .TUBO EXTERIOR 2 1 1
3 1WS–23110–00 .TUBO INTERIOR COMPLETO 1 1 1
4 5BN–23171–00 ..PISTON HORQUILLA DELANT. 1 1
5 4EB–23144–00 .GUARDAPOLVO 1 1
6 26H–23156–00 .ANILLO DE ENGANCHE 1 1
7 4EB–23145–01 .RETEN DE ACEITE 1 1
8 36Y–23146–10 .ARANDELA DE SELLO DE ACEITE 1 1
9 4FM–23125–40 .METAL CORREDIZO 1 1 1
10 1WS–23170–00 .CILINDRO COMPL DE HORQ DELANT 1 1
11 4YR–23173–00 .VASTAGO AHUSADO 1 1
12 509–23158–L0 .EMPAQUE 1 1
13 278–23181–50 .TORNILLO CABEZAHEXAGONAL 1 1
14 1WS–23141–00 .RESORTE HORQUILLA DELANT. 1 1
15 3EN–23149–50 .ARANDELA DE RESORTE SUPERIOR 1 1
16 3FW–23118–00 .SEPARADOR 1 1
17 1D0–23111–00 .PERNO DE TAPA 1 1
18 43F–23188–10 .ANILLO O 1 1
19 91314–08040 .TORNILLO ALLEN 1 1
20 1WS–23102–00 HORQUILLA DELANTERA COMPL.(MI) 1 1
21 1WS–23126–00 .TUBO EXTERIOR (IZQUIERDO) 1 1
22 1WS–23110–00 .TUBO INTERIOR COMPLETO 1 1 1
23 5BN–23171–00 ..PISTON HORQUILLA DELANT. 1 1
24 4EB–23144–00 .GUARDAPOLVO 1 1
25 26H–23156–00 .ANILLO DE ENGANCHE 1 1
26 4EB–23145–01 .RETEN DE ACEITE 1 1
27 36Y–23146–10 .ARANDELA DE SELLO DE ACEITE 1 1
35
FIG. 25 HORQUILLA DELANTERA
REF.
1XB6
1XB8
Nº
28 4FM–23125–40 .METAL CORREDIZO 1 1 1
29 1WS–23170–00 .CILINDRO COMPL DE HORQ DELANT 1 1
30 4YR–23173–00 .VASTAGO AHUSADO 1 1
31 509–23158–L0 .EMPAQUE 1 1
32 278–23181–50 .TORNILLO CABEZAHEXAGONAL 1 1
33 1WS–23141–00 .RESORTE HORQUILLA DELANT. 1 1
34 3EN–23149–50 .ARANDELA DE RESORTE SUPERIOR 1 1
35 3FW–23118–00 .SEPARADOR 1 1
36 1D0–23111–00 .PERNO DE TAPA 1 1
37 43F–23188–10 .ANILLO O 1 1
38 1WS–23340–00 PLATINA INFERIOR COMPLETA 1 1
39 3FV–23462–00 SELLO PARA POLVO 1 1
40 93399–99932 COJINETE 1 1
41 91314–08030 TORNILLO ALLEN 4 4
42 1WS–2331G–00 CUBIERTA 2 2
43 4KM–23123–01 CUBIERTA INFERIOR 1 1
36
FIG. 26 DEPOSITO DE COMBUSTIBLE
REF.
1XB6
1XB8
Nº
1 1WS–24110–00 DEPOSITO DE COMBUSTIBLE COMP. 1 1
2 1WS–2412Y–00 SOPORTE TANK ELEQUIPO 1 1
3 3D7–24339–00 ANILLO PROTECTOR 2 2
4 90387–06136 ESPACIADOR 2 2
5 5YU–85886–00 SENSOR 1 1
6 98502–05012 TORNILLO 1 1
8 95817–08100 TORNILLO 1 1
9 1WS–2413Y–00 SOPORTE ACCESORIO DE DEPOSITO 1 1
10 90480–16003 TAPON 2 2
11 90387–06287 ESPACIADOR 2 2
12 90111–06084 TORNILLO 2 2
13 92012–06012 PERNO 4 4
14 1WS–13907–00 BOMBA DE COMBUSTIBLE COMPLETA 1 1
15 1WS–24491–00 SOPORTE BOMBA COMBUSTIBLE 1 1
16 1RC–24486–00 ANILLO O 1 1
17 91312–05010 TORNILLO 4 4
18 1WS–24602–00 TAPON COMPLETO 1 1
19 90110–05112 TORNILLO ALLEN 3 3
20 91317–05010 PERNO 1 1
21 1WS–13971–00 ANILLO DE ESPACIADOR 1 1
22 1WS–24318–00 TUBO DE REBOSAMIENTO 1 1
23 90467–090A2 PRESILLA 1 1
24 1WS–24312–00 TUBO 2 1 1
25 90467–090A2 PRESILLA 1 1
26 1WS–24135–00 GRAMPA 1 1 1
27 92017–06010 PERNO 1 1
37
FIG. 26 DEPOSITO DE COMBUSTIBLE
REF.
1XB6
1XB8
Nº
28 1WS–2419F–00 SOPORTE 1 1
29 90464–11007 BRIDA 1 1
30 90111–06119 TORNILLO 1 1
31 1WS–2414H–00 EQUILIBRIO, CUBIERTA 1 1
32 1WS–2414J–00 EQUILIBRIO, CUBIERTA 1 1
34 3D7–24188–00 MOLDURA DEPOSITO COMBUST. 2 2
38
FIG. 27 DEPOSITO DE COMBUSTIBLE 2
REF.
1XB6
1XB8
Nº
3 90480–01559 TAPON 1 1
4 1WS–2414P–00 EQUILIBRIO, CUBIERTA 1 1
5 1WS–2137W–00 CUBIERTA DE GUIA DE AIRE 1 1 1
7 90111–05003 TORNILLO 2 2
8 1WS–2836K–00 PANEL 1 1 1
10 90111–05003 TORNILLO 3 3
11 1WS–2837N–00 REJILLA, ADMISION DE AIRE 1 1 1
13 90110–06087 TORNILLO ALLEN 1 1
14 90480–17007 TAPON 1 1
15 90387–10107 ESPACIADOR 1 1
16 90269–07077 REMACHE 1 1
17 90111–05003 TORNILLO 5 5
18 90111–05037 TORNILLO 1 1
19 90202–05088 ARANDELA DE PLANA 1 1
20 90480–01558 TAPON 1 1
23 90480–01559 TAPON 1 1
24 1WS–2414R–00 EQUILIBRIO, CUBIERTA 1 1
25 1WS–2137X–00 CUBIERTA DE GUIA DE AIRE 2 1 1
27 90111–05003 TORNILLO 2 2
39
REF.
1XB6
1XB8
Nº
28 1WS–2836L–00 PANEL 2 1 1
29 90111–05003 TORNILLO 3 3
30 1WS–2837R–00 REJILLA, ADMISION DE AIRE 2 1 1
32 90110–06087 TORNILLO ALLEN 1 1
33 90480–17007 TAPON 1 1
34 90387–10107 ESPACIADOR 1 1
35 90269–07077 REMACHE 1 1
36 90111–05003 TORNILLO 5 5
37 90111–05037 TORNILLO 1 1
38 90202–05088 ARANDELA DE PLANA 1 1
39 90480–01558 TAPON 1 1
40 1WS–2171A–00–P4 CUBIERTA, TECHO 1 1 PARA DNMN
42 90269–07077 REMACHE 1 1
43 1WS–28219–00 CUBIERTA 1 1 1
44 90111–05007 TORNILLO 1 1
45 1XB–2464E–00 CUBIERTA DE TAPA 1 1
46 90111–05007 TORNILLO 2 2
47 90387–0611W ESPACIADOR 2 2
48 90480–13018 TAPON 2 2
50 90111–06084 TORNILLO 2 2
51 90387–07042 ESPACIADOR 2 2
52 90480–14452 TAPON 2 2
53 90269–07077 REMACHE 1 1
54 90480–01559 TAPON 2 2
40
REF.
1XB6
1XB8
Nº
55 1WS–2463E–00 SOPORTE TAPA 1 1
57 1XC–21568–00 ETIQUETA DE PRECAUCION 1 1
58 1RC–2413B–00 EMBLEMA 1 1
59 1RC–2413B–00 EMBLEMA 1 1
60 99246–00100 EMBLEMA, YAMAHA 1 1
61 99246–00100 EMBLEMA, YAMAHA 1 1
41
FIG. 28 ASIENTO
REF.
1XB6
1XB8
Nº
1 1WS–24710–00 ASIENTO SIMPLE COMPLETO 1 1
2 371–27114–00 .TOPE DE PUNTAL PRINCIPAL 4 4
3 1D7–27114–00 .TOPE DE PUNTAL PRINCIPAL 1 1
4 90480–14604 .TAPON 2 2
5 90387–07391 .ESPACIADOR 2 2
7 1WS–21131–00 SOPORTE 1 1
8 5RU–27114–00 TOPE DE PUNTAL PRINCIPAL 2 2
9 157–27114–00 TOPE DE PUNTAL PRINCIPAL 2 2
11 1WS–24750–00 ASIENTO TANDEM COMPLETO 1 1
12 278–27114–00 .TOPE DE PUNTAL PRINCIPAL 4 4
13 1WS–24780–00 CERRADURA SILLIN COMPLETO 1 1
14 95702–06500 TUERCA DE BRIDA 2 2
15 1WS–2478E–00 CABLE 1 1
16 2TV–W2470–00 JUEGO DE ROTOR 1 1
17 23P–2117K–00 SOPORTE DE CERRADURA 1 1
19 14B–28164–00 WRENCH, HEXAGON 8 1 1
20 2H7–28151–00 TORNILLO DE TIRADOR PRI.FIJACI 1 1
21 137–28152–00 CONDUCTOR 1 1
