AL Compact PDH Radio 3 LAN LCT Description

PART 1

Connecting to LCT Equipment -

PC: USB Cable Connexion to LCT Software

Click on Connect

Login to equipment
Equipment @ IP SYSTEM SIAEMICR

To avoid each time to enter Password Connexion automatic to

Connexion from one or more IP@ from a file (See P45)

Clique on OK to accede to the LCT software

PART 2 LCT Windows

Description of the Menu Bar From Left to Write:

Connect / Disconnect
Connect - Contains the commands to activate the connection with every equipment present into the network. Disconnect - Allows deactivating the connection.

Login
Contains the commands to activate the login with one or more remote equipment present into the Equipment list area.

Logout
Contains the commands to deactivate the login with one or more remote equipment present into the Equipment list area.

Refresh
Contains the commands to request the updating of the information present into the Equipment list area.

Equipment
Contains the commands to check the configuration, composition, functional status etc. of the equipment selected into the Equipment list area.

Network
Contains the commands for the management of the users that can use the program.

Option
Contains the commands to customize the program (number of signals that can be stored into the alarm history, connection modes and parameters, etc.).

Tools
Contains the command to save, open, display, transfer a configuration file, the command for the management of the remote equipment list and the command to display the monitoring files (alarms and PM measurements) detected with the Siae Alarm & Performance Monitoring program

Menu Equipment:

Menu Equipment description LCT Interface, they allow opening the equipment graphical interface (Local Craft Terminal or Local Operator Manager). Properties, it allows checking the features (network identification code, addresses, reference date/time, etc.) and executing the software reset of the equipment. View Current Alarms, it allows checking the current alarms.

Alarm Severity Config, it allows changing the forwarding status of the alarms/trap and the seriousness level coupled with the alarms. View Active Manual Operation, it allows checking the actually activated manual operations and setting the time (timeout) after which the forcing operations are automatically deactivated. History Events Realignment, it allows realigning the information relevant to the alarms, memorized into the disk of the PC and displayed into the Alarm History Log area, with the ones really present into the selected equipment. Version, it allows checking the version and executing the updating of the equipment software/firmware. Performances, it allows checking the list of the Performance Monitoring measurements available for the selected equipment type, the status (activated or deactivated) of each single measurement and the relevant results. Units, it allows checking the characteristics of the hardware that composes the equipment. Diagnosis, it allows running the diagnostics program which, analyzing the active alarms of the selected equipment, returns the possible causes that have triggered the alarms themselves. Communication Setup, it allows checking and changing the connection parameters (IP address, baud rate, routing table, OSPF parameters, etc.) used by the equipment. IP/OSI Table Alignment, it allows copying the elements present into the remote element list of the local equipment, into the Remote Element List of the selected equipment. Disable/Enable, it allows disabling and then re-enabling again the connection of a equipment with the program. Equipment Features Management, (Optional) allows checking the functionalities (capacity and additional service channels, management of OSPF protocol, etc.) enabled for the selected equipment. Warning. This command is available only for equipment of PDH-AL type.

Equipment Inventory Report, allows saving to file the configuration and the network parameters of the selected equipment.

PART 3 LCT Interface

To access to the LCT Interface: Equipment LCT Interface

Interface LCT

Description of the higher part of the LCT interface

Channel and Frequencies Transmit and receive. Lower Parity Channel 7 17892.500 MHz Higher Parity Channel 7 18902.500MHz

IDU

ODU

ODU

IDU

Configuration 1+ 0

Configuration: Equipment configuration

Modulation / Capacity
The choice between 4,16 QAM et 8,16, 32 et 64 M Bits is made only locally

Link ID Capacity
The choice between 4,16 QAM et 8,16, 32 et 64 M Bits s is made on remote site first and secondly locally

Tributary: 16x2Mbits on Equipment situated on the front of panel de lIDU

Tributary: Put into service one of 16x2Mbits 2 M Bits

Click on switch to declare the 2M Bits Tributary channel. It decrease the

At nearly the same time, this action has to be performed on Remote and Local side, For this short period, the alarm Demultiplexer will appear, and disappeared when the local and remote tributary shall be activated or deactivated.