22 23P–28164–00 WRENCH, HEXAGON 8 1 1
23 1WS–28100–00 JUEGO DE HERRAMIENTAS 1 1
24 2S3–21398–00 COLGADOR DE CASCO 1 1
25 4KG–28186–10 SACO PLASTICO 1 1
26 1WS–28199–F1 MANUAL DEL PROPRIETARIO 1 1
1WS–28199–G1 MANUAL DEL PROPRIETARIO 1 1
42
FIG. 28 ASIENTO
REF.
1XB6
1XB8
Nº
26 1WS–28199–H1 MANUAL DEL PROPRIETARIO 1 1
1WS–28199–S1 MANUAL DEL PROPRIETARIO 1 1
43
FIG. 29 RUEDA DELANTERA
REF.
1XB6
1XB8
Nº
1 1XB–25168–00–P0 RUEDA FUNDIDA DELANTERA 1 1 DPBM15 PARA DNMN
2 90560–17356 SEPARADOR 1 1
3 93306–20352 COJINETE 2 2
4 93102–25017 SELLO ACEITE 2 2
5 * NEUMATICO (120/70ZR17M/C 58W) 1 1 UR LM MICHELIN
94112–17121 NEUMATICO (120/70ZR17M/C 58W) 1 1 UR BRIDGESTONE
6 93900–00030 VALVULA DE ARO (TR412) 1 1 TAIHEIYO
7 5MT–25398–00 BALANCEADOR DE RUEDA (10G) 1 1 UN
5MT–25398–10 BALANCEADOR DE RUEDA (20G) 1 1 UN
8 90387–17017 ESPACIADOR 2 2
9 3MA–25181–10 EJE DE LA RUEDA 1 1
44
FIG. 30 CALIBRE FRENO DELANTERA
REF.
1XB6
1XB8
Nº
1 1WS–2581T–00 DISCO DE FRENO 2 2
2 90109–064G6 PERNO 10 10
3 2DR–2517G–00 ROTOR DE SENSOR 1 1
5 1WS–2580T–00 CALIBRE COMPLETO (IZQUIERDO) 1 1
6 4SV–25802–10 .PISTON COMPLETO PINZA 1 1
7 3GM–25803–10 ..JUEGO DE RETENES DE PINZA 1 1
9 3MA–25803–10 ..JUEGO DE RETENES DE PINZA 1 1
10 1WS–25805–00 .JUEGO DE COJIN DE FRENO 1 1
11 13S–25919–00 .SOPORTE DE PASTILLAS 1 1
12 4SV–25924–00 .PASADOR 1 1
13 3GM–25925–00 .PRESILLA 2 2
14 1J3–25824–00 .TORNILLO DE RESPIRADERO 1 1
15 306–25825–01 .TAPA 1 1
16 90105–10638 TORNILLO 2 2
17 1XB–2580U–00 CALIBRE COMPLETO (DERECHO) 1 1
19 3GM–25803–10 ..JUEGO DE RETENES DE PINZA 1 1
21 3MA–25803–10 ..JUEGO DE RETENES DE PINZA 1 1
22 1WS–25805–00 .JUEGO DE COJIN DE FRENO 1 1
23 13S–25919–00 .SOPORTE DE PASTILLAS 1 1
24 4SV–25924–00 .PASADOR 1 1
25 3GM–25925–00 .PRESILLA 2 2
26 5VS–25824–00 .TORNILLO DE RESPIRADERO 1 1
27 306–25825–01 .TAPA 1 1
45
FIG. 30 CALIBRE FRENO DELANTERA
REF.
1XB6
1XB8
Nº
28 5VS–25975–00 .AMORTIGUADOR BUJE 1 1
29 90105–10638 TORNILLO 2 2
46
FIG. 31 RUEDA TRASERA
REF.
1XB6
1XB8
Nº
1 2DR–25338–00–P0 RUEDA FUNDIDA TRASERA 1 1 DPBM15 PARA DNMN
2 93306–20480 COJINETE 1 1
3 93102–28022 SELLO ACEITE 1 1
4 93306–00416 COJINETE 1 1
5 1D7–25317–00 ESPACIADOR DE COJINETE 1 1
6 5SL–25364–00 AMORTIGUADOR 6 6
7 94118–17079 NEUMATICO (180/55ZR17 M/C 73W) 1 1 UR LM MICHELIN
94118–17080 NEUMATICO (180/55ZR17 M/C 73W) 1 1 UR BRIDGESTONE
8 93900–00030 VALVULA DE ARO (TR412) 1 1 TAIHEIYO
9 5MT–25398–00 BALANCEADOR DE RUEDA (10G) 1 1 UN
10 5JJ–25366–00 EMBRAGUE DE MASA 1 1
11 93306–205B5 COJINETE 1 1
12 1RC–25383–00 COLLAR DE RUEDA 1 1
13 93106–40013 SELLO ACEITE 1 1
14 1WS–25443–00 CORONA (43T) 1 1
15 90116–10048 ESPARRAGO 6 6
17 1WS–2537W–00 SOPORTE 1 1 1
18 90201–10045 ARANDELA PLANA 6 6
19 90387–20036 ESPACIADOR 1 1
20 90387–20035 ESPACIADOR 1 1
21 94582–40108 CADENA (DID 525VAZ-108LE) 1 1
22 1WS–25388–00 TIRADOR DE CADENA 1 2 2
23 1WS–22174–00 EXTREMO 1 1 1
24 1WS–22175–00 EXTREMO 1 1 1
47
FIG. 31 RUEDA TRASERA
REF.
1XB6
1XB8
Nº
25 95302–08600 TUERCA 4 4
26 92902–08600 ARANDELA 2 2
27 4FN–22141–00 EJE DEL BARCULANTE 1 1
29 90201–18021 ARANDELA PLANA 1 1
30 1WS–2538D–00 BRAZO EJE CUBIERTA 1 1 1
31 1WS–2538N–00 BRAZO EJE CUBIERTA 2 1 1
48
FIG. 32 CALIBRE FRENO TRASERA
REF.
1XB6
1XB8
Nº
1 1WS–2582W–00 DISCO DE FRENO TRASEROS 2 1 1
2 90109–08045 PERNO 5 5
3 2DR–2517G–00 ROTOR DE SENSOR 1 1
5 2DR–2580W–00 CALIBRE COMPLETO TRASEROS 2 1 1
6 5SL–25802–00 .PISTON COMPLETO PINZA 1 1
7 5SL–25803–00 ..JUEGO DE RETENES DE PINZA 1 1
8 5SL–25917–00 .FUNDA DE CALIBRE 1 1
9 5SL–25838–00 .CASQUILLO DE CALIBRE 1 1
10 5SL–25919–00 .SOPORTE DE PASTILLAS 1 1
11 5SL–25914–00 .PASADOR 1 1
12 2DR–25921–50 .MENSULA DE SOPORTE 1 1
13 3JD–25917–00 .FUNDA DE CALIBRE 1 1
14 5VX–25806–00 .JUEGO DE PASTILLAS DE FRENO 2 1 1
15 8CR–25924–00 .PASADOR 1 1
16 5DH–25916–00 .TAPON 1 1
17 1RC–25926–00 .PERNO 1 1
18 8CR–25824–00 .TORNILLO DE RESPIRADERO 1 1
19 1UY–25825–51 .TAPA 1 1
20 5SL–25827–00 .CUNA DE CALIBRE 1 1
49
FIG. 33 MANILLAR & CABLE
REF.
1XB6
1XB8
Nº
1 1WS–26111–00 MANUBRIO 1 1
2 4YR–26241–02 EMPUNADURA (IZQUIERDO) 1 1
3 1WS–26240–00 EMPUNADURA COMPLETA 1 1
4 5RU–26246–00 EXTREMO DE EMPUNADURA 2 2
5 1WS–26301–00 CABLE DE ACELERADOR COMPLETO 1 1
6 90468–15139 PRESILLA 1 1
7 39P–2627E–00 GRAMPA 1 1
8 1WS–26281–00 TAPA DE EMPUNADURA SUPERIOR 1 1
9 1WS–26282–00 TAPA, EMPUNADURA INFERIOR 1 1
10 91317–05040 PERNO 2 2
11 1WS–26335–00 CABLE DE EMBRAGUE 1 1
12 1WS–2612E–00 SOPORTE 1 1
13 90111–06101 TORNILLO 1 1
14 1RC–26280–00 ESPEJO COMPLETO (IZQUIERDO) 1 1
15 1RC–26290–00 ESPEJO COMPLETO (DERECHO) 1 1
50
FIG. 34 CILINDRO MAESTRO DELANTERO
REF.
1XB6
1XB8
Nº
1 1XB–2580A–00 CILINDRO MAESTRO SUB COMPLET 2 1 1
2 1WS–25807–00 .JUEGO DE CILINDRO MAESTRO 1 1
3 5VS–25852–00 .TAPA DE TANQUE DE RESERVA 1 1
4 5VS–25855–00 .BUJE DE DIAFRAGMA 1 1
5 20S–25854–00 .EMPAQUE,DIAFRAGMA 1 1
6 5VS–2589H–00 .TORNILLO 2 2
7 5VS–2589F–00 PERNO DE PALANCA 1 1
8 95617–06100 TUERCA U 1 1
9 5VS–83922–00 PALANCA 2 1 1
10 5VS–26332–00 PERNO 2 2
11 5VS–25867–00 SOPORTE DE CILINDRO MAESTRO 1 1
12 1HP–83980–01 INTERRUP. DE PARADA DELANTERO 1 1
13 98502–04012 TORNILLO 1 1
14 92902–04100 ARANDELA 1 1
15 92902–04600 ARANDELA 1 1
16 1XB–25872–00 MANGUERA DE FRENO 1 1 1
17 1XB–25873–00 MANGUERA DE FRENO 2 1 1
18 1XB–25874–00 MANGUERA DE FRENO 1 1
19 90401–10172 PERNO DE UNION 4 4
20 90401–10042 PERNO DE UNION 1 1
21 90430–10005 JUNTA 11 11
22 1XB–25875–00 SOPORTE DE MANGUERA FRENO 1 1 1
23 1WS–2587A–00 SOPORTE DE MANGUERA FRENO 1 1
24 1XB–25876–00 SOPORTE DE MANGUERA FRENO 2 1 1
25 1XB–25886–00 SOPORTE DE MANGUERA FRENO 1 1
26 90464–18002 BRIDA 2 2
27 1WS–26296–00 SOPORTE 1 1
51
FIG. 34 CILINDRO MAESTRO DELANTERO
REF.
1XB6
1XB8
Nº
28 97027–05012 PERNO 1 1
29 92907–05600 ARANDELA 1 1
52
FIG. 35 SOPORTE & APOYAPIE
REF.
1XB6
1XB8
Nº
1 1WS–274A3–00 SOPORTE, ADAPTADOR 1 1 1
2 90111–10060 TORNILLO 2 2
3 1WS–27311–00 PUNTAL LATERAL 1 1
4 90101–10025 TORNILLO 1 1
6 90387–10050 ESPACIADOR 1 1
10 5VX–27351–00 GUIA DE PUNTAL LATERAL 1 1
11 5VX–27315–00 CONEXION DE PUNTAL LATERAL 1 1
12 1WS–82566–00 INTERRUPTOR 1 1
13 1WS–2419A–00 SOSTEN 1 1
14 90110–05071 TORNILLO ALLEN 2 2
16 1WS–27321–00 SOPORTE DE PUNTAL LATERAL 1 1
17 90111–10058 TORNILLO 2 2
18 1WS–27451–00 APOYAPIE 1 1
19 91701–08040 PASADOR DE ABRAZADERA 1 1
20 91402–25015 CHAVETA 1 1
22 3YX–27413–00 CUBIERTA DE APOYAPIE 1 1
23 90157–05025 TORNILLO CABEZA CONICA PLANA 2 2
24 90109–086F8 PERNO 1 1
25 1WS–27442–00 SOPORTE 2 1 1
26 36Y–27414–00 AMORTIGUADOR DE APOYAPIE 2 2
27 5VX–27114–00 TOPE DE PUNTAL PRINCIPAL 1 1
53
REF.
1XB6
1XB8
Nº
28 5VX–18116–00 VARILLA DE CONECTOR 1 1 1
29 5VX–18154–00 CUBIERTA GUARDAPOLVO 1 1
30 1WS–27445–00 PLACE 1 1 1
31 92014–06012 PERNO 2 2
32 1WS–18110–00 PEDAL DE CAMBIO COMPLETO 1 1
33 1WS–18113–00 .FUNDA DEL PEDAL DEL CAMBIO 1 1
34 90201–12051 ARANDELA PLANA 1 1
35 90206–12005 ARANDELA ONDULADA 1 1
36 4BP–27434–01 PERNO 1 1
37 90201–08053 ARANDELA PLANA 1 1
38 5A8–18115–00 VARILLA DEL CAMBIO 1 1
39 90170–06026 TUERCA 1 1
40 95314–06700 TUERCA 1 1
41 90110–08071 TORNILLO ALLEN 2 2
43 90387–06372 ESPACIADOR 1 1
44 90111–06098 TORNILLO 1 1
45 1WS–27453–00 CUBIERTA APOYAPIE 1 1 1
46 90480–14003 TAPON 2 2
47 90387–06057 ESPACIADOR 2 2
49 1WS–27425–00 SOPORTE DE APOYAPIE 2 1 1
51 90269–08008 REMACHE 1 1
52 1WS–27475–00–P0 TAPA 1 1 1 MBL2 PARA DNMN
53 3VR–27431–01 APOYAPIE POSTERIOR 1 1 1
54 1WS–2741L–00 MENSULA 4 1 1
54
REF.
1XB6
1XB8
Nº
56 93501–04011 BOLA 1 1
57 5VX–27437–00 ARANDELA ESPECIAL 1 1
58 91702–08040 PASADOR DE ADRAZADERA 1 1
59 91401–25015 CHAVETA 1 1
60 90110–08231 TORNILLO ALLEN 2 2
55
FIG. 36 SOPORTE & APOYAPIE 2
REF.
1XB6
1XB8
Nº
1 1WS–274A4–00 SOPORTE,ADAPTADOR 2 1 1
2 90111–10060 TORNILLO 2 2
3 90465–08045 BRIDA 1 1
4 95022–06010 PERNO, DE BRIDA 1 1
5 1WS–27461–00 APOYAPIE 1 1
6 91701–08040 PASADOR DE ABRAZADERA 1 1
7 91402–25015 CHAVETA 1 1
9 3YX–27413–00 CUBIERTA DE APOYAPIE 1 1
10 90157–05025 TORNILLO CABEZA CONICA PLANA 2 2
11 90109–086F8 PERNO 1 1
12 1WS–27443–00 SOPORTE 3 1 1
13 36Y–27414–00 AMORTIGUADOR DE APOYAPIE 2 2
14 5VX–27114–00 TOPE DE PUNTAL PRINCIPAL 1 1
15 1WS–27446–00 PLACE 2 1 1
16 92014–08025 PERNO 2 2
17 1WS–27211–00 PEDAL DE FRENO 1 1
18 1WS–18113–00 FUNDA DEL PEDAL DEL CAMBIO 1 1
19 90206–12005 ARANDELA ONDULADA 1 1
20 4BP–27434–01 PERNO 1 1
21 90201–12051 ARANDELA PLANA 1 1
22 90201–08053 ARANDELA PLANA 1 1
24 90110–08071 TORNILLO ALLEN 2 2
26 1WS–27463–00 CUBIERTA APOYAPIE 2 1 1
27 90480–14003 TAPON 2 2
56
FIG. 36 SOPORTE & APOYAPIE 2
REF.
1XB6
1XB8
Nº
28 90387–06057 ESPACIADOR 2 2
30 1WS–27425–00 SOPORTE DE APOYAPIE 2 1 1
32 90269–08008 REMACHE 1 1
33 1WS–27475–00–P0 TAPA 1 1 1 MBL2 PARA DNMN
34 3VR–27441–01 APOYAPIE POSTERIOR 2 1 1
35 1WS–2742L–00 MENSULA 5 1 1
37 93501–04011 BOLA 1 1
38 5VX–27437–00 ARANDELA ESPECIAL 1 1
39 91702–08040 PASADOR DE ADRAZADERA 1 1
40 91401–25015 CHAVETA 1 1
41 90110–08231 TORNILLO ALLEN 2 2
57
FIG. 37 CILINDRO MAESTRO TRASERO
REF.
1XB6
1XB8
Nº
1 4P5–2583V–00 CILINDRO, MAESTRO TRASERO 1 1
2 5VX–W0042–51 .JUEGO DE CILINDRO MAESTRO 1 1
3 2D1–2582A–00 .CONECTOR 1 1
4 4BP–2585F–01 .ANILLO O 1 1
5 4BP–27222–02 .UNION 1 1
6 90170–08010 .TUERCA 2 2
7 90240–08005 PASADOR CON HOYO 1 1
9 91401–20012 CHAVETA 1 1
10 14B–25894–00 TANQUE DE RESERVA 1 1
11 2C0–25852–00 TAPA DE TANQUE DE RESERVA 1 1
12 2VN–25854–00 EMPAQUE,DIAFRAGMA 1 1
13 2VN–25855–00 BUJE DE DIAFRAGMA 1 1
14 90387–05028 ESPACIADOR 1 1
15 2C0–26326–00 TAPON PROTECTOR 1 1
16 90467–11044 PRESILLA 2 2
17 1WS–25895–00 MANGUERA DE TANQUE DE RESERVA 1 1
18 1WS–82530–00 INTERRUPTOR DE PARADA COMPLETO 1 1
19 1WS–2144G–00 SOPORTE DE INTERRUPTOR 1 1
20 1WS–2582E–00 SOSTEN, TANQUE DE RESERVA 1 1
21 95707–05500 TUERCA DE BRIDA 1 1
22 90464–17008 BRIDA 1 1
23 1XB–2584D–00 MANGUERA DE FRENO 1 1
24 1XB–2584E–00 MANGUERA DE FRENO 5 1 1
25 90464–07014 BRIDA 1 1
26 90464–07009 BRIDA 1 1
27 90105–06148 TORNILLO 1 1
58
FIG. 37 CILINDRO MAESTRO TRASERO
REF.
1XB6
1XB8
Nº
28 90401–10020 PERNO DE UNION 2 2
29 90430–10005 JUNTA 4 4
30 90401–10172 PERNO DE UNION 2 2
31 90430–10005 JUNTA 4 4
32 92012–06010 PERNO 1 1
59
FIG. 38 GENERADOR
REF.
1XB6
1XB8
Nº
1 1WS–81410–00 ESTATOR COMPLETO 1 1
2 1WS–81450–00 ROTOR COMPLETO 1 1
5 1WS–15484–00 GRAMPA 2 1 1
60
FIG. 39 MOTOR DE ARRANQUE
REF.
1XB6
1XB8
Nº
1 1WS–81890–00 MOTOR DE ARRANQUE COMPLETO 1 1
2 4B5–81844–00 .EMPAQUE 2 2
3 1FK–81847–00 .ANILLO GOMA 1 1
4 4XV–8182A–00 .TUERCA 1 1
5 4B5–81871–00 .TAPA 1 1
6 18P–81826–00 .PERNO 2 2
7 18P–81801–00 .JUEGO DE ESCOBILLA 1 1
8 1WS–81815–00 CABLE, MOTOR DE ARRANQUE 1 1
9 4XV–8182A–00 TUERCA 1 1
10 91312–06025 TORNILLO 2 2