If no 2M Bits are not connected on this Port

Independent loop on 16 x 2 M Bits line side and Radio side

2M Bits loop Line side

2Mbits Radio Side

Radio Branch
Frequency Change only Locally

Frequency to be changed is in red

1) To select other frequency, use the lift on the left of the Windows

2) Click on Lock Channel

3) Click on Apply

Link Branch
Frequency Change on the link, both remote and local side with one click on local side

Radio Branch: Power

Manual Mode and Automatic Mode

Automatic: ATCP This allowed to limited the transmit Power of transmitter: -To preserve from interferences other microwave -To limit the consumption

Radio Branch: Setting

Carrier on/off. Tx on/off. Power supply on/off

Configurare-LAN:
LAN 1:

LAN 2:

LAN 3:

INTERNAL PORT:

ETHERNET SWITCH:

Virtual-Lan configuration:

Adaugare VLAN 1. Vid = 1 LAN 1 = Ena. Untagged LAN 2 = Disable LAN 3 = Disable PORT 1 = Ena. Tagged Apply Adaugare VLAN 2. Vid = 2 LAN 1 = Disable LAN 2 = Ena. Untagged LAN 3 = Disable PORT 1 = Ena. Tagged Apply Adaugare VLAN 3. Vid =3 LAN 1 = Disable LAN 2 = Disable LAN 3 = Ena. Untagged PORT 1 = Ena. Tagged Apply

Cum trebuie sa arate configuratia finala dupa adaugarea celor 3 Vlan-uri:

Ex. Configurare SIAE:

Ex. Wo IT: Ip Management : IP 172.17.64.70,Net Mask 255.255.255.224, Def.Gw 172.17.64.65 IP RAU A : IP 172.17.37.49,Net Mask 255.255.255.252 IP RAU B : IP 172.17.37.50,Net Mask 255.255.255.252
Radio 1 USER:SYSTEM PASS:SIAEMICR Radio 1/2 USER:SYSTEM PASS:SIAEMICRO

Radio A Equipment type ALC (NMS=Q3) 1.Equipment /Properties : Radio A / Agent IP: 172.17.64.70 Comunication Setup / Port Configuration IP Eth : 172.17.64.70 255.255.255.224 LCT PPP : 1.0.0.1 255.255.255.252 PPP RADIO : 172.17.37.49 255.255.255.252 Client Set Values /Store 2.Comunication Setup/ Stored Routing Table Routing Table : 2.0.0.0 255.255.255.252 Next Hop 172.17.37.50 pe Radio Def.Gateway: 172.17.64.65 pe LAN 3.Tools/Subnetwork Configutaion Wizard(se foloseste pt ca A sa vada B) New Configutation/Add Station Add Element 1 :IP 172.17.64.70 Managed by SCT Add Element 2 :IP 172.17.37.50 Remote Link Actul Configuration se bifeaza Station/Send

Radio B Equipment type ALC (NMS=Q3) 1. Equipment /Properties : Radio B / Agent IP: 172.17.37.50 Comunication Setup / Port Configuration IP Eth : 10.17.1.1 ?????? nu conteaza 255.255.255.252 nu conteaza LCT PPP : 2.0.0.1 255.255.255.252 PPP RADIO : 172.17.37.50 255.255.255.252 Client Set Values /Store 2.Comunication Setup/ Stored Routing Table Routing Table : Def.Gateway: 172.17.37.49 pe Radio 3.Tools/Subnetwork Configutaion Wizard(se foloseste pt ca B sa vada A) Add Station Add Element 1 :IP 172.17.37.50 Managed by SCT Add Element 2 :IP 172.17.64.70 Remote Link Actul Configuration se bifeaza Station/Send OBS. Se reseteaza echipamentul 1-2 minute Equipment /Comunication Setup / Port Configuration / Set Values /Store/Restart 1.Equipment type ALC (NMS=Q3) 2.Equipment type AL plus (NMS=Q3 - 2porturi cu rol de switch) View Active Manual Operation (mentenanta)