61
FIG. 40 LUZ DE DESTELLADOR
REF.
1XB6
1XB8
Nº
1 1WS–83310–00 DESTELLADOR DE LUZ DELANT. 1 1
2 1KB–83311–00 .BOMBILLA (12V-10W) 1 1
3 1KB–8333A–00 .LENTES COMPLETO 1 1 1
4 3D9–H3333–10 .TORNILLO ACCESORIO DE LENTE 1 1
5 1WS–83320–00 DESTELLADOR DE LUZ DELANT. 1 1
6 1KB–83311–00 .BOMBILLA (12V-10W) 1 1
9 3D7–83318–10 SOPORTE DE DESTELLADOR 1 2 2
10 1WS–83330–00 DESTELLADOR DE LUZ TRAS.COMPL. 1 1
11 1KB–83311–00 .BOMBILLA (12V-10W) 1 1
14 1WS–83340–00 DESTELLADOR DE LUZ TRAS.COMPL. 1 1
15 1KB–83311–00 .BOMBILLA (12V-10W) 1 1
18 3D7–83318–10 SOPORTE DE DESTELLADOR 1 2 2
62
FIG. 41 MEDIDOR
REF.
1XB6
1XB8
Nº
1 1XB–83500–00 METRO COMPLETO 1 1
2 90164–05001 TORNILLO ROSCA HEMBRA 3 3
3 5PS–83513–00 AMORTIGUADOR 3 3
4 1WS–83559–00 CUBIERTA DE MEDIDOR 1 1
5 90111–06095 TORNILLO 2 2
6 90338–06018 TAPON 2 2
63
FIG. 42 FARO DELANTERO
REF.
1XB6
1XB8
Nº
1 1WS–84300–00 FARO DELANTERO COMPLETO 1 1
2 1RC–84397–00 .CUBIERTA DE ENCASTRE 1 1
3 1RC–84314–00 .BOMBILLA (12V-60/55W) 1 1
4 1RC–84347–00 .BOMBILLA (12V-W5W) 1 1
5 1WS–84526–00 .TORNILLO 1 1
6 1WS–8454J–00 .GRAMPA DE CORDON 1 1
7 1WS–84359–00 .CABLE DE FARO DELANTERO 1 1
8 90111–06038 TORNILLO 2 2
9 90387–06170 ESPACIADOR 2 2
10 90183–061A7 TUERCA DE RESORTE 2 2
11 1WS–84118–00–P0 APOYO DE FARO DELANTERO 1 1 1 MBL2 PARA DNMN
13 1WS–84119–00–P0 APOYO DE FARO DELANTERO 2 1 1 MBL2 PARA DNMN
15 90111–06150 TORNILLO 2 2
16 90387–06301 ESPACIADOR 2 2
17 90480–12015 TAPON 2 2
18 90201–06029 ARANDELA PLANA 2 2
19 1WS–84396–00 CUBIERTA 1 1
20 1WS–28376–00 ADORNO 1 1
22 90179–06072 TUERCA 4 4
64
FIG. 43 LUZ DE COLA
REF.
1XB6
1XB8
Nº
1 1WS–84710–00 UNIDAD FARO TRASERO COMPL. 1 1
2 90111–06137 TORNILLO 2 2
3 90387–067V1 ESPACIADOR 2 2
4 90480–13001 TAPON 2 2
6 90480–10003 TAPON 2 2
7 1WS–84740–00 LUZ DE LICENCIA COMPLETA 1 1
8 1WS–84547–00 .CABLE DE LUZ DE LICENCIA 1 1
9 1TP–84347–00 .BOMBILLA (W5W-12V) 1 1
11 90387–05042 ESPACIADOR 2 2
12 90480–12023 TAPON 2 2
13 90201–054K4 ARANDELA PLANA 2 2
65
FIG. 44 INTERRUPTOR DE MANILLAR&PALANC
REF.
1XB6
1XB8
Nº
1 1B3–82911–00 SOPORTE DE LEVA 1 1 1
2 5EB–83912–03 PALANCA 1 1 1
3 2C0–83945–00 PERNO DE PALANCA 1 1
5 95027–06020 PERNO, DE BRIDA 1 1
6 5LV–83951–00 PERNO DE CABLE DE AJUSTE 1 1
7 4XV–83929–00 PLACA DE RESORTE 1 1
8 3YX–82917–01 INTERRUPTOR 1 1
9 98704–03020 TORNILLO DE CABEZA PLANA 1 1
10 98507–04010 TORNILLO DE CABEZA PLANA 1 1
11 5JJ–83913–00 COLLAR DE PALANCA 1 1 1
12 1WS–83972–00 INTERRUPTOR DE MANIJA 4 1 1
13 98507–04025 .TORNILLO DE CABEZA PLANA 2 2
14 90464–13073 BRIDA 1 1
15 1WS–83975–00 INTERRUPTOR DE MANIJA 2 1 1
18 90464–13073 BRIDA 1 1
66
FIG. 45 EQUIPO ELECTRICO 1
REF.
1XB6
1XB8
Nº
1 5VY–82100–00 BATERIA COMPLETA(YUASA YTZ10S) 1 1
2 1WS–82131–00 TIRANTE DE BATERIA 1 1
3 1XC–81940–00 ARRANCADOR RELEVO (RC19-089B) 1 1
4 1AE–82151–00 .FUSIBLE (30A-BL) 2 2
5 5SL–82119–10 CUBIERTA DE CABLE CONDUCTOR 1 1
6 95022–06008 PERNO, DE BRIDA 2 2
7 1XB–82115–00 CABLE CONDUCTOR POSITIVO 1 1
8 1XB–82590–00 CONJUNTO DE CABLES 1 1
9 5JJ–82151–80 .FUSIBLE (2A-BL) 2 2
10 5JJ–82151–00 .FUSIBLE (7.5A-BL) 4 4
11 5JJ–82151–30 .FUSIBLE (10A-BL) 5 5
12 5JJ–82151–10 .FUSIBLE (15A-BL) 2 2
13 5JJ–82151–20 .FUSIBLE (20A-BL) 2 2
14 5JJ–82151–60 .FUSIBLE (30A-BL) 2 2
15 91380–06012 PERNO 1 1
16 90464–20191 BRIDA 1 1
17 90464–18007 BRIDA 1 1
18 90464–14010 BRIDA 2 2
19 90464–18011 BRIDA 1 1
20 1UA–82591–00 BANDA 2 2
21 90464–65001 BRIDA 1 1
22 1WS–81916–00 CUBIERTA DE TERMINAL 1 1
23 90464–14010 BRIDA 1 1
24 90464–13073 BRIDA 1 1
25 90464–14010 BRIDA 1 1
26 27D–81960–00 RECTIFICADOR Y REGULADOR 1 1
27 90183–060A6 TUERCA DE RESORTE 2 2
67
REF.
1XB6
1XB8
Nº
28 95022–06020 PERNO, DE BRIDA 2 2
29 5VK–81950–50 RELE COMPLETO (G8R-30Y-V5) 1 1
30 1WS–8246B–00 CUBIERTA 1 1 1
31 1TP–81950–00 RELE COMPLETO (1TP-00) 2 2
32 5EA–81952–00 .SOSTEN DE RELE 1 1
33 5PS–82576–01 SENSOR ANGULO DE INCLINATION 1 1
34 91312–04025 TORNILLO 2 2
35 90201–04030 ARANDELA PLANA 2 2
68
REF.
1XB6
1XB8
Nº
1 1WS–82380–00 SENSOR DE PRESION 1 1
2 91312–05020 TORNILLO 1 1
3 1WS–82310–00 BOBINA DE ENCENDIDO COMPLETA 2 2
4 1WS–82540–00 INTERRUPTOR NEUTRAL COMPL 1 1
5 93210–21001 ANILLO O 1 1
7 4P9–83591–00 UNIDAD TERMOSTATO 1 1
8 90430–10004 JUNTA 1 1
9 1WS–82504–00 INTERRUPTOR PRESION DE ACEITE 1 1
10 1WS–81315–00 CABLE CONDUCTOR COMPLETO 1 1
11 3P6–15399–00 TAPON CIEGO 1 1
12 93210–15566 .ANILLO O 1 1
13 91312–06016 TORNILLO 1 1
14 1XB–82309–00 CABLE SUBCONDUCTOR 1 1
15 1XB–W8250–00 JUEGO DE INMOVILIZADOR 1 1
16 1XB–8591A–00 .UNIDAD CONTROL 1 1
17 1WS–8255P–00 .UNIDAD INMOVILIZADORA 1 1
18 5SL–82113–01 .TORNILLO 2 2
19 5SL–82511–08 BLANK KEY 1 1 AP
20 90109–08195 PERNO 2 2
21 90465–13M24 BRIDA 1 1
22 1WS–81662–00 CUBIERTA DE CONECTOR 1 1
23 3XV–83350–21 RELE DE DESTELLADOR COMPL. 1 1
24 1WS–83371–00 BOCINA 1 1
25 95707–06500 TUERCA DE BRIDA 1 1
69
REF.
1XB6
1XB8
Nº
1 1XB–85930–09 UNIDAD DE HIDRAULICA 1 1
2 90480–14229 TAPON 3 3
3 90387–06M60 ESPACIADOR 3 3
4 95817–06020 TORNILLO 3 3
6 92014–06014 PERNO 1 1
7 90464–12013 BRIDA 3 3
8 90464–04001 BRIDA 2 2
9 1XB–23591–00 PASADOR 1 1
10 1XB–23592–00 PASADOR 2 1 1
12 92014–06014 PERNO 1 1
13 90464–10233 BRIDA 3 3
14 90464–30009 BRIDA 1 1
15 1XB–2175T–00 SOPORTE 1 1 1
16 92012–06040 PERNO 1 1
17 92012–06016 PERNO 1 1
70
INDICE NUMERICO
REF. REF. REF. REF. REF. REF.

CODIGO Nº CODIGO Nº CODIGO Nº CODIGO Nº CODIGO Nº CODIGO Nº
Nº Nº Nº Nº Nº Nº
1WS–11101–09 1 – 1 1HX–12168–K1 3 – 10 5GJ–12675–00 6 – 4 1WS–15100–09 12 – 1 1WS–17401–00 16 – 1 1WS–2161J–00 19 – 34

5VY–1111G–00 1 – 11 1HX–12168–M1 3 – 10 5VY–13117–10 7 – 10 1WS–15128–00 12 – 23 1WS–17421–00 16 – 17 1WS–21629–00 20 – 30
1 – 22 1HX–12168–R1 3 – 10 1WS–13300–00 7 – 1 5EB–15155–00 12 – 2 1WS–17446–00 16 – 15 1WS–21639–00 20 – 21
4D9–11133–10 1 – 2 1HX–12168–U1 3 – 10 1WS–13400–00 8 – 5 1WS–15156–00 12 – 13 1WS–17460–00 16 – 40 1WS–2163A–00 20 – 39
1WS–11165–00 1 – 17 1HX–12168–W1 3 – 10 1WS–13410–00 7 – 7 1WS–15189–00 12 – 10 1WS–18101–00 18 – 4 1WS–21642–00 20 – 28
1WS–11166–00 9 – 31 1HX–12168–Y1 3 – 10 1WS–13414–00 8 – 8 36Y–15189–00 12 – 8 1WS–18110–00 35 – 32 1WS–2164F–00 20 – 33
1WS–11169–00 1 – 18 1HX–12169–11 3 – 10 5GH–13440–50 8 – 4 3KJ–15337–00 19 – 27 1WS–18112–00 18 – 14 1WS–2164G–00 20 – 34
1WS–11181–00 1 – 14 1HX–12169–31 3 – 10 1WS–13470–00 8 – 1 2H7–15361–00 12 – 7 1WS–18113–00 35 – 33 1WS–21650–00 22 – 25
1WS–11190–00 1 – 16 1HX–12169–50 3 – 10 1XD–13475–00 8 – 2 3F9–15362–10 13 – 19 36 – 18 1WS–21651–00 21 – 29
1WS–11193–00 1 – 20 1HX–12169–70 3 – 10 1WS–13542–00 9 – 4 1WS–15377–00 13 – 11 5A8–18115–00 35 – 38 1TP–21668–00 22 – 33
214–11198–01 8 – 7 1HX–12169–90 3 – 10 1WS–13545–00 9 – 27 3P6–15399–00 46 – 11 5VX–18116–00 35 – 28 1WS–21682–00 20 – 35
1WS–11400–00 2 – 1 1HX–12169–E0 3 – 10 1WS–13546–00 9 – 28 1WS–15411–00 13 – 1 1D7–18127–00 18 – 3 1WS–21711–00–P1 21 – 1
2S3–11413–00 2 – 22 1HX–12169–G0 3 – 10 1WS–13547–00 9 – 29 1WS–15416–00 12 – 20 1WS–18140–00 18 – 7 1WS–2171A–00–P4 27 – 40
2S3–11413–10 2 – 22 1HX–12169–J0 3 – 10 8FP–13556–00 10 – 2 1WS–15418–00 13 – 10 5VX–18154–00 35 – 29 1WS–2171E–00–P1 21 – 19
2S3–11413–20 2 – 22 1HX–12169–L0 3 – 10 8GL–13571–00 10 – 11 1WS–15421–00 5 – 22 2C0–18175–00 18 – 6 1WS–2171J–00 21 – 25
2S3–11413–30 2 – 22 1HX–12169–N0 3 – 10 8HG–13573–00 10 – 10 1WS–15441–00 13 – 17 1WS–18511–00 17 – 4 1WS–2171K–00 21 – 27
2S3–11413–40 2 – 22 1HX–12169–T0 3 – 10 1WS–13635–00 9 – 1 1WS–15451–00 13 – 6 1WS–18512–00 17 – 5 1WS–2171X–00–P1 21 – 21
3GM–11416–00 2 – 5 1WS–12170–00 4 – 1 1WS–13750–00 10 – 1 1WS–15456–00 12 – 21 1WS–18513–00 17 – 6 1WS–21721–00–P1 21 – 10
3GM–11416–10 2 – 5 2C0–12176–00 4 – 2 1WS–13750–20 10 – 1 1WS–15461–00 13 – 13 20S–18535–00 17 – 7 1WS–2172W–00 6 – 20
3GM–11416–20 2 – 5 1WS–12180–00 4 – 4 1WS–13761–00 10 – 3 1WS–15484–00 38 – 5 1WS–18536–00 17 – 8 1WS–21731–00 6 – 28
3GM–11416–A0 2 – 5 1WS–12181–00 4 – 5 1WS–13898–00 7 – 5 1WS–15512–00 14 – 5 1WS–18540–00 17 – 1 1WS–21741–00 6 – 29
3GM–11416–B0 2 – 5 1WS–12210–01 4 – 13 1WS–13907–00 26 – 14 1WS–15515–00 14 – 1 3D7–18542–00 17 – 2 1WS–21746–00 20 – 36
1WS–11454–00 2 – 14 1WS–12213–00 4 – 16 1WS–13938–00 10 – 9 23P–15521–00 14 – 4 1WS–21110–50 19 – 1 1XB–2175T–00 47 – 15
1WS–11496–00 2 – 15 5SL–12214–00 4 – 15 1WS–13971–00 26 – 21 1WS–15560–00 14 – 6 1WS–2112B–00 19 – 16 1WS–2175U–00 19 – 36
1WS–11500–00 2 – 13 5EL–12228–00 4 – 14 5PS–1410H–00 9 – 22 1WS–15590–00 14 – 2 1WS–21131–00 28 – 7 1WS–21781–40 21 – 31
1WS–11531–00 2 – 16 1WS–12247–00 4 – 9 5PS–14147–00 10 – 4 1WS–16150–00 15 – 1 1WS–21158–00 19 – 24 1WS–21782–40 21 – 32
1WS–11533–00 2 – 19 1WS–12251–00 4 – 18 8CC–14216–10 10 – 13 363–16154–00 15 – 2 23P–2117K–00 28 – 17 1WS–21816–00 6 – 18
1WS–11603–00 2 – 7 1WS–12252–00 4 – 19 54P–14243–00 10 – 8 15 – 13 1WS–2117N–00 19 – 18 26H–21828–00 6 – 14
1WS–11631–00 2 – 6 1WS–12257–00 4 – 10 1WS–14335–00 10 – 6 1WS–16181–00 15 – 11 1WS–2117R–00 19 – 38 1WS–21871–00 6 – 13
1WS–11633–00 2 – 8 1WS–12280–00 4 – 7 1WS–14401–00 9 – 5 5TG–16321–00 15 – 6 1WS–2117T–00 19 – 40 3P6–21875–00 6 – 16
1WS–11650–00 2 – 2 1PD–12288–00 4 – 11 1WS–14430–00 9 – 11 5VY–16321–00 15 – 4 1XB–21288–00 19 – 44 1WS–2191B–00 19 – 2
1RC–11654–00 2 – 3 1WS–12405–00 6 – 2 1WS–14430–20 9 – 11 5VY–16325–00 15 – 5 1WS–21315–00 19 – 9 1WS–21946–00 19 – 15
1RC–11656–00 2 – 4 1WS–12410–00 5 – 15 1WS–14437–00 9 – 12 1WS–16340–00 15 – 18 1WS–21316–00 19 – 10 1WS–22110–00 22 – 1
1RC–11656–10 2 – 4 1WS–12413–00 5 – 16 1WS–1443E–00 9 – 15 132–16346–00 18 – 2 4XV–21376–00 19 – 31 4FN–22141–00 31 – 27
1RC–11656–20 2 – 4 1WS–12422–00 5 – 34 1WS–14450–00 9 – 6 1WS–16350–00 15 – 7 1WS–2137W–00 27 – 5 1UY–22141–10 22 – 7
1RC–11656–30 2 – 4 5VK–12438–00 5 – 31 1WS–14452–00 9 – 7 1WS–16356–00 15 – 17 1WS–2137X–00 27 – 25 1WS–22151–00 22 – 24
1WS–12111–00 3 – 1 1WS–12439–00 5 – 35 1WS–14469–00 9 – 8 1WS–16371–00 15 – 3 2S3–21398–00 28 – 24 1WS–22174–00 31 – 23
1WS–12113–01 3 – 3 1WS–12450–00 5 – 29 1WS–14469–10 9 – 8 2D1–16382–00 5 – 23 20S–21445–01 11 – 7 1WS–22175–00 31 – 24
1WS–12114–00 3 – 4 1WS–12461–00 6 – 1 1WS–1446C–00 9 – 9 1WS–17121–00 16 – 13 1WS–2144G–00 37 – 19 1WS–2217A–00 22 – 10
1WS–12116–00 3 – 8 3D7–12462–00 6 – 8 1WS–1446C–10 9 – 9 1WS–17131–00 16 – 6 1WS–21511–00 20 – 1 1WS–2217F–00 22 – 18
1WS–12117–00 3 – 5 1WS–12469–00 5 – 12 5PS–1446E–00 9 – 25 1WS–17151–00 16 – 2 1WS–21512–00 20 – 9 1WS–22184–00 22 – 23
1WG–12118–00 3 – 6 1WS–12481–00 5 – 1 8HG–14534–00 10 – 12 1WS–17161–00 16 – 9 1WS–21513–00–P4 20 – 12 1WS–22189–00 22 – 17
4TE–12119–00 3 – 7 1WS–12482–00 5 – 3 3D7–14545–00 9 – 13 1WS–17211–00 16 – 38 1WS–21514–00–P4 20 – 15 30X–2219X–00 22 – 4
1WS–12121–00 3 – 2 1WS–12576–00 5 – 9 5PS–14552–00 9 – 24 1WS–17221–00 16 – 22 1XC–21568–00 27 – 57 1WS–22210–00 23 – 1
4C8–12153–09 3 – 9 1WS–12578–00 6 – 10 4XY–14568–00 6 – 19 1WS–17231–00 16 – 33 5VS–21578–10 20 – 18 1WS–23102–00 25 – 20
4C8–12153–10 3 – 9 1WS–12588–00 5 – 18 3YF–14613–01 11 – 5 1WS–17241–00 16 – 29 20 – 19 1XB–23103–00 25 – 1
1HX–12168–F0 3 – 10 1WS–12589–00 5 – 20 1WS–14708–00 11 – 2 1WS–17251–00 16 – 37 1WS–21612–00 20 – 10 1WS–23110–00 25 – 3
1HX–12168–H1 3 – 10 1WS–12671–00 6 – 3 1WS–14710–00 11 – 1 1WS–17261–00 16 – 26 1WS–2161G–00 20 – 37 25 – 22
71
INDICE NUMERICO

1D0–23111–00 25 – 17 1WS–24110–00 26 – 1 5MT–25398–20 31 – 9 1XB–25875–00 34 – 22 4BP–27222–02 37 – 5 1WS–2836L–00 27 – 28

25 – 36 1WS–24129–00–P4 27 – 1 1WS–25443–00 31 – 14 1XB–25876–00 34 – 24 1WS–27311–00 35 – 3 5DM–28371–00 19 – 29
3FW–23118–00 25 – 16 1WS–2412Y–00 26 – 2 4SV–25802–00 30 – 8 1WS–2587A–00 34 – 23 5VX–27315–00 35 – 11 1WS–28376–00 42 – 20
25 – 35 1WS–24135–00 26 – 26 30 – 20 1XB–25886–00 34 – 25 1WS–27321–00 35 – 16 1WS–2837N–00 27 – 11
1WS–23121–00 24 – 19 1WS–24139–00–P4 27 – 21 5SL–25802–00 32 – 6 1WS–25887–00 22 – 29 5VX–27351–00 35 – 10 1WS–2837R–00 27 – 30
4KM–23123–01 25 – 43 1RC–2413B–00 27 – 58 4SV–25802–10 30 – 6 1WS–2588F–00 22 – 30 3YX–27413–00 35 – 22 1WS–81315–00 46 – 10
4FM–23125–40 25 – 9 27 – 59 30 – 18 14B–25894–00 37 – 10 36 – 9 1WS–81410–00 38 – 1
25 – 28 1WS–2413Y–00 26 – 9 5SL–25803–00 32 – 7 1WS–25895–00 37 – 17 36Y–27414–00 35 – 26 1WS–81450–00 38 – 2
1WS–23126–00 25 – 21 3HA–24141–00 19 – 46 3GM–25803–10 30 – 7 5VS–2589F–00 34 – 7 36 – 13 1WS–81662–00 46 – 22
1WS–23131–00 24 – 21 1WS–2414H–00 26 – 31 30 – 19 5VS–2589H–00 34 – 6 1HX–27415–00 19 – 28 18P–81801–00 39 – 7
1XB–23136–00 25 – 2 1WS–2414J–00 26 – 32 3MA–25803–10 30 – 9 5SL–25914–00 32 – 11 19 – 39 1WS–81815–00 39 – 8
1WS–23141–00 25 – 14 1WS–2414P–00 27 – 4 30 – 21 5DH–25916–00 32 – 16 19 – 41 18P–81826–00 39 – 6
25 – 33 1WS–2414R–00 27 – 24 1WS–25805–00 30 – 10 3JD–25917–00 32 – 13 1WS–2741L–00 35 – 54 4XV–8182A–00 39 – 4
4EB–23144–00 25 – 5 1RC–2416B–00 21 – 33 30 – 22 5SL–25917–00 32 – 8 1WS–27425–00 35 – 49 39 – 9
25 – 24 3D7–24188–00 26 – 34 5VX–25806–00 32 – 14 13S–25919–00 30 – 11 36 – 30 4B5–81844–00 39 – 2
4EB–23145–01 25 – 7 1WS–2419A–00 35 – 13 1WS–25807–00 34 – 2 30 – 23 1WS–2742L–00 36 – 35 1FK–81847–00 39 – 3
25 – 26 1WS–2419F–00 26 – 28 1XB–2580A–00 34 – 1 5SL–25919–00 32 – 10 3VR–27431–01 35 – 53 4B5–81871–00 39 – 5
36Y–23146–10 25 – 8 1WS–24312–00 26 – 24 1WS–2580T–00 30 – 5 2DR–25921–50 32 – 12 4BP–27434–01 35 – 36 1WS–81890–00 39 – 1
25 – 27 1WS–24318–00 26 – 22 1XB–2580U–00 30 – 17 4SV–25924–00 30 – 12 36 – 20 1WS–81916–00 45 – 22
3EN–23149–50 25 – 15 3D7–24339–00 26 – 3 2DR–2580W–00 32 – 5 30 – 24 5VX–27437–00 35 – 57 1XC–81940–00 45 – 3
25 – 34 1RC–24486–00 26 – 16 1WS–2581T–00 30 – 1 8CR–25924–00 32 – 15 36 – 38 1TP–81950–00 45 – 31
26H–23156–00 25 – 6 1WS–24491–00 26 – 15 1J3–25824–00 30 – 14 3GM–25925–00 30 – 13 3VR–27441–01 36 – 34 5VK–81950–50 45 – 29
25 – 25 1WS–24602–00 26 – 18 5VS–25824–00 30 – 26 30 – 25 1WS–27442–00 35 – 25 5EA–81952–00 45 – 32
509–23158–L0 25 – 12 1WS–2463E–00 27 – 55 8CR–25824–00 32 – 18 1RC–25926–00 32 – 17 1WS–27443–00 36 – 12 27D–81960–00 45 – 26
25 – 31 1XB–2464E–00 27 – 45 306–25825–01 30 – 15 5VS–25975–00 30 – 28 1WS–27445–00 35 – 30 5VY–82100–00 45 – 1
1WS–23170–00 25 – 10 1WS–24710–00 28 – 1 30 – 27 1WS–26111–00 33 – 1 1WS–27446–00 36 – 15 5SL–82113–01 46 – 18
25 – 29 3UF–24737–00 19 – 26 1UY–25825–51 32 – 19 1WS–2612E–00 33 – 12 1WS–27451–00 35 – 18 1XB–82115–00 45 – 7
5BN–23171–00 25 – 4 1WS–24750–00 28 – 11 5SL–25827–00 32 – 20 1WS–26240–00 33 – 3 1WS–27453–00 35 – 45 5SL–82119–10 45 – 5
25 – 23 1WS–24780–00 28 – 13 5SL–25827–10 32 – 21 4YR–26241–02 33 – 2 1WS–27461–00 36 – 5 1WS–8212B–00 20 – 20
4YR–23173–00 25 – 11 1WS–2478E–00 28 – 15 5SL–25828–01 32 – 22 5RU–26246–00 33 – 4 1WS–27463–00 36 – 26 1WS–82131–00 45 – 2
25 – 30 1XB–25168–00–P0 29 – 1 2D1–2582A–00 37 – 3 39P–2627E–00 33 – 7 1WS–27475–00–P0 35 – 52 1AE–82151–00 45 – 4
278–23181–50 25 – 13 2DR–2517G–00 30 – 3 1WS–2582E–00 37 – 20 1RC–26280–00 33 – 14 36 – 33 5JJ–82151–00 45 – 10
25 – 32 32 – 3 1WS–2582W–00 32 – 1 1WS–26281–00 33 – 8 1WS–274A3–00 35 – 1 5JJ–82151–10 45 – 12
43F–23188–10 25 – 18 3MA–25181–10 29 – 9 5SL–25838–00 32 – 9 1WS–26282–00 33 – 9 1WS–274A4–00 36 – 1 5JJ–82151–20 45 – 13
25 – 37 1D7–25317–00 31 – 5 4P5–2583V–00 37 – 1 1RC–26290–00 33 – 15 1WS–28100–00 28 – 23 5JJ–82151–30 45 – 11
1WS–2318U–00 24 – 20 2DR–25338–00–P0 31 – 1 1XB–2584D–00 37 – 23 1WS–26296–00 34 – 27 2H7–28151–00 28 – 20 5JJ–82151–60 45 – 14
1WS–2331G–00 25 – 42 5SL–25364–00 31 – 6 1XB–2584E–00 37 – 24 1WS–26301–00 33 – 5 137–28152–00 28 – 21 5JJ–82151–80 45 – 9
1WS–23340–00 25 – 38 5JJ–25366–00 31 – 10 2C0–25852–00 37 – 11 2C0–26326–00 37 – 15 14B–28164–00 28 – 19 1XB–82309–00 46 – 14
1WS–2334G–00 24 – 14 1WS–2537W–00 31 – 17 5VS–25852–00 34 – 3 5VS–26332–00 34 – 10 23P–28164–00 28 – 22 1WS–82310–00 46 – 3
1WS–2334H–00 24 – 24 1RC–25383–00 31 – 12 20S–25854–00 34 – 5 1WS–26335–00 33 – 11 4KG–28186–10 28 – 25 1WS–82380–00 46 – 1
1WS–23357–00 24 – 3 1WS–25388–00 31 – 22 2VN–25854–00 37 – 12 157–27114–00 28 – 9 1WS–28199–F1 28 – 26 1WS–8246B–00 45 – 30
1W1–23416–00 24 – 2 1WS–2538D–00 31 – 30 2VN–25855–00 37 – 13 1D7–27114–00 28 – 3 1WS–28199–G1 28 – 26 1WS–82504–00 46 – 9
1WS–23430–00 24 – 4 1WS–2538N–00 31 – 31 5VS–25855–00 34 – 4 278–27114–00 28 – 12 1WS–28199–H1 28 – 26 5SL–82511–08 46 – 19
1E6–23441–10–P0 24 – 12 5MT–25398–00 29 – 7 4BP–2585F–01 37 – 4 371–27114–00 28 – 2 1WS–28199–S1 28 – 26 1WS–82530–00 37 – 18
1WS–23442–00–P0 24 – 8 31 – 9 5VS–25867–00 34 – 11 5RU–27114–00 28 – 8 1WS–28219–00 27 – 43 1WS–82540–00 46 – 4
3FV–23462–00 25 – 39 5MT–25398–10 29 – 7 1XB–25872–00 34 – 16 5VX–27114–00 35 – 27 1WS–2834E–00 21 – 2 1WS–8255P–00 46 – 17
1XB–23591–00 47 – 9 31 – 9 1XB–25873–00 34 – 17 36 – 14 1WS–2834F–00 21 – 11 1WS–82566–00 35 – 12
1XB–23592–00 47 – 10 5MT–25398–20 29 – 7 1XB–25874–00 34 – 18 1WS–27211–00 36 – 17 1WS–2836K–00 27 – 8 5PS–82576–01 45 – 33
72
INDICE NUMERICO

1XB–82590–00 45 – 8 1WS–84710–00 43 – 1 90109–08195 46 – 20 90111–06098 35 – 44 90183–05076 21 – 18 90209–21332 16 – 4

1UA–82591–00 45 – 20 1WS–84740–00 43 – 7 90109–086F8 35 – 24 90111–06101 33 – 13 27 – 2 16 – 8
1B3–82911–00 44 – 1 3Y6–85130–02 20 – 41 36 – 11 90111–06119 22 – 27 27 – 6 90209–21351 16 – 12
3YX–82917–01 44 – 8 1WS–85801–00 10 – 5 90110–05067 46 – 6 26 – 30 27 – 22 90209–22352 16 – 11
1WS–83310–00 40 – 1 3B4–85885–00 10 – 14 90110–05071 35 – 14 90111–06122 19 – 33 27 – 26 90209–28008 16 – 24
1KB–83311–00 40 – 2 5YU–85886–00 26 – 5 90110–05112 26 – 19 90111–06137 43 – 2 27 – 41 16 – 28
40 – 6 1XB–8591A–00 46 – 16 90110–06081 1 – 13 90111–06150 42 – 15 27 – 49 16 – 35
40 – 11 1WS–8592A–00 11 – 4 90110–06087 27 – 13 90111–06151 6 – 31 90183–05M02 21 – 26 90214–28002 16 – 32
40 – 15 1XB–85930–09 47 – 1 27 – 32 20 – 5 21 – 28 90214–29002 16 – 31
3D7–83318–10 40 – 9 1XB–85970–00 47 – 5 90110–06152 5 – 8 90111–10058 35 – 17 27 – 12 90240–08005 37 – 7
40 – 18 1XB–85980–00 47 – 11 90110–06163 6 – 23 90111–10060 35 – 2 27 – 31 90269–05055 24 – 22
1WS–83320–00 40 – 5 54P–E416A–00 10 – 15 90110–06168 7 – 6 36 – 2 90183–060A6 45 – 27 90269–06002 19 – 23
1WS–83330–00 40 – 10 3D9–H3333–10 40 – 4 90110–06172 26 – 7 90116–08087 1 – 8 90183–061A7 42 – 10 20 – 29
1KB–8333A–00 40 – 3 40 – 8 28 – 6 90116–10048 31 – 15 90185–10023 35 – 8 90269–06008 6 – 21
40 – 16 40 – 13 90110–06173 7 – 11 90119–06209 19 – 20 90185–16002 22 – 9 21 – 6
1WS–83340–00 40 – 14 40 – 17 90110–06177 38 – 3 90119–06241 20 – 7 90185–18009 31 – 28 21 – 15
1KB–8334A–00 40 – 7 5VX–W0042–51 37 – 2 90110–06274 5 – 37 90119–06263 15 – 10 90201–04030 45 – 35 21 – 30
40 – 12 2TV–W2470–00 28 – 16 90110–06388 13 – 8 90119–09014 12 – 12 90201–054K4 43 – 13 90269–07007 22 – 28
3XV–83350–21 46 – 23 1XB–W8250–00 46 – 15 13 – 15 90119–10056 1 – 12 90201–06029 42 – 18 90269–07008 20 – 40
1WS–83371–00 46 – 24 90101–06043 12 – 11 90110–06389 13 – 9 90149–05029 30 – 4 90201–064K6 9 – 21 90269–07077 19 – 37
1XB–83500–00 41 – 1 90101–10025 35 – 4 13 – 18 32 – 4 90201–08053 35 – 37 27 – 16
3C3–83513–00 24 – 16 90101–12049 22 – 19 90110–06395 12 – 22 90149–06030 28 – 18 36 – 22 27 – 35
5PS–83513–00 41 – 3 90105–05024 1 – 19 13 – 12 90149–06105 20 – 13 90201–08070 37 – 8 27 – 42
1WS–83559–00 41 – 4 90105–06027 1 – 5 90110–06396 4 – 17 20 – 16 90201–10029 15 – 20 27 – 53
4P9–83591–00 46 – 7 90105–06148 37 – 27 90110–08062 21 – 5 35 – 48 90201–10035 19 – 6 90269–08008 35 – 51
5EB–83912–03 44 – 2 90105–06205 20 – 38 21 – 14 36 – 29 35 – 7 36 – 32
5JJ–83913–00 44 – 11 90105–07006 4 – 3 90110–08071 35 – 41 90149–06109 38 – 4 90201–10043 24 – 10 90280–05029 2 – 10
5VS–83922–00 34 – 9 4 – 8 36 – 24 90149–06158 17 – 9 90201–10045 22 – 12 90282–04001 2 – 20
4XV–83929–00 44 – 7 90105–08164 11 – 8 90110–08111 19 – 12 90149–06189 16 – 16 31 – 18 90331–16001 4 – 6
2C0–83945–00 44 – 3 90105–10212 23 – 5 90110–08231 35 – 60 90149–06302 42 – 21 90201–12008 2 – 12 90338–06018 20 – 23
5LV–83951–00 44 – 6 90105–10219 19 – 3 36 – 41 90149–08030 14 – 3 90201–12051 35 – 34 41 – 6
1WS–83972–00 44 – 12 90105–10283 23 – 2 90110–10044 19 – 11 90157–05025 35 – 23 36 – 21 90338–16262 12 – 5
1WS–83975–00 44 – 15 90105–102A6 22 – 11 90111–05003 27 – 7 36 – 10 90201–12575 18 – 12 90340–14132 8 – 6
1HP–83980–01 34 – 12 90105–10349 19 – 4 27 – 10 90160–05013 9 – 10 90201–13020 19 – 8 90340–18002 1 – 6
1WS–84118–00–P0 42 – 11 90105–10445 2 – 21 27 – 17 90164–05001 41 – 2 90201–164H4 22 – 8 90340–36005 13 – 2
1WS–84119–00–P0 42 – 13 90105–10638 30 – 16 27 – 27 90170–06026 35 – 39 90201–17018 35 – 5 90380–16158 22 – 6
1WS–84136–00 24 – 7 30 – 29 27 – 29 90170–08010 37 – 6 90201–177G4 18 – 8 90387–05028 37 – 14
1WS–84300–00 42 – 1 90105–12092 19 – 7 27 – 36 90176–10003 24 – 11 90201–18021 31 – 29 90387–05042 43 – 11
1RC–84314–00 42 – 3 90105–126A8 2 – 11 90111–05007 27 – 44 90179–06072 42 – 22 90201–20008 16 – 43 90387–06024 6 – 22
1RC–84347–00 42 – 4 90109–06100 12 – 18 27 – 46 90179–08410 11 – 6 90201–20030 15 – 14 90387–06026 24 – 17
1TP–84347–00 43 – 9 90109–06202 20 – 22 90111–05037 27 – 18 90179–10024 19 – 5 90202–05088 27 – 19 90387–06057 35 – 47
1WS–84359–00 42 – 7 90109–06245 21 – 4 27 – 37 90179–20007 15 – 16 27 – 38 36 – 28
1WS–84396–00 42 – 19 21 – 13 90111–06038 42 – 8 90179–22018 16 – 42 90206–12005 35 – 35 90387–06066 20 – 8
1RC–84397–00 42 – 2 90109–06293 1 – 10 90111–06060 11 – 3 90183–04039 20 – 25 36 – 19 90387–06107 20 – 14
1WS–84526–00 42 – 5 90109–06295 4 – 20 90111–06084 26 – 12 90183–05042 21 – 7 90208–20001 15 – 15 20 – 17
1WS–84527–00 24 – 15 90109–064G6 30 – 2 27 – 50 21 – 16 90208–22002 16 – 41 90387–0611W 27 – 47
1WS–84547–00 43 – 8 90109–066F0 1 – 21 90111–06089 20 – 32 43 – 5 90209–08295 35 – 42 90387–06130 6 – 30
1WS–8454J–00 42 – 6 90109–08045 32 – 2 90111–06095 41 – 5 90183–05076 21 – 9 36 – 25 90387–06136 26 – 4
73
INDICE NUMERICO

90387–06170 42 – 9 90450–35001 6 – 12 90480–01559 27 – 54 91312–04025 45 – 34 93102–12106 18 – 11 93440–64199 16 – 20

90387–06287 26 – 11 90450–56011 9 – 2 90480–10003 43 – 6 91312–05010 26 – 17 93102–15212 5 – 28 93450–19052 2 – 9
90387–062M9 19 – 43 9 – 14 90480–12015 42 – 17 91312–05020 46 – 2 93102–25017 29 – 4 93501–04011 1 – 7
90387–06300 9 – 19 90450–56012 9 – 3 90480–12023 43 – 12 91312–06016 46 – 13 93102–28022 31 – 3 35 – 56
90387–06301 42 – 16 90462–10064 12 – 19 90480–13001 43 – 4 91312–06025 39 – 10 93102–40030 16 – 21 36 – 37
90387–06372 19 – 22 90464–04001 47 – 8 90480–13010 7 – 9 91312–06030 8 – 9 93106–22019 22 – 3 93603–12007 5 – 36
20 – 31 90464–07009 37 – 26 90480–13018 27 – 48 91314–06014 5 – 7 93106–40013 31 – 13 93605–10090 2 – 18
22 – 26 90464–07014 37 – 25 90480–14003 35 – 46 91314–08030 24 – 5 93108–35004 22 – 5 93900–00030 29 – 6
35 – 43 90464–07M40 6 – 27 36 – 27 25 – 41 93109–17071 22 – 15 31 – 8
90387–067V1 43 – 3 90464–10233 47 – 13 90480–14100 20 – 26 91314–08040 25 – 19 22 – 22 94112–17121 29 – 5
90387–06M60 47 – 3 90464–11007 26 – 29 90480–14229 47 – 2 91314–10035 24 – 6 93210–04092 12 – 3 94118–17079 31 – 7
90387–07042 27 – 51 90464–12013 47 – 7 90480–14452 27 – 52 91317–03006 6 – 9 93210–07540 12 – 14 94118–17080 31 – 7
90387–07391 6 – 6 90464–13073 44 – 14 90480–14604 28 – 4 91317–05010 26 – 20 93210–12790 12 – 6 94581–79060 7 – 4
28 – 5 44 – 18 90480–15001 9 – 17 91317–05040 33 – 10 93210–15566 46 – 12 94582–40108 31 – 21
90387–08079 20 – 6 45 – 24 90480–15014 9 – 18 91317–06020 18 – 15 93210–16325 12 – 9 94591–61134 4 – 12
90387–08101 21 – 8 90464–14010 45 – 18 90480–15363 6 – 5 91380–06012 45 – 15 93210–207A0 7 – 8 94701–00436 1 – 9
21 – 17 45 – 23 90480–16003 26 – 10 91401–20012 37 – 9 93210–21001 46 – 5 95022–06008 45 – 6
90387–1001B 19 – 19 45 – 25 90480–17007 27 – 14 91401–25015 35 – 59 93210–235A1 5 – 2 95022–06010 5 – 4
90387–10050 35 – 6 90464–17008 37 – 22 27 – 33 36 – 40 5 – 6 20 – 11
90387–10107 27 – 15 90464–18002 20 – 24 90480–30167 19 – 30 91402–25015 35 – 20 93210–27194 13 – 20 36 – 4
27 – 34 34 – 26 90501–06022 17 – 3 36 – 7 93210–33786 5 – 13 95022–06020 45 – 28
90387–1012A 22 – 16 90464–18007 45 – 17 90501–12743 35 – 55 91701–08040 35 – 19 93210–357A3 13 – 3 95022–08035 24 – 13
23 – 4 90464–18011 45 – 19 36 – 36 36 – 6 93210–40M10 24 – 23 95027–06010 19 – 45
90387–17017 29 – 8 90464–20191 45 – 16 90501–22721 2 – 17 91702–08040 35 – 58 93306–00006 14 – 8 95027–06020 44 – 5
90387–20035 31 – 20 90464–30009 47 – 14 90501–230E4 15 – 9 36 – 39 93306–00106 5 – 30 95302–08600 31 – 25
90387–20036 31 – 19 90464–65001 45 – 21 90506–18021 18 – 1 91808–16023 1 – 3 15 – 8 95314–06700 35 – 40
90387–21003 16 – 10 90465–08045 13 – 16 90506–23008 36 – 23 1 – 4 93306–00416 31 – 4 95602–05200 20 – 42
90387–25008 16 – 39 36 – 3 90506–23018 35 – 9 92012–06010 19 – 17 93306–20352 29 – 3 35 – 15
90387–250R3 16 – 3 90465–13275 20 – 27 90508–18056 35 – 21 37 – 32 93306–20464 16 – 14 43 – 10
90387–28004 16 – 30 90465–13M24 46 – 21 36 – 8 92012–06012 26 – 13 16 – 44 95602–10200 22 – 13
16 – 34 90467–08003 6 – 25 90508–18132 15 – 19 92012–06016 47 – 17 93306–20480 31 – 2 23 – 3
90387–30012 16 – 19 90467–08075 6 – 17 90508–29040 18 – 5 92012–06040 47 – 16 93306–205B5 31 – 11 23 – 6
90387–31003 16 – 23 6 – 24 90520–01002 20 – 2 92014–06012 35 – 31 93306–20663 16 – 18 31 – 16
90401–10020 37 – 28 90467–090A2 26 – 23 20 – 3 92014–06014 47 – 6 93310–232R9 15 – 12 95602–12200 22 – 20
90401–10042 34 – 20 26 – 25 20 – 4 47 – 12 93315–21570 5 – 27 95607–06200 44 – 4
90401–10172 34 – 19 90467–11044 37 – 16 90520–01004 19 – 25 92014–06016 22 – 31 93315–31758 22 – 14 95617–06100 34 – 8
37 – 30 90467–13083 9 – 16 90520–02011 26 – 33 92014–08025 36 – 16 93317–11096 5 – 26 95702–06500 19 – 32
90401–20009 8 – 3 90467–160A2 9 – 33 90520–05018 42 – 12 92017–06010 19 – 35 14 – 7 28 – 14
90430–06014 5 – 5 90467–170A6 5 – 19 90520–05019 42 – 14 22 – 32 93317–11295 18 – 10 95707–05500 9 – 23
90430–08143 13 – 5 5 – 21 90520–06004 21 – 22 26 – 27 93317–22262 22 – 2 9 – 26
90430–10004 46 – 8 90467–17128 9 – 32 90520–06005 21 – 3 92017–08012 13 – 4 93317–31771 22 – 21 37 – 21
90430–10005 34 – 21 90467–290A0 5 – 10 21 – 12 92902–04100 34 – 14 93399–99931 24 – 1 95707–06500 46 – 25
37 – 29 6 – 11 90520–09002 27 – 56 92902–04600 34 – 15 93399–99932 25 – 40 95802–06010 35 – 50
37 – 31 90468–15139 33 – 6 90520–10023 27 – 9 92902–08600 31 – 26 93440–25186 16 – 5 36 – 31
90445–08010 9 – 30 90480–01558 27 – 20 90520–10024 21 – 20 92902–10200 24 – 9 16 – 7 95802–06025 6 – 7
90445–08020 6 – 15 27 – 39 90520–20003 19 – 14 92907–05600 34 – 29 93440–31187 16 – 25 95807–06012 19 – 42
90445–11M08 6 – 26 90480–01559 27 – 3 90520–20004 19 – 13 92907–08600 5 – 24 16 – 27 95812–06010 28 – 10
90450–35001 5 – 11 27 – 23 90560–17356 29 – 2 93101–12173 5 – 32 16 – 36 95812–06020 5 – 14
74
INDICE NUMERICO

95812–06040 7 – 3
12 – 16
95812–06060 12 – 17
95812–08065 12 – 15
95817–06020 5 – 17
47 – 4
95817–06025 9 – 20
95817–08100 26 – 8
95822–06012 19 – 21
95824–06016 11 – 9
95827–06025 24 – 18
97027–05012 34 – 28
97702–50012 21 – 23
97707–50016 21 – 24
98502–04012 34 – 13
98502–05012 26 – 6
98502–06012 10 – 7
98507–04010 44 – 10
98507–04020 44 – 16
98507–04025 44 – 13
98507–04030 44 – 17
98704–03020 44 – 9
99001–07600 5 – 25
99002–10600 18 – 13
99009–10400 15 – 21
99009–12400 5 – 33
99009–15500 7 – 2
99009–17400 18 – 9
99246–00100 27 – 60
27 – 61
99530–08012 13 – 7
13 – 14
99530–10014 12 – 4
99530–10114 1 – 15
75

MT07 20142 PDF

Cargado por

Información del documento

Título original

Derechos de autor

Formatos disponibles

Compartir este documento

Compartir o incrustar documentos

Opciones para compartir

¿Le pareció útil este documento?

¿Este contenido es inapropiado?

Copyright:

Formatos disponibles

MT07 20142 PDF

Cargado por

Copyright:

Formatos disponibles

MT07A (1XB6) EUROPE

MT07A (1XB8) EUROPE

1. Las modificaciones y agregados que se hayan realizado después de la edición de este

3. La cantidad de componentes para el montaje

CODIGO Nº DESCRIPCION CANT. OBSERVACIONES

4. Los colores de los componentes se indican como sigue en la columna de “OBSERVA-

CODIGO Nº DESCRIPCION CANT. OBSERVACIONES

8. Códigos de color aplicables (El símbolo (*) muestra el color de modelo.)

Abreviatura Nombre de color Código de color

(3) Ubicación de fijación del Rótulo de Modelo SLOVAK

2 4D9–11133–10 .GUIA DE VALVULA 1 8 8

3 91808–16023 .PASADOR DE CLAVIJA 2 2

4 91808–16023 .PASADOR DE CLAVIJA 2 2

6 90340–18002 .TORNILLO, DE DRENAJE 1 1

9 94701–00436 BUJIA (NGK LMAR8A-9) 2 2

11 5VY–1111G–00 CASQUILLO DE GOMA 1 1

12 90119–10056 TORNILLO CON ARANDELA 6 6

13 90110–06081 TORNILLO ALLEN 2 2

14 1WS–11181–00 JUNTA, DE CULATA 1 1 1

15 99530–10114 PASADOR, DE ESPIGA 2 2

16 1WS–11190–00 TAPA CULATA DE CILINDRO 1 1 1

17 1WS–11165–00 .PLACA RESPIRADERO 1 1

18 1WS–11169–00 .EMAPQ CBTA.DE RESP. 1 1

22 5VY–1111G–00 CASQUILLO DE GOMA 4 4

2 1WS–11650–00 BIELA COMPLETA 2 2

3 1RC–11654–00 .TORNILLO DE BIELA 2 2

4 1RC–11656–00 COJINETE PLANO 4 4 UR AZUL

1RC–11656–10 COJINETE PLANO 4 4 UR NEGRO

1RC–11656–20 COJINETE PLANO 4 4 UR MARRON

1RC–11656–30 COJINETE PLANO 4 4 UR VERDE

5 3GM–11416–B0 COJINETE PLANO 1 6 6 UR PURPURA

3GM–11416–A0 COJINETE PLANO 1 6 6 UR BLANCO

3GM–11416–00 COJINETE PLANO 1 6 6 UR AZUL

3GM–11416–10 COJINETE PLANO 1 6 6 UR NEGRO

3GM–11416–20 COJINETE PLANO 1 6 6 UR CASTANO

6 1WS–11631–00 PISTON (NORMA) 2 2

7 1WS–11603–00 JUEGO DE ANILLOS (NORMA) 2 2

8 1WS–11633–00 PASADOR, PISTON 2 2

10 90280–05029 CUNA WOODRUFF 1 1

12 90201–12008 ARANDELA PLANA 1 1

13 1WS–11500–00 COMPENSADOR COMPLETA 1 1

15 1WS–11496–00 .COPA TOPE 1 1

16 1WS–11531–00 .ENGRANAJE CONTRAPESO 1 1

17 90501–22721 .RESORTE DE COMPRESION 8 8

18 93605–10090 .PASADOR DE CLAVIJA 8 8

19 1WS–11533–00 .PLACA DE AMORTIGUADOR 1 1

20 90282–04001 .CHAVETA, RECTA 1 1

22 2S3–11413–00 DESLIZADOR METALICO P/PESO 6 6 UR AZUL

2S3–11413–10 DESLIZADOR METALICO P/PESO 6 6 UR NEGRO

2S3–11413–20 DESLIZADOR METALICO P/PESO 6 6 UR CASTANO

2S3–11413–30 DESLIZADOR METALICO P/PESO 6 6 UR VERDE

2S3–11413–40 DESLIZADOR METALICO P/PESO 6 6 UR AMARILLO

2 1WS–12121–00 VALVULA DE ESCAPE 4 4

3 1WS–12113–01 RESORTE VALVULA INTERNA 4 4

4 1WS–12114–00 RESORTE VALVULA EXTERIOR 4 4

5 1WS–12117–00 RETEN RESORTE DE VALVULA 8 8

6 1WG–12118–00 SEGURO DE VALVULA 16 16

7 4TE–12119–00 SELLO DE ACEITE VALVULA 8 8

8 1WS–12116–00 ASIENTO RESORTE DE VALVULA 8 8

9 4C8–12153–10 LEVANTADOR DE VALVULA 8 8 AMARILLO

4C8–12153–09 LEVANTADOR DE VALVULA (O/S) 8 8 AP VERDE

10 1HX–12168–F0 COJIN, AJUSTADOR 2 (1.50) 8 8 UR

1HX–12168–H1 COJIN, AJUSTADOR 2 (1.55) 8 8 UR
